| Ref | Part Number | Description |
|---|
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 1 |
67-7050 |
FIELD AND ROTOR ASM Price: $667.81 |
| 1 |
KB-15841-72860 |
PIPE Not Available Price: |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
KB-15841-72870 |
PIPE Not Available Price: |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 3 |
KB-15841-91510 |
STUD Not Available Price: |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 4 |
KB-02056-50060 |
NUT Not Available Price: |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
67-7070 |
DISCONTINUED Price: Call Us |
| 5 |
KB-04512-70060 |
WASHER Not Available This part replaces KB-04512-50060. Price: |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
67-7080 |
DISCONTINUED Price: Call Us |
| 6 |
KB-09318-89030 |
HOSE CLAMP Not Available Price: |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
67-7090 |
DISCONTINUED Price: Call Us |
| 7 |
KB-04012-50060 |
WASHER PLA Not Available Price: |
| 8 |
67-7060 |
RING-RETAINING Price: $10.44 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 8 |
KB-19054-72700 |
Flange, Water Price: Call Us |
| 9 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
KB-19498-83040 |
SWITCH-TEMP. Not Available This part replaces KB-19498-83041. Price: |
| 10 |
44-8320 |
SPRING Price: $8.31 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 10 |
KB-15841-72923 |
GASKET-WATER FLANG Not Available This part replaces KB-15841-72920. Price: |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 11 |
KB-01023-50616 |
BOLT W/WASHER Not Available Price: |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
KB-15841-91040 |
BOLT Not Available Price: |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
KB-1E399-73010 |
THERMOSTAT ASSEMBLY Not Available This part replaces KB-19203-73010. Price: |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 14 |
KB-15841-73260 |
COVER Not Available Price: |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
KB-16851-73270 |
GASKET-THERMOSTAT Not Available This part replaces KB-15531-73270. Price: |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 16 |
KB-01023-50622 |
BOLT Not Available Price: |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
KB-12581-73353 |
Pipe, Water Return Price: Call Us |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
