| Ref | Part Number | Description |
|---|
| 1 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 2 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
74-4980 |
SHROUD-TOP Price: $112.09 |
| 4 |
76-8750 |
PLATE-WARNING Price: $9.67 |
| 5 |
3290-271 |
RIVET-POP Price: $0.25 |
| 6 |
74-3410 |
RADIATOR ASM Price: $2,099.35 |
| 7 |
32148-10 |
NUT-CLINCH Price: $1.29 |
| 8 |
93-7799 |
RADIATOR MTG ASM Price: $970.73 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
94-5616 |
SEAL-HOOD Price: $46.12 |
| 10 |
94-5621 |
DISCONTINUED Price: Call Us |
| 11 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532400008. Price: $329.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
94-5622 |
SEAL-STRIP, SCREEN Price: $98.66 |
| 13 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 14 |
114-3995 |
OIL COOLER ASM This part replaces 82-3740. Price: $1,388.56 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
532422804 |
TANK FUEL Price: $149.99 |
| 15 |
94-5612-03 |
SCREEN ASM This part replaces 94-5612. Price: $2,248.01 |
| 16 |
27-4570 |
KNOB-SEAT Price: $25.38 |
| 17 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 18 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 19 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 20 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
94-8010 |
HOSE ASM Price: $148.03 |
| 22 |
237-65 |
O-RING Price: $2.50 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
37-8771 |
BOLT-SHOULDER,HFH Price: $3.59 |
| 24 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 25 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 26 |
32128-20 |
NUT-HF Price: $0.99 |
| 27 |
93-7244-03 |
BRACKET-SUPPORT This part replaces 93-7244. Price: $21.16 |
| 28 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
322-4 |
SCREW-HH Price: $0.35 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 31 |
74-6400 |
FILTER LINE TUBE ASM Price: $97.62 |
| 32 |
94-8298 |
OIL COOLER TUBE ASM Price: $115.67 |
| 33 |
325-34 |
SCREW-HH Price: $2.37 |
| 34 |
88-1360 |
WASHER-WEIGHT, REAR Price: $35.05 |
| 35 |
92-9711-03 |
WEIGHT-REAR This part replaces 92-9711. Price: $2,626.70 |
| 36 |
76-6381 |
STRIP-SEALING, RADIATOR Price: $4.29 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
76-6382 |
STRIP-SEALING, FAN SHROUD Price: $4.22 |
| 38 |
304-46 |
DRAINCOCK Price: $7.55 |
| 39 |
2811-1 |
ELBOW-STREET, 45 DEG Price: $21.35 |
| 40 |
92-7781-03 |
WEIGHT ASM - REAR This part replaces 92-7781. Price: $602.77 |
| 41 |
325-35 |
SCREW-HH Price: $2.37 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
74-5460-03 |
ANGLE-SUPPORT, RADIATOR This part replaces 74-5460. Price: $65.15 |
| 43 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 44 |
32128-49 |
NUT-HHF Price: $1.04 |
| 45 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
94-1418 |
HOSE-RADIATOR, UPPER Price: $48.18 |
| 47 |
74-6020 |
HOSE-RADIATOR, LOWER Price: $48.93 |
| 48 |
74-4990 |
DISCONTINUED Price: Call Us |
| 49 |
322-3 |
SCREW-HH Price: $0.79 |
| 50 |
94-5625 |
HOSE Price: $13.26 |
| 51 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 This part replaces 532424765. Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 This part replaces 532424766. Price: $24.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
