| Ref | Part Number | Description |
|---|
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
195968 |
Axle Asm., Front Price: Call Us |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 4 |
403089 |
Spindle Asm., LH Price: Call Us |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
403090 |
Spindle Asm., RH Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
194746 |
Shaft Steering Price: Call Us |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
195626X428 |
Boot, Steering Price: Call Us |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 45 |
19183812 |
Washer 9/16 x 2-3/8 x 12 Ga. Price: Call Us |
| 50 |
73900600 |
Nut Lock Flg. 3/8-16 unc Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex Hs 3/8-16 unc x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
197246 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
