| Ref | Part Number | Description |
|---|
| 1 |
137-6113 |
LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 114-5415. Price: $383.80 |
| 1 |
532140064 |
Spring, Mower Clutch (AYP part number) Price: $12.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
873680600 |
Nut, Crownlock 3/8-16 Price: $1.99 |
| 4 |
532130840 |
Brake Asm. (AYP part number) Price: $8.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532131251 |
Guide, Belt Idler (AYP part number) Price: $3.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
532121316 |
Pulley, Flat Idler (AYP part number) Price: $22.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 7 |
872110616 |
Bolt, Carr. 3/8-16 x 1-3/4 Gr. 5 (AYP part number) Price: $3.99 |
| 8 |
734117201 |
WASHER This part replaces 819131410. Price: $1.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
532127744 |
Arm Asm., Idler Mower (AYP part number) Price: $11.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
583611601 |
BOLT.3/8-14X1.25 This part replaces 872140610. Price: $3.99 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532130841 |
Rod, Brake (AYP part number) Price: $22.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532127356 |
Bracket, Lift R. H. Rear Price: $3.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
532127357 |
Bracket, Lift L. H. Rear Price: $4.99 |
| 16 |
532153298 |
BELT KEEPER This part replaces 532140093. Price: $9.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
532128508 |
Link, Asm. Mower Stabilizer Price: $41.84 |
| 18 |
532128511 |
Pin, Drive (AYP part number) Price: $2.99 |
| 19 |
532127380 |
Bracket, Asm. Front (AYP part number) Price: $7.99 |
| 20 |
532140101 |
Blade Mulching Price: $17.99 |
| 21 |
532140296 |
Washer, Hard (AYP part number) Price: $2.99 |
| 22 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 23 |
532850857 |
Bolt 3/8-24 x 1-1/4 Gr. 8 (AYP part number) Price: $1.99 |
| 24 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532140329. Price: $3.99 |
| 25 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $1.99 |
| 26 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 27 |
532129983 |
Deck Assembly Price: $129.99 |
| 28 |
532129207 |
Pulley, Mandrel (AYP part number) Price: $12.99 |
| 29 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $4.99 |
| 30 |
532136631 |
Bracket, Asm. Deflector (AYP part number) Price: $8.99 |
| 31 |
817490508 |
Screw, Hex Wsh. Thdrol. 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 32 |
532122051 |
Arm, Support Idler Mower (AYP part number) Price: $3.99 |
| 33 |
532131560 |
Deflector (AYP part number) Price: $29.99 |
| 36 |
583383801 |
PIN.HINGE.30 This part replaces 532121980. Price: $2.99 |
| 37 |
532123713 |
Spring, Torsion Deflector (AYP part number) Price: $3.99 |
| 38 |
532105304 |
Cap, Sleeve (AYP part number) Price: $2.99 |
| 39 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. (AYP part number) Price: $5.99 |
| 40 |
532110452 |
Pushnut (AYP part number) Price: $1.99 |
| 41 |
532131264 |
V-Belt Price: $19.99 |
| 42 |
819171616 |
Washer 11/32 x 5/8 16 Ga. (AYP part number) Price: $5.99 |
| 43 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 44 |
532140608 |
Keeper, L. H. (AYP part number) Price: $17.99 |
| 45 |
532110485 |
Bearing (AYP part number) Price: $7.99 |
| 46 |
532128774 |
Housing Mandrel Vented Price: $22.99 |
| 47 |
532129895 |
Bearing (AYP part number) Price: $6.99 |
| 48 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $17.99 |
| 49 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 50 |
532145989 |
Bolt, RdHd Sqnk M5 x 0.8 x 16 (AYP part number) Price: $8.99 |
| 51 |
532136383 |
Guard, Dftr. Mwr. 36 Tuv (AYP part number) Price: $74.99 |
| 52 |
819070718 |
Washer 7/32 x 7/16 x 18 (AYP part number) Price: $5.99 |
| 53 |
532145990 |
Nut, Acom M5 x 0.8 (AYP part number) Price: $5.99 |
