| Ref | Part Number | Description |
|---|
| 1 |
110-4468 |
COVER-FRONT, RH Price: $308.77 |
| 2 |
110-4466 |
SHIELD-PULLEY, RH Price: $264.26 |
| 2 |
580292901 |
SCREW ITXSCT PW4.2X18 10.9 ZN Price: $2.99 |
| 3 |
110-4683 |
YOKE COVER ASM Price: $492.91 |
| 4 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 5 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 6 |
110-4697 |
MOUNT-ISOLATED Price: $10.36 |
| 8 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 8 |
531293601 |
THROTTLE LOCKOUT ASSEMBLY DISS This part replaces 598721501. Price: $7.99 |
| 9 |
110-4478 |
SUPPORT-COVER, FRONT Price: $14.38 |
| 9 |
593044302 |
THROTTLE CONTROL ASSEMBLY This part replaces 593044301. Price: $7.99 |
| 10 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
593165501 |
HANDLE HALF RIGHT Price: $11.99 |
| 12 |
105-1069 |
SHIELD-SIDE Price: $110.46 |
| 12 |
580292901 |
SCREW ITXSCT PW4.2X18 10.9 ZN Price: $2.99 |
| 13 |
525755109 |
SCREW Price: $3.99 |
| 14 |
593838601 |
SPRING THROTTLE CONTROL Price: $3.99 |
| 15 |
110-4680 |
RH SHIELD SUPPORT ASM Price: $94.28 |
| 16 |
32144-109 |
SCREW-THD Price: $1.29 |
| 16 |
503221012 |
NUT Price: $2.99 |
| 17 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 17 |
593624001 |
HANDLES Price: $59.99 |
| 18 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 18 |
537172803 |
HANDLE Price: $8.99 |
| 19 |
2412-120 |
CLAMP-R Price: $6.49 |
| 19 |
503200784 |
SCREW IHSCFM M5X45 10.9 ZN/FE This part replaces 525755106. Price: $2.99 |
| 20 |
731231401 |
NUT Price: $1.99 |
| 21 |
537172902 |
BRACKET Price: $4.99 |
| 22 |
114439 |
RIVET-BLIND Price: $0.69 |
| 22 |
725238381 |
SCREW Price: $4.99 |
| 23 |
502203801 |
HANDLE Price: $5.99 |
| 25 |
502282101 |
WASHER Price: $2.99 |
| 26 |
593054301 |
HANDLES Price: $24.99 |
| 27 |
596283303 |
NEEDS DESCRIPTION Price: $24.99 |
