| Ref | Part Number | Description |
|---|
| 0 |
632991 |
CARBURETOR This part replaces 632237. Price: $108.30 |
| 1 |
121-4618 |
ARM-HOC, RH Price: $146.18 |
| 1 |
532156368 |
DECAL OPER Price: $3.99 |
| 1 |
631776A |
SHAFT & LEV Price: $12.00 |
| 2 |
106-8535 |
RH LIFT ARM ASM Price: $102.21 |
| 2 |
532186906 |
Price: $5.46 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 3 |
121-4614 |
NUT-HF Price: $2.10 |
| 3 |
532164579 |
Price: $4.18 |
| 4 |
107-8107 |
WASHER-WAVE Price: $8.93 |
| 4 |
532186764 |
DECAL SIDE PNL Price: $5.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
106-8482 |
ADJUSTER Price: $30.57 |
| 5 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 6 |
32120-19 |
E-RING Price: $2.27 |
| 6 |
532179128 |
DECAL DECK "B" 42" Price: $2.99 |
| 6 |
631778 |
SHUTTER Price: $1.20 |
| 7 |
104-4754 |
SPRING-DETENT Price: $23.47 |
| 7 |
532162391 |
Price: $6.05 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 8 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY This part replaces 532170563. Price: $2.99 |
| 9 |
121-4615 |
SCREW-HH Price: $0.26 |
| 9 |
532171448 |
Price: $3.84 |
| 10 |
106-8528 |
SCREW-LOCK Price: $16.17 |
| 10 |
532157002 |
Price: $2.66 |
| 10 |
631779 |
SHAFT & LEV Price: $5.16 |
| 11 |
121-4616 |
PIN-GROOVED Price: $1.49 |
| 11 |
532162398 |
Price: $2.38 |
| 11 |
631780B |
RET SPRING This part replaces 631780A. Price: $1.25 |
| 12 |
121-4617 |
ROD-LIFT Price: $11.77 |
| 12 |
532181249 |
DECAL.CLUTCH/BRAKE.HYDR.ENG. Price: $2.99 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
581580001 |
DECAL.V-BELT.SCH.42/46"MEC/ELE This part replaces 532160396. Price: $8.99 |
| 14 |
631753 |
SHUTTER Price: $1.25 |
| 16 |
532164578 |
DECAL HOOD RH Price: $5.99 |
| 16 |
632527 |
FUEL FITTING Price: $6.03 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 20 |
632281 |
IDLE SCREW Price: $2.60 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
630740 |
O RING Price: $1.49 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 40 |
632239 |
POWER SCREW Price: $10.32 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 581724901 |
DECAL.TRACTOR.6MIL.H/ADJUST |
This part replaces 532138311. Price: $11.99 581724901 |
