| Ref | Part Number | Description |
|---|
| 1 |
106-8085 |
SUSPENSION ASM Price: $723.03 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
104086X475 |
SHIELD.SIDE.OUTLH Price: Call Us |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
106-1031 |
TENSION ADJUSTER KNOB ASM Price: $68.93 |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 5 |
72110508 |
BOLT CRT Price: Call Us |
| 6 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
76-2940 |
BUMPER Price: $9.73 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 9 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 10 |
108-6702 |
ADJUSTER-SEAT, W/HANDLE This part replaces 66-8510. Price: $239.09 |
| 10 |
72140506 |
BOLT Price: Call Us |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 11 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 13 |
32128-25 |
NUT-HF Price: $3.19 |
| 13 |
72110510 |
BOLT Price: Call Us |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 15 |
104101X475 |
SHIELD.SIDE.OUTRH Price: Call Us |
| 15 |
93-3163 |
SPRING Price: $26.01 |
| 16 |
73220400 |
SUB= 50675 Price: Call Us |
| 17 |
10040400 |
LOCKWASHER Price: Call Us |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 28 |
120588X |
PIN HINGE Price: Call Us |
