| Ref | Part Number | Description |
|---|
| 0 |
632496 |
CARBURETOR Price: $79.78 |
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK Price: $22.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 1 |
98-0152 |
KNOB-TAPERED Price: $16.00 |
| 2 |
108-8485 |
DECAL-LIFT, FRONT Price: $29.62 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
108-7908-03 |
PANEL-CONTROL Price: $20.47 |
| 4 |
108-7944 |
FRONT LEVER ASM Price: $67.32 |
| 4 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $29.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
3290-477 |
WASHER-CURVED Price: $0.79 |
| 5 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 6 |
98-8159 |
PIVOT Price: $46.64 |
| 7 |
3290-360 |
SCREW-HH Price: $4.34 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
2710-20 |
LINK-OFFSET Price: $10.06 |
| 9 |
88-8480 |
BRACKET-PIVOT Price: $17.24 |
| 10 |
108-8453 |
HOSE ASM Price: $178.68 |
| 10 |
631919 |
SHAFT & LEV Price: $6.93 |
| 11 |
108-8454 |
HOSE ASM Price: $189.24 |
| 11 |
632042 |
SPRING Price: $3.00 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 13 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 15 |
108-8449 |
HOSE ASM Price: $120.90 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
108-7941 |
PLATE-GUIDE, LEVER Price: $17.50 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
32121-73 |
PIN-ROLL Price: $0.22 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
121-9070 |
VALVE ASM This part replaces 43-1710. Price: $458.43 |
| 20 |
108-6857 |
PLATE-VALVE Price: $11.33 |
| 20 |
631838 |
ADJ SCREW Price: $2.71 |
| 21 |
108-8447 |
TUBE ASM Price: $64.72 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
110-3328 |
WIRE ASM Price: $103.58 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 23 |
532169837 |
SHIELD.BROWNING.DBR.GUARD Price: $7.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
32151-29 |
RING-RETAINING Price: $3.59 |
| 25 |
114-0626 |
HYD CYLINDER ASM Price: $422.82 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 26 |
110-8189 |
PIN-PLAIN Price: $14.99 |
| 27 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 31 |
581289901 |
FUEL.TANK.ASM.1.5.GAL.NON-EPA This part replaces 532407545. Price: $54.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $14.99 |
| 33 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 37 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 40 |
31839 |
POWER SCREW Price: $10.89 |
| 40 |
532124028 |
GROMMET T Price: $3.99 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 46 |
819091416 |
WASHER Price: $3.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 72 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 78 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 81 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
