| Ref | Part Number | Description |
|---|
| 1 |
69-1180 |
ARMREST Price: $166.08 |
| 2 |
32128-19 |
NUT-HF Price: $0.99 |
| 3 |
323-9 |
SCREW-HH Price: $1.29 |
| 4 |
69-0770 |
BRACKET-ARM, RH Price: $117.82 |
| 5 |
3234-14 |
SCREW-HHF This part replaces 3234-23. Price: $0.61 |
| 502239101 |
502239101 |
SCREW Price: $5.99 |
| 510144101 |
510144101 |
MOTOR BOWL CUTTING MOTOR Price: $24.99 |
| 522771501 |
522771501 |
Price: Call Us |
| 525251401 |
525251401 |
TIE WRAP Price: $3.99 |
| 535075501 |
535075501 |
HUB CUTTING DISC Price: $8.99 |
| 535075702 |
535075702 |
SPACER Price: $11.99 |
| 535075901 |
535075901 |
PLATE SKID Price: $17.99 |
| 535076001 |
535076001 |
SCREW Price: $3.99 |
| 535081501 |
535081501 |
COVER SKID PLATE Price: $5.99 |
| 535082501 |
535082501 |
GASKET Price: $2.99 |
| 535122301 |
535122301 |
BELLOWS Price: $49.99 |
| 535123601 |
535123601 |
MOTOR Price: $109.99 |
| 535126301 |
535126301 |
BLADE DISC Price: $17.99 |
| 535126401 |
535126401 |
BEARING Price: $7.99 |
| 535130501 |
535130502 |
SCREW TORX M4X8 8.8 NYLON PATC This part replaces 535130501. Price: $2.99 |
| 535138501 |
535126301 |
BLADE DISC This part replaces 535138501. Price: $17.99 |
| 575543310 |
575543310 |
SCREW SILVER 10MM Price: $2.99 |
| 575543314 |
575543314 |
SCREW 14MM Price: $3.99 |
| 728828501 |
728828501 |
SCREW Price: $1.99 |
