| Ref | Part Number | Description |
|---|
| 1 |
77-5620-01 |
R/H DECK COVER This part replaces 77-5620. Price: $63.06 |
| 2 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 2 |
532007070 |
KEY 1/4 X 2.5 Price: $4.99 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 3 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 4 |
62-6520 |
KNOB Price: $7.79 |
| 5 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 5 |
77-5420-03 |
PULLEY ASM This part replaces 77-5420. Price: $186.20 |
| 6 |
59-5190 |
NUT-PULLEY Price: $126.34 |
| 6 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 7 |
127-1843 |
PLUG-DOME This part replaces 59-5310. Price: Call Us |
| 7 |
532140507 |
HUB ASMBLY Price: $149.99 |
| 8 |
80-3590 |
V-BELT Price: $54.22 |
| 9 |
56-4920 |
PULLEY-IDLER Price: $85.99 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
3256-38 |
WASHER-FLAT Price: $0.49 |
| 11 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 12 |
80-3250 |
SCREW-PIVOT Price: $95.39 |
| 13 |
257-10 |
WASHER-THRUST Price: $2.29 |
| 14 |
256-206 |
BUSHING Price: $1.15 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
80-3310 |
IDLER ARM ASM Price: $145.54 |
| 16 |
37-8880 |
SPRING-TRACTION Price: $16.99 |
| 17 |
532140921 |
SPRING.ROD.BRAKE Price: $3.99 |
| 17 |
80-3560 |
ROD-THREADED Price: $109.47 |
| 18 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 20 |
80-3570 |
HOOK Price: $22.15 |
| 20 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 22 |
321-4 |
SCREW-HH Price: $0.99 |
| 22 |
532156103 |
SHAFT ARM ASM Price: $37.99 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 25 |
77-5520 |
BRACKET WA - RH Price: $140.43 |
| 26 |
3290-451 |
WASHER-BELLEVILLE Price: $0.25 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
257-9 |
WASHER-THRUST Price: $3.29 |
| 29 |
532140494 |
BRAKE ROD Price: $10.99 |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 30 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 31 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 32 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 33 |
77-5560 |
BRACKET-LH Price: $185.21 |
| 33 |
812000053 |
E RING HYT Price: $3.99 |
| 34 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 34 |
77-5600-01 |
SUPPORT COVER ASM This part replaces 77-5600. Price: $23.98 |
| 35 |
32153-1 |
NUT-LOCK, SIDE This part replaces 32146-18. Price: $0.27 |
| 35 |
532137648 |
PARKING BRAKE ROD Price: $9.99 |
| 36 |
532149412 |
SPRING DRIVE GROUND Price: $4.99 |
| 36 |
80-3550 |
DEFLECTOR STOP *B Price: $19.02 |
| 37 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
532150035 |
NYLINER Price: $3.99 |
| 38 |
80-3450-03 |
BRACKET This part replaces 80-3450. Price: $57.46 |
| 39 |
80-3230 |
PIN - SPECIAL Price: $71.87 |
| 39 |
874321016 |
Screw Fin #10-24 x 1 Price: $2.99 |
| 40 |
532178575 |
ACTUATOR INTERLOCK SWITCH This part replaces 532005304. Price: $3.99 |
| 40 |
80-3440 |
SHAFT Price: $56.26 |
| 41 |
80-3200 |
PIN Price: $39.98 |
| 41 |
873931000 |
Nut Toplock #10-24 Unc Price: $4.99 |
| 42 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 44 |
80-3580 |
DISCONTINUED Price: Call Us |
| 45 |
77-6940-03 |
BUMPER ASM This part replaces 77-6940. Price: $367.04 |
| 46 |
3290-134 |
SCREW Price: $0.27 |
| 46 |
532145170 |
RETAINER SPRING Price: $3.99 |
| 47 |
323-19 |
SCREW-HH Price: $1.70 |
| 47 |
532138228 |
CLUTCH ROD Price: $6.99 |
| 48 |
322-3 |
SCREW-HH Price: $0.79 |
| 48 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 49 |
56-4810-03 |
PULLEY ASM This part replaces 56-4810. Price: $229.99 |
| 50 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 51 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 52 |
532139123 |
PULLEY.IDLER.V. Price: $32.99 |
| 53 |
532000207 |
WASHER T Price: $4.99 |
| 54 |
532161590 |
CLUTCH.ARM.ASM.IDLER.98 Price: $18.99 |
| 55 |
532105706 |
BEARING LT (2 2) Price: $5.99 |
| 56 |
532140218 |
V-BELT. Price: $49.99 |
| 61 |
532140488 |
PULLEY Price: $37.99 |
| 64 |
532154752 |
SHAFT CLUTCH/BRAKE PEDAL Price: $39.99 |
| 65 |
532067609 |
AXLE BOLT Price: $7.99 |
| 66 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 67 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 68 |
532005142 |
ROLL PIN STD Price: $3.99 |
| 69 |
532123800 |
WASHER Price: $3.99 |
| 70 |
532164892 |
FENDER CONSOLE This part replaces 532166624. Price: $16.99 |
| 71 |
532151179 |
PLATE CONSOLE SHIFT Price: $2.99 |
| 72 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 73 |
874490548 |
BOLT HEX FLGHD 5/16-18X3 GR. 5 Price: $4.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 76 |
532140481 |
BRACKET TRANSAXLE Price: $5.99 |
| 77 |
596238601 |
Bolts This part replaces 874760716. Price: $2.99 |
| 79 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 80 |
532140484 |
TORQUE BRACKET RH Price: $2.99 |
| 81 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 82 |
532154561 |
KIT.BRAKET/HDW.MOUNT.HYDRO This part replaces 532150586. Price: $14.99 |
| 83 |
532140479 |
STRAP TORQUE MID Price: $5.99 |
| 84 |
532140490 |
SPACER Price: $5.99 |
| 85 |
817541020 |
Screw #10-24 x 1-1/4 Price: $3.99 |
| 86 |
532140462 |
FAN 7" HYDRO Price: $9.99 |
| 87 |
532140491 |
ADAPTOR.FAN.TRANSAXLE.VGTH Price: $7.99 |
| 88 |
532161592 |
PULLEY Price: $29.99 |
| 89 |
873680700 |
Nut, Crownlock 7/16-14 Price: $2.99 |
| 90 |
532140489 |
KEEPER.BELT Price: $6.99 |
| 91 |
596564005 |
BOLT This part replaces 817490644. Price: $8.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 93 |
532140502 |
LINK ASM SHIFT Price: $52.99 |
| 94 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 96 |
532141103 |
WASHER Price: $3.99 |
| 98 |
532141004 |
SHIFT BRACKET Price: $3.99 |
| 99 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 100 |
532126881 |
WASHER Price: $3.99 |
| 101 |
532156106 |
WASHER BELLVILLE Price: $2.38 |
| 104 |
532140480 |
BRACKET IDLER Price: $3.99 |
| 105 |
596437001 |
Screws This part replaces 817580408. Price: $2.99 |
| 106 |
532142918 |
O-RING KIT 70110 Price: $22.99 |
| 107 |
532154739 |
LINE.VENT.HYDRO-GEAR Price: $4.99 |
| 108 |
532142578 |
VENT CAP 70109 This part replaces 532142917. Price: $37.99 |
| 109 |
532140929 |
RETURN SPRING Price: $14.99 |
| 111 |
532156240 |
SPACER SHIFT LEVER VGTH Price: $2.99 |
| 112 |
532178558 |
WASHER NYLON HIGH TEMP This part replaces 532156104. Price: $4.99 |
| 113 |
873220700 |
NUT Price: $2.99 |
| 115 |
532156109 |
BELT KEEPER KIT This part replaces 532123405. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 117 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
