| Ref | Part Number | Description |
|---|
| 1 |
182516X007 |
Bar, Weight Price: Call Us |
| 2 |
166785 |
Nut, Hex Price: Call Us |
| 3 |
72110510 |
Bolt, Carriage Price: Call Us |
| 4 |
191079 |
Pulley, Impeller Price: Call Us |
| 5 |
188909 |
Bearing Assembly, Flange Price: Call Us |
| 6 |
155377 |
Nut, Hex Flange 5/16-18 Price: Call Us |
| 7 |
180355 |
Bolt, Flat Head, Carriage 5/16-18 x 5/8 Price: Call Us |
| 8 |
72270505 |
Bolt, Carriage 5/16-18 x 5/8 Price: Call Us |
| 9 |
178820 |
Nut, Cage 3/8-16 Price: Call Us |
| 10 |
108-1402 |
GEAR CASE ASM Price: $859.88 |
| 10 |
178827X428 |
Housing, Auger Price: Call Us |
| 11 |
178691X479 |
Bar, Scraper Price: Call Us |
| 12 |
178675X008 |
Bracket, Corner Discharge Price: Call Us |
| 13 |
175322 |
Base, Discharge Chute Price: Call Us |
| 14 |
19111507 |
Washer, Flat Price: Call Us |
| 15 |
10040500 |
Washer, Lock 5/16 Price: Call Us |
| 16 |
74950512 |
Screw, Hex Head 5/16-18 x 3/4 Price: Call Us |
| 18 |
179582 |
Screw, Hex Head 5/16 x 1 Price: Call Us |
| 19 |
73800400 |
Nut, Hex Lock 1/4-20 Price: Call Us |
| 20 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 20 |
73800500 |
Nut, Hex Lock 5/16-18 Price: Call Us |
| 21 |
155415 |
Washer, Flat 5/16 Price: Call Us |
| 22 |
178777X479 |
Skid Plate, RH Price: Call Us |
| 23 |
108-3841 |
FILTER-OIL This part replaces 104-5167. Price: $10.81 |
| 23 |
179246 |
Washer, Nylon, Friction Price: Call Us |
| 24 |
72270506 |
Bolt, Carriage 5/16-18 x 3/4 Price: Call Us |
| 25 |
185600 |
Bolt, Shoulder 1/4-20 Price: Call Us |
| 26 |
174658 |
Bearing, Auger Price: Call Us |
| 27 |
174697 |
Washer, Thrust, 1" Price: Call Us |
| 28 |
192090 |
Bolt, Shear Price: Call Us |
| 29 |
174762X479 |
Skid Plate, LH Price: Call Us |
| 30 |
192125X479 |
Auger Assembly, RH Price: Call Us |
| 30 |
98-7487 |
PLUG Price: $3.18 |
| 31 |
192123X479 |
Auger Assembly, LH Price: Call Us |
| 32 |
174699 |
O-Ring Price: Call Us |
| 33 |
174700 |
Bushing, Flange 3/4 Price: Call Us |
| 34 |
174681 |
Washer, Thrust 3/4 Price: Call Us |
| 35 |
174684 |
Bearing, Thrust 3/4 Price: Call Us |
| 36 |
174660 |
Shaft, Impeller Price: Call Us |
| 37 |
174683 |
Washer, Thrust 5/8 Price: Call Us |
| 38 |
174686 |
Bushing, Flange 5/8 Price: Call Us |
| 39 |
150078 |
Screw, Hex Head 5/16-18 x 3/4 Price: Call Us |
| 40 |
86447 |
Plug, Case Price: Call Us |
| 41 |
174688 |
Housing, Gearbox, RH Price: Call Us |
| 42 |
174698 |
Seal, Oil Price: Call Us |
| 43 |
174701 |
Bushing, Flange, 1" Price: Call Us |
| 44 |
189282 |
Key, Square 1/4 x 1/4 x 7/8 Price: Call Us |
| 45 |
174659 |
Gear, Worm Price: Call Us |
| 46 |
174657 |
Shaft, Auger Price: Call Us |
| 47 |
174687 |
Housing, Gearbox, LH Price: Call Us |
| 48 |
175321X479 |
Impeller Assembly Price: Call Us |
| 49 |
74780426 |
Screw, Hex Head 1/4-20 x 1-5/8 Price: Call Us |
| 50 |
175311 |
Gasket, Gearbox Price: Call Us |
| 50 |
98-9544 |
SPRING Price: $0.94 |
| 51 |
7836M |
Pin, Roll 3/16 x 1-1/8 Price: Call Us |
| 52 |
181160X479 |
Bar, Drift Cutter Price: Call Us |
| 54 |
53847 |
Washer, Flat 1/4 Price: Call Us |
| 60 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 70 |
98-9380 |
BALL Price: $0.84 |
| 80 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 85 |
107-9069 |
COVER-PUMP, OIL Price: $27.77 |
| 90 |
107-9071 |
SCREW Price: $0.36 |
| 100 |
107-9072 |
PIN-STRAIGHT Price: $0.28 |
| 110 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 120 |
100-1765 |
BOLT This part replaces 107-9073. Price: $1.59 |
| 130 |
105-3797 |
BOLT Price: $1.40 |
| 140 |
98-9356 |
BOLT Price: $2.06 |
| 150 |
107-9074 |
BOLT Price: $1.43 |
| 160 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 170 |
105-3709 |
STUD Price: $1.13 |
| 180 |
98-7572 |
NUT Price: $0.32 |
| 190 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 200 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 210 |
105-3710 |
STUD Price: $1.16 |
