| Ref | Part Number | Description |
|---|
| 1 |
784-0171A |
BRACKET ASSEMBLY-SHIFT Not Available Price: |
| 2 |
932-0496 |
Compression Spring .50" Lg. This part replaces 732-0496. Price: $4.19 |
| 3 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 4 |
738-0645 |
Detent Shaft 1/2" Dia. Price: $54.36 |
| 5 |
750-0664 |
Spacer .505" I.D. x .88" O.D. Price: $6.01 |
| 6 |
941-0155 |
Bearing .62" I.D. x 1.38" O.D. x .437" Thk. This part replaces 741-0155. Price: $22.09 |
| 7 |
717-0851 |
GEAR-SPUR-16T Not Available Price: |
| 8 |
717-0852 |
INPUT SHAFT Not Available Price: |
| 9 |
750-0651 |
SPACER Not Available Price: |
| 10 |
736-0187 |
Fl-Wash. .640" I.D. x 1.24" Price: $4.02 |
| 11 |
717-0857 |
GEAR-SPUR-30T Not Available Price: |
| 12 |
941-0478 |
NEEDLE BEARING Not Available This part replaces 741-0478. Price: |
| 13 |
921-0211 |
GASKET Not Available This part replaces 721-0211. Price: |
| 14 |
710-0599 |
Hex S-Tap Scr. 1/4-20 x .5" Price: $3.86 |
| 15 |
784-0211 |
HOUSING-BRG Not Available Price: |
| 16 |
710-0642 |
Hex TT-Tap Scr. 1/4-20 x .75" Price: $4.05 |
| 17 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 18 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 19 |
750-0662 |
SPACER-1.560 1D Not Available Price: |
| 20 |
712-0378 |
Hex Nut 7/16-20 Thd. Price: $5.99 |
| 21 |
736-0407 |
Bell-Wash. .45" I.D. x 1.0" Price: $3.64 |
| 22 |
750-0661 |
SPACER-1.015 1D Not Available Price: |
| 23 |
941-0420B |
BEARING This part replaces 741-0420. Price: $36.19 |
| 26 |
721-0379 |
Seal .75" Shaft Price: $16.93 |
| 27 |
611-0021A |
TINE SHAFT ASSEMBLY W/18T This part replaces 611-0021. Price: $135.73 |
| 28 |
736-0351 |
Fl-Wash. .76" I.D. x 1.5" O.D. Price: $3.93 |
| 29 |
950-0671 |
Spacer .75 x 2.0 x .50 This part replaces 750-0671. Price: $10.01 |
| 30 |
913-0226 |
Chain #50 5/8 Pitch x 52 Links - Endless This part replaces 713-0226. Price: $89.85 |
| 31 |
741-0488 |
BEARING-NE Not Available Price: |
| 32 |
716-0865 |
Snap Ring Price: $3.86 |
| 33 |
726-0277 |
Taper Cap Plug Price: $4.19 |
| 34 |
717-0854 |
Spur Gear 30T 12/16" I.D. Price: Call Us |
| 35 |
717-0874 |
GEAR-30/44T Not Available Price: |
| 37 |
941-0181 |
SLEEVE BEARING .627 x .750 X Not Available This part replaces 741-0181. Price: |
| 38 |
717-0835 |
HUB-GEAR Not Available Price: |
| 39 |
717-0855 |
SPUR GEAR-30T Not Available Price: |
| 40 |
738-0647 |
JACKSHAFT Not Available Price: |
| 41 |
738-0648 |
Jack Shaft 5/8" Dia. x 2.38" Price: $45.11 |
| 43 |
717-1471 |
GEAR SPUR 44T Not Available Price: |
| 45 |
741-0421B |
BEARING This part replaces 741-0421. Price: $23.31 |
| 47 |
753-05575 |
KIT-SERVICE WHEEL SHAFT 611-0020 Not Available This part replaces 611-0020. Price: |
| 48 |
784-0192 |
BRACKET GEAR CASE - R H. Not Available Price: |
| 49 |
686-0074 |
R.H. HOUSING ASS'Y. Not Available Price: |
| 50 |
710-3103 |
Hex Bolt 5/16-18 x 2.00" Lg. This part replaces 710-0116. Price: $4.02 |
| 51 |
710-0378 |
Hex Bolt 5/16-18 x 2.5" Price: $4.09 |
| 52 |
710-0513A |
BOLT 1/4-28 X .625 GR8 This part replaces 710-0513. Price: $4.04 |
| 53 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 54 |
736-0176 |
Fl-Wash. 1/4" I.D. x .93" O.D. Price: $3.95 |
| 55 |
786-0065 |
BRACKET-GE Not Available Price: |
| 56 |
936-0406 |
Fl-Wash. 7/16" I.D. x 1-3/8" O.D. This part replaces 736-0406. Price: $5.94 |
| 57 |
921-0378 |
Seal 1.0 Shaft This part replaces 721-0378. Price: $17.34 |
| 58 |
950-0570 |
Step Spacer This part replaces 750-0570. Price: $8.81 |
| 59 |
717-0853A |
Shifting Fork This part replaces 717-0853. Price: $73.49 |
| 60 |
710-0376 |
Hex Bolt 5/16-18 x 1" Lg. Price: $3.66 |
| 63 |
984-0162A |
SPROCKET ASSEMBLY-10T Not Available This part replaces 784-0162A. Price: |
| 64 |
736-0163 |
Thrust Wash. 1.03" I.D. x 1.62" O.D. Price: $4.05 |
