| Ref | Part Number | Description |
|---|
| 1 |
15808D |
HOOD Not Available Price: |
| 2 |
731-0511 |
Trim Strip 31" Lg. Price: $3.29 |
| 3 |
736-0931 |
Fl-Wash. .20" I.D. x .41" O.D. Price: $4.02 |
| 4 |
712-0272 |
Hex Sems Nut #10-24 Thd. Price: $3.58 |
| 5 |
727-0290A |
Brake Cable 11.75" Lg. This part replaces 727-0290. Price: $10.96 |
| 6 |
710-0473 |
Truss Mach. Scr. #10-24 x .5" Lg. Price: $3.90 |
| 7 |
16550A |
DASH PANEL Not Available Price: |
| 8 |
712-0271 |
Hex Sems Nut 1/4-20 Thd. Price: $3.78 |
| 9 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 10 |
736-0173 |
Fl-Wash. .281" I.D. x .73" O.D. Price: $3.76 |
| 11 |
735-0126A |
RUBBER WASHER Not Available This part replaces 735-0126. Price: |
| 12 |
747-0513 |
BLADE CLUTCH LEVER Not Available Price: |
| 13 |
710-0106 |
Hex Bolt 1/4-20 x 1.25" Lg. Price: $3.66 |
| 14 |
13950A |
BRACKET-CL Not Available Price: |
| 15 |
726-0106 |
PUSH NUT This part replaces 7260106. Price: $3.37 |
| 16 |
747-0307 |
DECK CONTROL ROD Not Available Price: |
| 17 |
710-0286 |
Truss Mach. Scr. 1/4-20 x .5" Lg. Price: $3.86 |
| 18 |
925-0465A |
Safety Switch This part replaces 725-0465A. Price: $26.56 |
| 19 |
712-0121 |
Hex Nut #10-24 Thd. Price: $3.75 |
| 20 |
910-0749 |
CHAIN ADJUSTMENT BOLT Not Available This part replaces 710-0749. Price: |
| 21 |
912-0287 |
HEX NUT 1/4-20 Not Available This part replaces 7120287. Price: |
| 22 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 23 |
15931 |
TIE-STRAP Not Available Price: |
| 24 |
710-0924 |
Truss Mach. Scr. 1/4-20 x.75" Lg. This part replaces 710-0255. Price: $4.02 |
| 25 |
710-0642 |
Hex TT-Tap Scr. 1/4 20 x .75" Lg. Price: $4.05 |
| 26 |
736-0463 |
FI Wash . .25" I . D. x .62" Price: $3.91 |
| 27 |
736-0413 |
Spr. Wash. .39" I.D. x .62" Price: $6.01 |
| 29 |
938-0952A |
Shoulder Bolt, .375 x .125 This part replaces 738-0724. Price: $6.17 |
| 30 |
925-0963 |
Miniature Lamp 12V Socket Type This part replaces 725-0963. Price: $6.73 |
| 31 |
925-1058A |
HEADLAMP SOCKET Not Available This part replaces 725-1058. Price: |
| 32 |
712-0380 |
LOCK NUT 1/4 x 28 Not Available Price: |
| 33 |
931-0705 |
HEADLIGHT HOUSING Not Available This part replaces 731-0705. Price: |
| 34 |
931-0706 |
HEADLAMP LENS Not Available This part replaces 731-0706. Price: |
| 35 |
15804A |
GRILLE Not Available Price: |
| 37 |
722-0157 |
FOAM STRIP Not Available Price: |
| 38 |
710-0118 |
Hex Bolt 5/16-18 x .75" Lg. Price: $3.76 |
| 39 |
16469 |
SIDE COVER - R.H Not Available Price: |
| 40 |
710-05177 |
CARRIAGE BOLT 1/4-20X.50" This part replaces 710-0167. Price: $4.26 |
| 41 |
710-0726 |
Hex Wash. AB-Tap Scr. 5/16 x .75" Lg. Price: $3.82 |
| 42 |
731-0511 |
Trim Strip-81" Lg. Price: $3.29 |
| 43 |
17426 |
Fender Price: Call Us |
| 44 |
710-0946 |
Truss Mach. Scr. 1/4-20 x .62" Lg. Price: $3.24 |
| 45 |
931-1774 |
INDEX BRACKET 7-SPEED Not Available This part replaces 731-1071. Price: |
| 46 |
720-0218 |
Shitt Knob Price: $17.27 |
| 47 |
732-0462 |
EXTENSION SPRING Not Available Price: |
| 48 |
946-0613A |
Choke Control 44.0" Lg. This part replaces 746-0613A. Price: $25.62 |
| 49 |
925-0925 |
Ammeter Not Available This part replaces 725-0925. Price: |
| 50 |
925-0634 |
Light Switch This part replaces 725-0634. Price: $15.62 |
| 51 |
925-0267B |
Ignition Switch This part replaces 725-0267. Price: $33.31 |
| 52 |
925-0201 |
Key This part replaces 725-0201. Price: $8.70 |
| 53 |
15828C |
SUPPORT BRACKET (RH) Not Available Price: |
| 54 |
17294B-0637 |
BRACKET-DASH SUP-L Not Available This part replaces 15829C. Price: |
| 55 |
17399 |
SHIFT COVER Not Available Price: |
| 56 |
720-0166 |
THROTTLE KNOB Not Available Price: |
| 57 |
920-0232 |
Knob This part replaces 720-0165. Price: $9.11 |
| 58 |
910-0289 |
Hex Bolt 1/4-20 x .50" Lg. This part replaces 710-0289. Price: $3.15 |
| 59 |
925-0771 |
Solenoid This part replaces 725-0771. Price: $32.55 |
| 60 |
736-0222 |
Ext. L-Wash. 1/4n I.D. Price: $5.07 |
| 61 |
710-0599 |
Hex Wash. Hd. Scr. 1/4 x .5" Lg. Price: $3.86 |
| 62 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 63 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 64 |
16934 |
FRONT HEAT SHEILD Not Available Price: |
| 65 |
751-0474 |
MUFFLER Not Available Price: |
| 66 |
731-0511 |
Trim Strip 10" Lg. Price: $3.29 |
| 67 |
15826 |
Top Shield Price: Call Us |
| 68 |
831-0823A |
Throttle Control Box Ass'y. Price: $30.59 |
| 69 |
710-0779A |
Truss Mach. AB-Tap Scr. #10 x .5" Lg. Price: $3.85 |
| 70 |
753-0685 |
CIRCUIT BREAKER Not Available This part replaces 725-0459. Price: |
| 71 |
736-0170 |
SPECIAL WASHER Not Available Price: |
| 72 |
722-0138 |
PVC FOAM Not Available Price: |
