| Ref | Part Number | Description |
|---|
| 1 |
174619 |
Chassis Price: Call Us |
| 1 |
99-1644 |
DASH SHROUD ASM Price: $365.54 |
| 2 |
176554 |
Drawbar Price: Call Us |
| 2 |
92-8997 |
COOLER-OIL Price: $512.86 |
| 3 |
17060612 |
Screw 3/8-16 X .75 Price: Call Us |
| 3 |
85-9550 |
RUBBER CLAMP ASM Price: $5.56 |
| 4 |
85-9670 |
NUT-T Price: $1.63 |
| 5 |
155272 |
Bumper Hood/Dash Price: Call Us |
| 5 |
AU218-5106 |
FITTING-ELB 90 This part replaces 353-371. Price: $10.29 |
| 6 |
95-0643 |
TUBE-VALVE TO COOLER Price: $45.04 |
| 8 |
767148 |
FILTER CONVERSION KIT This part replaces 95-0610. Price: $112.49 |
| 9 |
168337X012 |
Dash P/L Price: Call Us |
| 9 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
72140608 |
Bolt Carriage 3/8-16 x 1 Price: Call Us |
| 11 |
174996 |
Panel Dash Lh Price: Call Us |
| 11 |
322-14 |
SCREW-HH Price: $1.01 |
| 12 |
145660 |
Clip Tinnerman Price: Call Us |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
172105X010 |
Panel Dash Rh Price: Call Us |
| 13 |
92-7159 |
TREAD-FLOOR, LH Price: $26.24 |
| 14 |
17490608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 14 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 15 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 16 |
95-5807 |
SPACER Price: $10.10 |
| 17 |
159639X428 |
Hood LT/PL Price: Call Us |
| 17 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 18 |
126938X |
Bumper Hood Price: Call Us |
| 18 |
322-2 |
SCREW-HH Price: $0.69 |
| 19 |
95-0620-01 |
STRIP-RETAINER Price: $12.71 |
| 20 |
180679 |
Plate Mtg Battery Fuel Tank Price: Call Us |
| 20 |
95-5826 |
SHIELD-RUBBER Price: $40.16 |
| 21 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 22 |
95-0582 |
HOSE-INTAKE, AIR Price: $61.51 |
| 23 |
124028X |
Bushing Price: Call Us |
| 23 |
95-5805 |
AIR CLEANER ASM Price: $140.44 |
| 24 |
74780616 |
Bolt Fin Hex 3/8-16 x 1 Gr 5 Price: Call Us |
| 24 |
95-5806 |
BRACKET-MOUNTING Price: $28.01 |
| 25 |
19131312 |
Washer 13/32 X 13/16 X 12 Ga Price: Call Us |
| 25 |
92-7158 |
TREAD-FLOOR, RH Price: $26.24 |
| 26 |
73800600 |
Nut Lock Hex W/Ins 3/8-16 Unc Price: Call Us |
| 26 |
95-5817 |
FRONT SHIELD ASM Price: $354.47 |
| 27 |
95-0607 |
DISCONTINUED Price: Call Us |
| 28 |
179844 |
Grille/Lens Asm Price: Call Us |
| 28 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 29 |
170472X599 |
Lens LT/PL Price: Call Us |
| 29 |
95-5828 |
STRIP-WEAR Price: $2.51 |
| 30 |
169470X428 |
Fender Footrest STLT Pnt Price: Call Us |
| 30 |
94-4519 |
TUBE-CONVOLUTE Price: $2.24 |
| 31 |
136619 |
Bracket Fender Price: Call Us |
| 31 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
95-7861 |
DECAL-INFIELD, PRO 3020 Price: Call Us |
| 33 |
179716X428 |
Footrest Pnt Lh Price: Call Us |
| 34 |
179717X428 |
Footrest Pnt Rh Price: Call Us |
| 35 |
72110606 |
Bolt Rdhd Sht Sqnk 3/8-16 x 3/4 Price: Call Us |
| 37 |
17490508 |
Screw Thdrol 6/16-18 x 1/2 TYT Price: Call Us |
| 38 |
175710 |
Bracket Asm Pivot Mower Rear Price: Call Us |
| 51 |
73800400 |
Nut Lock Hex W/Ins 1/4-20 Price: Call Us |
| 52 |
19091416 |
Washer 9/32 x 7/8 x 16 Ga. Price: Call Us |
| 53 |
144697 |
Bracjet Grukke Lh Price: Call Us |
| 54 |
161464 |
Screw Hex Wshd 8-18 x 7/8 Price: Call Us |
| 55 |
144696 |
Bracket Grille Rh Price: Call Us |
| 57 |
74780412 |
Bolt Hex 1/4-20 x 3/4 Price: Call Us |
| 58 |
174930 |
Duct Air Price: Call Us |
| 64 |
154798 |
Dash Lower STLT Price: Call Us |
| 142 |
175702 |
Plate Reinforcement STLT Price: Call Us |
| 145 |
156524 |
Rod Pivot Chassis/Hood Price: Call Us |
| 159 |
169473X428 |
Cupholder Price: Call Us |
| 206 |
170165 |
Bolt Shoulder 5/16-18 Price: Call Us |
| 207 |
17670508 |
Screw Thdrol 5/16-18 x 1/2 Price: Call Us |
| 208 |
17670608 |
Screw Thdrol 3/8-16 x 1/2 Price: Call Us |
| 212 |
156229 |
Insert Lens Relect Price: Call Us |
| 219 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
