| Ref | Part Number | Description |
|---|
| 1 |
903-05143C |
LATCH HANDLE Price: $148.39 |
| 4 |
680E01074 |
DECK LIFT SHAFT Price: $136.61 |
| 5 |
680-01094 |
DECK CONTROL ROD Price: $82.46 |
| 12 |
710-0182A |
SCREW-HEX 1/2-13 x 3.00 Price: $6.88 |
| 13 |
910-0224 |
HEX SCREW AB-TAP #10 x .50 Price: $3.19 |
| 14 |
710-04186 |
SCREW 1/2-13 x 1.25 GR5 Price: $6.17 |
| 15 |
710-0451 |
CARRIAGE BOLT 5/16-18 x .75 Price: $3.53 |
| 16 |
710-0521 |
SCREW 3/8-16 x 3 GR8 Price: $4.54 |
| 17 |
710-06047 |
SCREW 5/8-11 x 2.25 GR5 Price: $3.74 |
| 18 |
710-06428 |
EYE BOLT 5/8-11 x 3.63 Price: $20.29 |
| 19 |
710-07874 |
SCREW 5/8-11 X 4.5 GR5 Price: $6.04 |
| 20 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 21 |
710-3067A |
FLANGE BOLT 1/2-13:1.75:GR5 Price: $6.51 |
| 22 |
710-3240A |
SCREW 5/8-11 x 3.75 GR5 Price: $8.25 |
| 23 |
711-05217 |
CLEVIS PIN .50 x 2.00 Price: $11.63 |
| 24 |
711-0642A |
LIFT HANDLE BUTTON Price: $6.90 |
| 25 |
711-09882 |
DECK LIFT SHAFT Price: $54.53 |
| 26 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 27 |
712-04065 |
NUT Price: $3.68 |
| 28 |
712-04150 |
NUT Price: $3.74 |
| 29 |
712-04151 |
FLANGE LOCK NUT Price: $3.37 |
| 30 |
712-3000 |
LOCK NUT 3/8-16 Price: $3.90 |
| 31 |
712-3015 |
HEX NUT Price: $4.02 |
| 32 |
714-05005 |
BOW TIE COTTER PIN Price: $4.24 |
| 33 |
720P05841 |
MAGNETIC DECK LOCK KNOB Price: $42.57 |
| 34 |
731-3158 |
LIFT HANDLE GRIP Price: $15.37 |
| 35 |
732-3097 |
COMPRESSION SPRING Price: $12.51 |
| 36 |
736-0208 |
WASHER .51 x 1.5 x .07 Price: $4.02 |
| 37 |
736-04088 |
FLAT WASHER .635 x 1.24 x .181 Price: $3.90 |
| 38 |
736-0445 |
FLAT WASHER Price: $3.95 |
| 39 |
736-05642 |
FLAT WASHER .53"x2.125"x.25" Price: $6.20 |
| 40 |
738-1011A |
SHOULDER SCREW .50 x 2.23 3/8-16 Price: $7.65 |
| 41 |
741-0491 |
NYLINER BEARING Price: $4.39 |
| 42 |
948-3051A |
FLANGE BEARING Price: $23.56 |
| 43 |
750-06078 |
SPACER 0.535 x 0.68 x 0.83 Price: $3.66 |
| 44 |
750-07690 |
SPACER 0.630x1.25x1.00LG Price: $5.29 |
| 45 |
750-07750 |
SPACER .38 ID x .50 OD x 2.06 LG Price: $3.90 |
| 46 |
750-11232 |
SPACER .542 ID X 1.375 LG Price: $11.65 |
| 47 |
750-1206 |
SPACER Price: $14.23 |
