| Ref | Part Number | Description |
|---|
| 1 |
3296-9 |
NUT-HEX Price: $0.25 |
| 2 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 2 |
737-0280 |
GREASE FITTING (SLOTTED) Price: $6.84 |
| 3 |
85-9150 |
PLATE-SWITCH Price: $5.42 |
| 3 |
934-0255 |
Tubeless Air Valve This part replaces 734-3068. Price: $3.83 |
| 4 |
323-10 |
SCREW-HH Price: $0.89 |
| 4 |
777-8680 |
Label, Inflation Price: Call Us |
| 5 |
85-8300-03 |
PUMP LEVER ASM This part replaces 85-8300. Price: $116.03 |
| 5 |
941-3002 |
FRONT WHEEL BEARING ASSEMBLY Not Available This part replaces 741-3002. Price: |
| 6 |
32105-21 |
SCREW-HH Price: $1.09 |
| 6 |
931-3020 |
Hubcap This part replaces 731-3020. Price: $7.77 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
736-0179 |
Washer, Flat, .531 x 1.25 x .100 Thk Price: $4.02 |
| 8 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 8 |
588543701 |
TRIMMER GUARD 323L MFL. This part replaces 503977101. Price: $39.99 |
| 8 |
736-3095 |
Washer, Flat, .535 x 1.92 x .060 Thk Price: $6.01 |
| 9 |
93-9051 |
DECAL-BOLT, ECCENTRIC Price: $16.37 |
| 10 |
95-0553 |
DISCONTINUED Price: $39.13 |
| 11 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 11 |
588117901 |
COMBINATION GUARD This part replaces 503934202. Price: $19.99 |
| 12 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 13 |
85-9030 |
SPRING-EXTENSION Price: $45.40 |
| 14 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 15 |
85-8460 |
SWITCH ARM ASM Price: $109.84 |
| 16 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 17 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 18 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 19 |
322-8 |
SCREW-HH Price: $1.26 |
| 20 |
251-259 |
BEARING-BALL This part replaces 251-307. Price: $13.67 |
| 21 |
85-9120 |
SPACER-PIVOT, TILT Price: $4.01 |
| 22 |
75-5470 |
SPACER-BEARING Price: $3.06 |
