| Ref | Part Number | Description |
|---|
| 1 |
108-6715 |
GAUGE BAR ASM Price: $148.12 |
| 1 |
532123385 |
Pulley (AYP part number) Price: $22.99 |
| 2 |
29-9100 |
BRUSH AND HANDLE ASM Price: $58.15 |
| 2 |
812000028 |
Ring, Retainer (AYP part number) Price: $4.99 |
| 3 |
532123655 |
Transaxle, Foote 6 Speed, Model No. 4360-18 (AYP part number) Price: $489.53 |
| 4 |
115-0803 |
ROLLER REBUILD TOOL KIT Price: $122.41 |
| 4 |
532125096 |
Key, Woodruff #9 (AYP part number) Price: $3.99 |
| 5 |
125-5610 |
PAPER-REEL, TORO (10 PACK) Price: $6.02 |
| 5 |
873680600 |
Nut, Crownlock 3/8-16 Price: $1.99 |
| 6 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 7 |
532123378 |
Strap, Torque (AYP part number) Price: $2.99 |
| 8 |
817490508 |
Screw, Hex Thdrol. 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 9 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $4.99 |
| 10 |
532059192 |
Cap, Valve (AYP part number) Price: $3.99 |
| 11 |
532065139 |
Stem, Valve (AYP part number) Price: $5.99 |
| 12 |
532008134 |
Tube (AYP part number) Price: $37.99 |
| 13 |
532122075 |
TIRE.FRT.(16X6).TURF.SAVER This part replaces 532106230. Price: $54.99 |
| 14 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $1.99 |
| 15 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Ga. (AYP part number) Price: $1.99 |
| 16 |
812000001 |
E-Ring (AYP part number) Price: $2.99 |
| 17 |
532104757 |
Cap, Axle (AYP part number) Price: $1.99 |
| 18 |
532124844 |
Rim (AYP part number) Price: $137.43 |
| 19 |
532123409 |
Spacer (AYP part number) Price: $3.08 |
| 20 |
532123583 |
Key, Square (AYP part number) Price: $2.99 |
| 21 |
874760644 |
Bolt, Fin, Hex 3/8-16x 2-3/4 (AYP part number) Price: $3.99 |
| 22 |
532123377 |
Bracket, Transaxle (AYP part number) Price: $2.99 |
| 23 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 24 |
876020416 |
Pin, Cotter 1/8 X 1 (AYP part number) Price: $3.99 |
| 25 |
532128085 |
Extension, Spring (AYP part number) This part replaces 532123393. Price: $4.99 |
| 26 |
532123632 |
Link, Shift (AYP part number) Price: $14.99 |
| 27 |
810040400 |
Washer, Lock Hvy. Helical Spring 1/4 (AYP part number) Price: $3.99 |
| 28 |
871040412 |
Bolt, Fin, Hex 1/4-28 UNF x 3/4 Gr.8 (AYP part number) Price: $3.99 |
| 29 |
531003379 |
WASHER This part replaces 819091210. Price: $2.99 |
| 30 |
532122011 |
Knob, Shift Contol (AYP part number) Price: $6.08 |
| 31 |
532123692 |
Retainer, Knob (AYP part number) Price: $2.42 |
| 32 |
532125976 |
Assembly, Shift Handle (AYP part number) Price: $21.03 |
| 33 |
873510500 |
Nut, Keps 5/16-18 (AYP part number) Price: $5.99 |
| 34 |
532105701 |
Washer, Shift Plate (AYP part number) Price: $3.99 |
| 35 |
532123539 |
Arm, Shift (AYP part number) Price: $2.38 |
| 36 |
873610500 |
This part replaces 873810500. Price: Call Us |
