| Ref | Part Number | Description |
|---|
| 1 |
38-6710 |
DISCONTINUED This part replaces 27-2070. Price: Call Us |
| 2 |
27-3100 |
SPLASH SHIELD Price: $101.97 |
| 3 |
27-2060 |
REAR UNIT RETURN HOSE Price: $50.97 |
| 3 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873710700. Price: $3.99 |
| 4 |
27-2080 |
DISCONTINUED Price: Call Us |
| 5 |
10-7490 |
DISCONTINUED Price: Call Us |
| 6 |
47-4840 |
HYD HOSE ASM This part replaces 27-2010. Price: $124.46 |
| 7 |
27-2100 |
DISCONTINUED Price: Call Us |
| 7 |
532175689 |
TRUNNION This part replaces 532106308. Price: $2.99 |
| 8 |
7-3123 |
DISCONTINUED Price: Call Us |
| 9 |
237-80 |
O-RING Price: $6.10 |
| 9 |
819292016 |
Washer (AYP part number) Price: $3.99 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 10 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 874780624. Price: $3.99 |
| 11 |
47-4850 |
HYD HOSE ASM This part replaces 27-2020. Price: $121.00 |
| 11 |
812000037 |
Klip Ring (AYP part number) Price: $3.99 |
| 12 |
27-2090 |
DISCONTINUED Price: Call Us |
| 12 |
532121891 |
Lift Adjust Handle (AYP part number) Price: $3.99 |
| 13 |
47-4830 |
DISCONTINUED This part replaces 10-7700. Price: Call Us |
| 13 |
532110807 |
Special Nut (AYP part number) Price: $3.99 |
| 14 |
10-7500 |
DISCONTINUED Price: Call Us |
| 14 |
532110729 |
Lift Adjust Rod (AYP part number) Price: $18.99 |
| 15 |
27-2930 |
LH TRACTION LINE Price: $113.24 |
| 15 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 16 |
27-2030 |
DISCONTINUED X-REF Price: Call Us |
| 16 |
819131016 |
Washer (AYP part number) Price: $3.99 |
| 17 |
237-42 |
O-RING Price: $2.78 |
| 17 |
812000022 |
E-Ring (AYP part number) Price: $3.99 |
| 18 |
27-2000 |
DISCONTINUED X-REF Price: Call Us |
| 18 |
532121000 |
Lift Shaft (AYP part number) Price: $119.99 |
| 19 |
68-5880 |
HOSE-HYD This part replaces 28-2040. Price: $112.20 |
| 20 |
27-2920 |
RH TRACTION LINE Price: $107.92 |
| 20 |
873680600 |
Crownlock Nut Price: $1.99 |
| 21 |
27-2110 |
RH CYL DROP HOSE Price: $118.00 |
| 21 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532122364. Price: $5.99 |
| 22 |
10-7630 |
DISCONTINUED Price: Call Us |
| 22 |
532109413 |
Handle Grip (AYP part number) Price: $2.99 |
| 23 |
10-7670 |
LH FRT RETURN HOSE Price: $49.52 |
| 23 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 24 |
27-2950 |
LH CU PRESSURE LINE Price: $191.01 |
| 25 |
27-2940 |
DISCONTINUED Price: Call Us |
| 25 |
532110810 |
Stop Depth Trunnion Price: $14.99 |
| 26 |
27-2970 |
DISCONTINUED Price: Call Us |
| 26 |
819151216 |
Washer (AYP part number) Price: Call Us |
| 27 |
38-6730 |
DISCONTINUED This part replaces 10-7650. Price: Call Us |
| 27 |
532009135 |
Spring Retainer (AYP part number) Price: $2.99 |
| 28 |
10-7660 |
DISCONTINUED Price: Call Us |
| 28 |
532124670 |
Spring Retainer (AYP part number) Price: $5.99 |
| 29 |
33-0610 |
DISCONTINUED Price: Call Us |
| 29 |
532052160 |
Washer (AYP part number) This part replaces 819171516. Price: $3.99 |
| 30 |
532110448 |
Adjust Link Lift (AYP part number) Price: $7.99 |
| 31 |
532110029 |
Lift Link (AYP part number) Price: $3.45 |
| 32 |
872140606 |
Carriage Bolt 3/8-16 x 3/4 (AYP part number) Price: $3.99 |
| 34 |
532105864 |
Bracket Suspension (AYP part number) Price: $2.38 |
| 35 |
532121599 |
L.H. Arm Suspension (AYP part number) Price: $21.14 |
| 36 |
532105848 |
Shoulder Bolt (AYP part number) Price: $2.02 |
| 37 |
532121598 |
R.H. Arm Suspension (AYP part number) Price: $14.99 |
| 38 |
873350800 |
NUT.HEX.JAM.1/2-13 This part replaces 873220800. Price: $1.99 |
| 40 |
876020308 |
Cotter Pin (AYP part number) Price: $1.99 |
| 41 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 43 |
532121252 |
Mower Upstop (AYP part number) Price: $2.99 |
| 44 |
532108236 |
Switch Bracket (AYP part number) Price: $2.99 |
| 45 |
817021008 |
Tap Hex Screw (AYP part number) Price: $1.99 |
| 47 |
532121006 |
Lever Rod Assembly (AYP part number) Price: $19.99 |
| 49 |
532102727 |
Extension Spring (AYP part number) Price: $6.99 |
| 50 |
532110447 |
Lift Trunnion (AYP part number) Price: $9.99 |
| 51 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873360700. Price: $3.99 |
| 52 |
532004921 |
Retainer Spring (AYP part number) Price: $3.99 |
| 53 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 54 |
532110739 |
Spring Washer (AYP part number) Price: $2.99 |
