| Ref | Part Number | Description |
|---|
| 1 |
3-8394 |
DISCONTINUED Price: Call Us |
| 2 |
3-7138 |
DISCONTINUED Price: Call Us |
| 2 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 539107518. Price: $3.99 |
| 3 |
351-26 |
DISCONTINUED Price: Call Us |
| 3 |
532133957 |
Wheel, Gauge (AYP part number) This part replaces 539107610. Price: $9.99 |
| 4 |
3-8408 |
DISCONTINUED Price: Call Us |
| 4 |
532405380 |
BLADE.MOWER.46".HI.LIFT This part replaces 777405380. Price: $14.99 |
| 5 |
3233-23 |
Carriage Bolt Price: Call Us |
| 5 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $1.99 |
| 6 |
3210-3 |
SCREW-HH Price: $5.29 |
| 6 |
532400234 |
NUT.FLANGE.LOCK.TOP This part replaces 539107590. Price: $3.99 |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
532193406 |
BOLT.SHOULDER.3/8-16X3-5/8. This part replaces 539107608. Price: $1.99 |
| 8 |
4-2320 |
DISCONTINUED Price: Call Us |
| 8 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 9 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 9 |
532405506 |
COVER.MANDREL.RH.46" Price: $29.99 |
| 10 |
117127 |
TIRE (16 X 6.5-8) 2-PLY -2 WHEEL AXEL This part replaces 231-39. Price: $107.13 |
| 10 |
532405507 |
COVER.MANDREL.LH.46" Price: $29.99 |
| 11 |
3-2889 |
DISCONTINUED Price: Call Us |
| 11 |
532403149 |
BAFFLE CENTER FRONT Price: $11.99 |
| 12 |
532403150 |
BAFFLE FRONT RH Price: $11.99 |
| 13 |
3-8014 |
AXLE SHAFT Price: $49.11 |
| 13 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 14 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 14 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $3.99 |
| 15 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 15 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $44.99 |
| 16 |
5108 |
VALVE This part replaces 232-21. Price: $6.29 |
| 16 |
532174356 |
MANDREL ASM This part replaces 539107515. Price: $49.99 |
| 17 |
242-39 |
WHEEL ASM Price: $244.32 |
| 17 |
539113962 |
PULLEY, DECK Price: $54.99 |
| 18 |
242-32 |
LUG NUT Price: $4.77 |
| 18 |
539107609 |
TORSION SPRING Price: $1.99 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 19 |
532105304 |
CAP-SLEEVE LT This part replaces 539107627. Price: $2.99 |
| 20 |
32146-1 |
DISCONTINUED Price: Call Us |
| 20 |
532131491 |
ROD.HINGE This part replaces 539110462. Price: $1.99 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 21 |
532110452 |
NUT PUSH M This part replaces 539107626. Price: $1.99 |
| 22 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 22 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 23 |
3-6506 |
DISCONTINUED Price: Call Us |
| 24 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 24 |
539118762 |
SPRING Price: $17.99 |
| 25 |
5-0460 |
STRG SWAGED CABLE ASM Price: $96.86 |
| 25 |
539128101 |
CARRIAGE BOLT 3/8-16 X Price: $1.99 |
| 26 |
3-8011 |
DISCONTINUED Price: Call Us |
| 26 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE Price: $1.99 |
| 27 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
539990717 |
NUT 5/16 NYLOC Price: $1.99 |
| 28 |
3-6493 |
DISCONTINUED Price: Call Us |
| 28 |
539976979 |
NUT 3/8-16 NYLOC Price: $1.99 |
| 29 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 29 |
539200282 |
NUT HEX 3/8-16 NYLON, THIN Price: $1.99 |
| 30 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 30 |
539117245 |
V-BELT Price: $49.99 |
| 31 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 31 |
539991034 |
SCREW #10 X 1/2 SELF TAPPING Price: $1.99 |
| 32 |
5-2106 |
PVT CSTR/SFT WA*RO Price: $291.44 |
| 32 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $1.99 |
| 33 |
5-1257 |
DISCONTINUED Price: Call Us |
| 33 |
532137729 |
SCREW.1/4-20X5/8 This part replaces 539107631. Price: $2.99 |
| 34 |
3217-6 |
NUT-HEX Price: $1.19 |
| 34 |
539104870 |
BOLT 7/16-14 X 2-1/2 GR 5 ZD Price: $1.99 |
| 35 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 36 |
32121-48 |
PIN-SPRING Price: $0.61 |
| 36 |
539104864 |
WASHER 7/16 FLAT ZD Price: $1.99 |
| 37 |
510240201 |
DECAL, BELT ROUTING Price: $1.99 |
| 38 |
3-7993 |
DISCONTINUE Price: Call Us |
| 38 |
539132728 |
PULLEY, IDLER Price: $22.99 |
| 39 |
5-1036 |
DISCONTINUED Price: Call Us |
| 39 |
574689002 |
ARM, IDLER BLK Price: $59.99 |
| 40 |
322-13 |
SCREW-HH Price: $2.73 |
| 40 |
532196104 |
PULLEY.IDLER.MWR.STATIONARY.LH Price: $22.99 |
| 41 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 41 |
539112076 |
IDLER BUSHING Price: $6.99 |
| 42 |
3290-239 |
DISCONTINUED Price: Call Us |
| 42 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $1.99 |
| 43 |
3-6501 |
DISCONTINUED Price: Call Us |
| 43 |
539115574 |
EYE BOLT 5/16 X 3.50 Price: $4.99 |
| 44 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 44 |
539990585 |
NUT 5/16C WHIZ Price: $1.99 |
| 45 |
3218-6 |
NUT-JAM Price: $0.61 |
| 45 |
539120920 |
SPRING, DECK BELT Price: $5.99 |
| 46 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 46 |
539990627 |
HCS 5/16C X 1 1/4 Price: $1.99 |
| 47 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 47 |
522629701 |
BELT KEEPER 5" Price: $2.99 |
| 48 |
5-1037 |
DISCONTINUED Price: Call Us |
| 49 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 50 |
322-10 |
SCREW-HH Price: $0.70 |
