| Ref | Part Number | Description |
|---|
| 1 |
52-038-04 |
DIPSTICK, BLADE Price: Call Us |
| 1 |
757-3005 |
SEAT Not Available Price: |
| 1 |
94-7205 |
DISCONTINUED Price: Call Us |
| 2 |
52-123-09 |
TUBE, OIL LEVEL Price: Call Us |
| 2 |
94-7213 |
PIN-PIVOT Price: $8.27 |
| 2 |
MA-19633404AG1 |
BRACKET Not Available Price: |
| 3 |
94-7206 |
DISCONTINUED Price: Call Us |
| 3 |
MA-19633409AG1 |
BRACKET SEAT Not Available Price: |
| 3 |
X-67-64 |
SCREW Price: Call Us |
| 4 |
52-154-01 |
CLIP, TUBE Price: Call Us |
| 4 |
94-7207 |
LID Price: $73.08 |
| 4 |
MA-19633411000 |
PIN Not Available Price: |
| 5 |
52-173-01 |
CAP, PIPE Price: Call Us |
| 5 |
94-7208 |
GASKET Price: $31.57 |
| 5 |
MA-07420100800 |
RING, SNAP Not Available Price: |
| 6 |
94-7211 |
RING Price: $59.47 |
| 6 |
MA-69509-16000 |
BOX,TOOL Not Available Price: |
| 7 |
94-7209 |
PLUNGER Price: $5.80 |
| 7 |
MA-H1540108020 |
BOLT,W/WASHER Not Available Price: |
| 8 |
94-7210 |
BODY Price: $10.89 |
| 8 |
MA-19633417000 |
RUBBER Not Available Price: |
| 9 |
712-3077 |
HEX NUT M8X1.25 GR8.8 Not Available This part replaces 712-3097. Price: |
| 9 |
94-7212 |
NUT Price: $10.72 |
| 10 |
MA-03500160826 |
WASHER Not Available Price: |
| 11 |
MA-19633415AG0 |
SPRING Not Available This part replaces MA-19633415000. Price: |
| 12 |
703-2641 |
SEAT SLIDE ADJUSTMENT TRACK Not Available Price: |
| 13 |
703-2640 |
SEAT SLIDE TRACK Not Available Price: |
| 14 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 15 |
MA-19643408AG0 |
SUPPORT Not Available Price: |
| 16 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 17 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 18 |
MA-F3010108001 |
NUT Not Available Price: |
| 20 |
MA-H1540108025 |
BOLT,W/WASHER Not Available Price: |
| 21 |
MA-11930439000 |
GROMMET Not Available Price: |
