| Ref | Part Number | Description |
|---|
| 1 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 1 |
530057991 |
Assy-Throttle Cable Price: $8.99 |
| 1 |
631199 |
SHAFT & LEV Price: Call Us |
| 2 |
104-3546 |
PULLEY-DRIVEN, LOW Price: $163.56 |
| 2 |
530058000 |
Trigger Price: $2.99 |
| 3 |
530057582 |
Throttle Hsg. (Right) Price: $7.99 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
119-4775 |
SPINDLE HOUSING ASM Price: $244.67 |
| 4 |
530015880 |
Screw-Throttle Hsg. Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 5 |
530015786 |
Bolt-Handle Price: $1.99 |
| 5 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 6 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 6 |
530071971 |
Kit-Drive Shaft Assy. Price: $24.99 |
| 6 |
630766 |
SPRING Price: $1.25 |
| 7 |
120-5576 |
WASHER-HARDENED Price: $3.91 |
| 7 |
530095803 |
Shaft- Flex Price: $5.99 |
| 7 |
631200 |
SHAFT & LEV Price: Call Us |
| 8 |
530057581 |
Throttle Hsg. (Left) Price: $7.99 |
| 9 |
631222 |
SHUTTER Price: Call Us |
| 10 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 10 |
630898 |
ADJ SCREW Price: $1.69 |
| 11 |
545026201 |
Assy-Handle This part replaces 530150338. Price: $11.99 |
| 11 |
630738 |
SPRING Price: $1.25 |
| 11A |
631192 |
SPRING Price: Call Us |
| 12 |
530052286 |
Line Limiter Price: $1.54 |
| 12 |
630739 |
WASHER Price: $1.25 |
| 12A |
631191 |
WASHER Price: $1.20 |
| 13 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 13 |
630740 |
O RING Price: $1.49 |
| 13A |
631190 |
O RING Price: Call Us |
| 14 |
530095563 |
Dust Cup Price: $9.99 |
| 14 |
631189 |
ADJ SCREW Price: Call Us |
| 15 |
530015820 |
Bolt Price: $1.99 |
| 15 |
630748 |
WELCH PLUG Price: $1.17 |
| 16 |
630953 |
PUMP ELEMENT Price: $6.03 |
| 17 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 17 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 18 |
631049 |
SPRING Price: $1.20 |
| 19 |
530071306 |
Kit-Hub Ass'y This part replaces 530095776. Price: $8.99 |
| 19 |
630742 |
GASKET Price: $1.25 |
| 20 |
530053241 |
Spring-Compression Price: $1.99 |
| 20 |
630932A |
INLET NEEDLE Price: $4.39 |
| 21 |
530401957 |
Clip-Retainer-Head Price: $1.99 |
| 21 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 22 |
630978 |
DIAPHRAGM Price: $4.49 |
| 22 |
952701719 |
TNG 6 RH .080X25' PLN This part replaces 952711616. Price: $7.95 |
| 23 |
630751 |
COVER Price: $8.60 |
| 24 |
650545 |
SCREW Price: $1.20 |
| 25 |
631201 |
CHECK VALVE Price: $15.40 |
| 26 |
631202 |
FUEL FITTING Price: $9.70 |
| 28 |
650569 |
SCREW Price: Call Us |
| 29 |
630955 |
RETAINER--NLA Price: Call Us |
| 30 |
650545 |
SCREW Price: $1.20 |
| 31 |
631203 |
SPRING Price: Call Us |
