| Ref | Part Number | Description |
|---|
| 1 |
182032X |
Mower Deck Assembly, 42" Price: Call Us |
| 2 |
72140506 |
Bolt Price: Call Us |
| 3 |
138017 |
Bracket Asm Fr. Sway Bar 3/42 Price: Call Us |
| 4 |
165460 |
Bracket Asm Deck 42" Sway Bar Price: Call Us |
| 5 |
4939M |
Retainer Spring Price: Call Us |
| 6 |
178024 |
Bar Sway Deck Price: Call Us |
| 8 |
850857 |
Bolt 3/8-24 x 1.25 Gr. 8 patched Price: Call Us |
| 9 |
10030600 |
Washer, Lock Price: Call Us |
| 10 |
140296 |
Washer, Hardened Price: Call Us |
| 13 |
137645 |
Shaft Assembly, Mandrel, Vented Price: Call Us |
| 14 |
128774 |
Housing, Mandrel, Vented Price: Call Us |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 16 |
174493 |
Stripper, Mandrel Deck Price: Call Us |
| 18 |
72140505 |
Bolt, Carriage 5/16-18 x 5/8 Price: Call Us |
| 19 |
132827 |
Bolt, Shoulder Price: Call Us |
| 20 |
159770 |
Baffle, Vortex Price: Call Us |
| 21 |
73680500 |
Nut Price: Call Us |
| 23 |
177563 |
Bracket, Deflector Mower 42" Price: Call Us |
| 24 |
105304X |
Cap, Sleeve 80 x 112 Blk Mower Price: Call Us |
| 25 |
123713X |
Spring, Torsion, Deflector 2 52 Price: Call Us |
| 26 |
110452X |
Nut, Push Phos & Oil Price: Call Us |
| 27 |
130968X428 |
Shield, Deflector 42" Blk Price: Call Us |
| 28 |
19111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: Call Us |
| 29 |
131491 |
Rod, Hinge 42" 6 75 W/G Price: Call Us |
| 30 |
173984 |
Screw Thdrol Price: Call Us |
| 31 |
187690 |
Washer, Spacer Mower Vented Price: Call Us |
| 32 |
153535 |
Pulley, Mandrel Price: Call Us |
| 33 |
178342 |
Nut, Toplock Price: Call Us |
| 34 |
72110612 |
Bolt Carr SH 3/8-16 x 1-1/2 Gr.5 Price: Call Us |
| 36 |
131494 |
Pulley, Idler, Flat Price: Call Us |
| 40 |
73900600 |
Nut Lock 3/8-16 Price: Call Us |
| 44 |
140088 |
Guard, Mandrel, LH Price: Call Us |
| 45 |
4497H |
Retainer Price: Call Us |
| 46 |
137729 |
Screw, Thdrol 1/4-20 x 5/8 T Price: Call Us |
| 54 |
178515 |
Washer, Hardened Price: Call Us |
| 55 |
155046 |
Arm, Idler Price: Call Us |
| 56 |
165723 |
Spacer, Retainer Price: Call Us |
| 59 |
141043 |
Guard TUV Idler Price: Call Us |
| 61 |
174882 |
Spring Ext Elect. Clutch Price: Call Us |
| 92 |
73800600 |
Nut Lock Hex w/Ins 3/8-16 unc Price: Call Us |
| 101 |
136420 |
Mulcher Cover Price: Call Us |
| 102 |
71081010 |
Screw, Pan Hd Phillip 10-24 x 5/8 Price: Call Us |
| 103 |
19061216 |
Washer, Flat Price: Call Us |
| 104 |
10071000 |
Washer, Lock Price: Call Us |
| 105 |
160793 |
Latch Assembly Price: Call Us |
| 106 |
2029J |
Nut, Weld Price: Call Us |
| 113 |
17000510 |
Bolt 5/16-18 Hex Wsh Hd Lock Price: Call Us |
| 116 |
4898H |
Bolt, Shoulder Price: Call Us |
| 117 |
188606 |
Wheel, Gauge Price: Call Us |
| 118 |
73930600 |
Nut Centerlock 3/8-16 Price: Call Us |
| 119 |
19121414 |
Washer 3/8 x 7/8 x 14 Ga. Price: Call Us |
| 129 |
19131312 |
Washer 13/32 x 13/16 x 12 Ga. Price: Call Us |
| 130 |
74780616 |
Bolt Fin HEx 3/8-16 unc x 1 Gr. 5 Price: Call Us |
| 131 |
72140608 |
Bolt RDHD SQNK 3/8-16 unc x 1 Price: Call Us |
| 134 |
156941 |
Pin Head Rivet Price: Call Us |
| 135 |
159765X |
Bracket Asm. Whl Ga. R LH Price: Call Us |
| 136 |
155986 |
Bar Adjusting Gauge Wheel Price: Call Us |
| 138 |
159763X |
Bracket Asm Whl Ga. R RH Price: Call Us |
| 139 |
159767X |
Bracket Asm. Whl Ga. F RH Price: Call Us |
| 140 |
159768X |
Bracket Asm Whl Ga. F LH Price: Call Us |
| 140 |
710-05315 |
BOLT M5 x 10 Not Available Price: |
| 141 |
951-12265 |
Cowl Price: $24.06 |
| 142 |
710-05316 |
Valve Cover Bolt Price: $3.56 |
| 143 |
157109 |
Bracket Arm Idler 42" Price: Call Us |
| 143 |
951-12266 |
Valve Cover Price: $23.04 |
| 144 |
158634 |
Keeper Belt 42" Clutch Cable Price: Call Us |
| 144 |
951-12267 |
Valve Cover Ring Price: $8.12 |
| 145 |
165888 |
Pulley Idler Flat Price: Call Us |
| 145 |
951-11981A |
ROCKER ARM ASSEMBLY This part replaces 951-11981. Price: $35.16 |
| 146 |
171977 |
Bolt Carriage Idler Price: Call Us |
| 146 |
751-11124 |
Jam Nut Price: $8.18 |
| 147 |
751-11123 |
Fulcrum Nut Price: $9.09 |
| 148 |
169022 |
Spring Return Idler Price: Call Us |
| 148 |
951-11966 |
Rocker Arm Price: $7.31 |
| 149 |
165898 |
Retainer Spring Yellow Price: Call Us |
| 149 |
710-04962 |
Rocker Arm Stud Price: $5.51 |
| 150 |
19091210 |
Washer 9/32 x 3/4 x 10 Ga. Price: Call Us |
| 150 |
951-12268 |
Push Rod Guide Price: $6.42 |
| 151 |
951-12269 |
Exhaust Valve Adjuster Price: $5.48 |
| 152 |
951-12080 |
Exhaust Valve Spring Retainer Price: $3.68 |
| 153 |
951-12078 |
Valve Spring Price: $3.49 |
| 154 |
951-11964A |
INTAKE VALVE SEAL This part replaces 951-11964. Price: $9.96 |
| 155 |
951-12077A |
VALVE SPRING RETAINER This part replaces 951-12077. Price: $3.49 |
| 157 |
951-11337 |
Valve Kit Price: $46.81 |
| 159 |
72140614 |
Bolt Rdhd Sqn 3/8-16 unc x 1-3/4 Price: Call Us |
| 162 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 163 |
710-05317 |
Bolt M10×1.25×85 Price: $5.59 |
| 164 |
710-05318 |
Bolt /M10×1.25×65 Price: $5.59 |
| 166 |
951-14460 |
Air Valve Core Price: $14.23 |
| 167 |
951-12775 |
Strainer Clip Price: $3.56 |
| 168 |
951-12776 |
Second Air Valve Filter Element Price: $3.49 |
| 169 |
951-12777 |
The Air Valve Bonnet Not Available Price: |
| 170 |
736-04629 |
Washer Price: $3.56 |
| 171 |
710-05337 |
Screw M5×12 Price: $3.65 |
| 172 |
951-12273 |
Cylinder Head Gasket Price: $42.37 |
| 173 |
715-04122 |
Cylinder Head Dowel 12×16 Price: $3.52 |
| 174 |
951-11335 |
Push Rod Kit Price: $21.93 |
| 175 |
951-11962A |
TAPPET This part replaces 951-11962. Price: $5.88 |
| 176 |
736-04561 |
Camshaft Thrust Washer Price: $3.52 |
| 177 |
951-12274 |
Camshaft Assembly Price: $91.34 |
| 184 |
19131410 |
Washer 13/32 x 7/8 x 10 Ga. Price: Call Us |
| 196 |
951-12197 |
Valve Cover Kit Price: $36.36 |
