| Ref | Part Number | Description |
|---|
| 1 |
95-5986 |
HYD HOSE ASM This part replaces 74-3830. Price: $77.25 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
95-5987 |
HOSE-HYD This part replaces 63-3840. Price: $68.07 |
| 3 |
56-7981 |
SLEEVE-PROTECTIVE Price: $24.56 |
| 4 |
70-8600 |
HYDRAULIC HOSE ASSEMBLY Price: $203.81 |
| 5 |
70-7150 |
HYDRAULIC HOSE ASSEMBLY Price: $135.85 |
| 6 |
63-3930 |
HOSE ASM Price: $62.22 |
| 7 |
63-3900 |
HOSE ASM Price: $151.52 |
| 8 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
92-9767 |
HOSE This part replaces 63-3880. Price: $69.61 |
| 10 |
27-3040 |
DISCONTINUED Price: Call Us |
| 11 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
63-3940 |
HOSE ASM Price: $150.79 |
| 13 |
63-3910 |
HOSE ASM Price: $144.55 |
| 14 |
63-3920 |
HOSE ASM Price: $105.86 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
83-1200 |
TUBE-TRACTION, LH (LOWER) Price: $110.49 |
| 16 |
83-2460 |
HOSE ASSY - HYD Price: $118.42 |
| 17 |
63-3850 |
HOSE ASM Price: $83.26 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 18 |
63-3890 |
HOSE ASM Price: $60.05 |
| 19 |
70-7130 |
LINE-TUBE Price: $141.98 |
| 20 |
532412165 |
CONTROL.THROTTLE.COBRA.BLACK Price: $27.99 |
| 20 |
68-5880 |
HOSE-HYD Price: $112.20 |
| 21 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
63-3950 |
HOSE ASM Price: $67.13 |
| 23 |
95-5988 |
HOSE-HYD This part replaces 63-3870. Price: $63.42 |
| 24 |
95-5989 |
HOSE-HYD This part replaces 63-3830. Price: $88.20 |
| 25 |
63-4020 |
TUBE-HYD Price: $176.67 |
| 26 |
100-6431 |
TUBE-RETURN This part replaces 63-4040. Price: $176.26 |
| 27 |
63-4030 |
TUBE-HYD Price: $148.62 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 28 |
95-5985 |
HOSE-HYD This part replaces 63-3820. Price: $73.16 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
56-7980 |
SLEEVE-PROTECTIVE Price: $22.90 |
| 30 |
95-5984 |
HOSE-HYD This part replaces 63-3810. Price: $81.29 |
| 31 |
3334-945 |
TIE-CABLE This part replaces 3333-975. Price: $0.43 |
| 32 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 33 |
70-8610 |
HYDRAULIC HOSE ASSEMBLY Price: $155.38 |
| 34 |
2412-41 |
CLAMP-R Price: $4.82 |
| 35 |
12-3270 |
SCREW Price: $3.09 |
| 36 |
321-3 |
SCREW-HH Price: $0.28 |
| 37 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 39 |
56-7981 |
SLEEVE-PROTECTIVE This part replaces 56-7986. Price: $24.56 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
