| Ref | Part Number | Description |
|---|
| 1 |
322-2 |
SCREW-HH Price: $0.69 |
| 1 |
532443425 |
AUGER.PLENUM.SINGLE.STAGE.GREY Price: $59.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
532443426 |
COVER.NON-DRIVE.SIDE.HUSQ.GRAY Price: $37.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 3 |
532443973 |
COVER.DRIVE.SIDE HUSQVARNA.SNO Price: $37.99 |
| 4 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 4 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 5 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 6 |
817411312 |
SCREW.HX.13X.750 Price: $4.99 |
| 7 |
51-0790 |
ADJUSTER-SEAT, LH Price: $127.92 |
| 7 |
532196688 |
CLIPS Price: $3.99 |
| 8 |
532442250 |
SCREW.PAN.HD.TORX.1/4-20X.750 Price: $3.99 |
| 8 |
83-1270 |
SEAT SUPPORT ASM Price: $350.78 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 9 |
532444262 |
SCREW.1/4-20.PAN.HEAD.TORX. Price: $3.99 |
| 10 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 10 |
580833501 |
PLATE.EXHAUST.SINGLE.STAGE.SNO Price: $3.99 |
| 11 |
68-5100 |
ROD-SEAT, PROP Price: $32.13 |
| 12 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 13 |
68-5310 |
CLIP-ROD, PROP Price: $6.35 |
| 14 |
321-3 |
SCREW-HH Price: $0.28 |
| 15 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 16 |
3284-3 |
PIN-GROOVED Price: $2.24 |
| 17 |
51-0350 |
PIN-SPRING, SEAT Price: $11.90 |
| 18 |
3-6685 |
SPRING Price: $10.99 |
| 19 |
43-9071 |
LIMIT SWITCH ASM Price: $182.60 |
| 20 |
218-461 |
NUT-HH Price: $2.50 |
| 21 |
49-5880 |
SHAFT-SUPPORT, SEAT Price: $17.88 |
| 22 |
83-1840-01 |
COVER-VALVE, RH Price: $27.61 |
| 23 |
3274-12 |
SCREW-HSH Price: $0.81 |
| 24 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 25 |
51-0780 |
SLIDER-SEAT Price: $116.02 |
| 26 |
104-4620 |
SEAT This part replaces 100-3187. Price: $273.15 |
| 27 |
93-6686 |
DECAL-OIL, HYD This part replaces 93-8067. Price: $7.01 |
| 28 |
94-8036 |
DECAL-SERVICE Price: $25.59 |
