| Ref | Part Number | Description |
|---|
| 1 |
117-5141 |
HYD MOTOR ASM Price: $686.31 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 5 |
105-1216 |
HOSE-HYD Price: $214.79 |
| 6 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 7 |
105-1215 |
HOSE-HYD Price: $224.84 |
| 8 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 9 |
104-1080 |
HOSE-HYD Price: $121.86 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
100-4876 |
HOSE-HYD Price: $118.57 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 11 |
99-3477 |
FITTING-TEE Price: $47.71 |
| 12 |
100-4880 |
HOSE-HYD Price: $250.85 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $54.99 |
| 13 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 17 |
112-9901-03 |
GUARD-FOOT, RH Price: $62.73 |
| 18 |
112-9902-03 |
GUARD-FOOT, LH Price: $62.73 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
112-9900-03 |
GUARD-FOOT Price: $82.81 |
| 20 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 21 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 22 |
323-52 |
SCREW-HH Price: $3.63 |
| 23 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 24 |
95-8803 |
BUSHING-FLANGE Price: $2.43 |
| 25 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 64 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 99 |
532194329 |
SHIELD.BROWNING/DEBRIS Price: $17.99 |
