| Ref | Part Number | Description |
|---|
| 1 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 1 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 2 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 2 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 3 |
532141342 |
KEEPER/MOWER DRIVE RH Price: $4.99 |
| 4 |
112-0169 |
SEATBELT ASM-SERVICE This part replaces 21-4191. Price: $283.31 |
| 4 |
532138029 |
PULLEY.ENGINE.36/38 LR Price: $48.99 |
| 5 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 5 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 6 |
323-4 |
SCREW-HH Price: $1.02 |
| 6 |
871170744 |
Bolt Hex 7/16-20 Gr. 5 Price: $2.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
532124525 |
BELT Price: $39.99 |
| 8 |
3212-4 |
SCREW-HH Price: $2.73 |
| 8 |
532156109 |
BELT KEEPER KIT This part replaces 532123405. Price: $3.99 |
| 9 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 9 |
872140612 |
Bolt, Carr. 3/8-16 UNC x 1-1/2 Price: $2.99 |
| 10 |
532123396 |
KEEPER.BELT.GROUND.DRIVE.IDLER Price: $4.99 |
| 10 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 11 |
532140911 |
ARM/GROUND DRIVE CLUTCH Price: $4.35 |
| 11 |
92-8753 |
DISCONTINUED Price: Call Us |
| 12 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 12 |
532123674 |
PULLEY.IDLER.FLAT Price: $24.99 |
| 13 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 13 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 14 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 15 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 15 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 16 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 16 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 17 |
2412-133 |
CLAMP-R Price: $3.19 |
| 17 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
532131459 |
SPRING.EXTENSION Price: $4.99 |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 20 |
532139919 |
KEEPER-T/A GROUND DRIVE BELT Price: $2.99 |
| 20 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 21 |
2412-93 |
CLAMP-R Price: $1.02 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 22 |
532123404 |
KEEPER,FRA DR BEL Price: $3.22 |
| 22 |
92-6534 |
ORDER COMPLETE SEAT Price: Call Us |
| 23 |
351-78 |
EDGING Price: $60.98 |
| 23 |
532140916 |
KEEPER-MOWER DRIVE LH Price: $5.99 |
