| Ref | Part Number | Description |
|---|
| 0 |
640340 |
CARBURETOR This part replaces 640306A. Price: $78.00 |
| 1 |
603000558 |
LOCKNUT, M6-1.00 NYLON INSERT Price: $1.99 |
| 1 |
632791 |
SHAFT & LEV Price: $7.61 |
| 2 |
603000773 |
SEAT HOLDER BASE Price: $24.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
603001049 |
PAN, CENTER, CLOSEOUT Price: $74.99 |
| 4 |
603001585 |
BRKT, SEATBELT, BOLT-ON Price: $24.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
603001673 |
WASHER, HARD, M10, ZN-NI/BLK Price: $1.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
603003464 |
COVER, CENTER CONSOLE Price: $279.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
603000695 |
SCREW, TUFLOK PANEL, 1/4 Price: $1.99 |
| 9 |
603003475 |
NUT, FLANGED, M10 X 1.5, BLACK Price: $2.99 |
| 10 |
31868 |
SHAFT & LEV Price: $7.97 |
| 11 |
603000125 |
HINGE PLATE Price: $8.99 |
| 11 |
632042 |
SPRING Price: $3.00 |
| 12 |
603000736 |
RIVET, 1/4 X .438 BLIND Price: $6.99 |
| 13 |
603000774 |
SCREW, 6M-1.00 X 10MM HEX HEAD Price: $2.99 |
| 14 |
603000777 |
SEAT HOLDER CUP Price: $29.99 |
| 14 |
631890 |
SHUTTER Price: $1.20 |
| 15 |
603000875 |
BOLT - FLANGED HD, M8 X 30.0 Price: $2.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
603001298 |
NUT FLG, M8 X 1.25 MECH DEF Price: $1.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
603001093 |
PAN, SEAT, DRIVER ASM Price: $229.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
603001102 |
DECAL, WARNING HOT SURFACE Price: $3.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
603001137 |
ADJUSTER, FORE/AFT Price: $64.99 |
| 20 |
603001138 |
ADJUSTER, SLIDER Price: $49.99 |
| 20 |
640018 |
FUEL JET Price: $6.16 |
| 20A |
640053 |
CAP Price: $0.81 |
| 21 |
603001145 |
WASHER, BELL Price: $5.99 |
| 22 |
603004080 |
SEAT, BUCKET, BLACK Price: $349.99 |
| 23 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 25 |
603000125 |
HINGE PLATE Price: $8.99 |
| 25 |
631951 |
FLOAT BOWL Price: $12.35 |
| 26 |
603000579 |
SCREW, M8-125 X 22 HEX GR.8.8 Price: $2.99 |
| 27 |
603000184 |
LOCKWASH Price: $1.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
603000689 |
PAN, SEAT - PASSENGER Price: $89.99 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 29 |
603000736 |
RIVET, 1/4 X .438 BLIND Price: $6.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
603000774 |
SCREW, 6M-1.00 X 10MM HEX HEAD Price: $2.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
603000777 |
SEAT HOLDER CUP Price: $29.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
27136A |
DRAIN ASSY Price: $5.96 |
| 32 |
603001102 |
DECAL, WARNING HOT SURFACE Price: $3.99 |
| 33 |
27554 |
GASKET Price: $1.05 |
| 33 |
603004080 |
SEAT, BUCKET, BLACK Price: $349.99 |
| 34 |
603000058 |
LOCKWASHER, 1/4 HELICAL SPLIT Price: $1.99 |
| 35 |
603000054 |
WASHER 1/4 FLAT Price: $1.99 |
| 36 |
640080 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 40 |
640206 |
NUT Price: $5.16 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
