| Ref | Part Number | Description |
|---|
| 1 |
115-5304 |
CAP-FUEL This part replaces 93-7170. Price: $26.87 |
| 1 |
539101714 |
SOLENOID Price: $22.99 |
| 2 |
105-8266 |
TANK-FUEL This part replaces 92-7189. Price: $466.98 |
| 2 |
596435501 |
Bolts This part replaces 539102335. Price: $3.99 |
| 3 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 3 |
539104415 |
KAW PIGTAIL Price: $27.99 |
| 4 |
539105382 |
FUEL LINE 30" This part replaces 539105281. Price: $11.99 |
| 4 |
63-8410 |
WASHER Price: $1.76 |
| 5 |
2412-41 |
CLAMP-R Price: $4.82 |
| 5 |
539106819 |
CLUTCH TIE DOWN Price: $36.99 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
539106880 |
CLUTCH-200 FT LB(RPLS 5218-102 Price: $449.99 |
| 7 |
3256-63 |
WASHER-FLAT Price: $0.25 |
| 7 |
539106957 |
SKID PLATE Price: $17.99 |
| 8 |
539106961 |
ENGINE SHROUD BRKT Price: $17.99 |
| 8 |
83-2200 |
NUT Price: $9.81 |
| 9 |
33113-012 |
SCREW-HH This part replaces 48-7610. Price: $0.71 |
| 9 |
539106962 |
SPACER Price: $50.99 |
| 10 |
2412-94 |
CLAMP Price: $2.31 |
| 10 |
539106992 |
PULLEY Price: $64.99 |
| 11 |
109-0275 |
HOSE-FUEL This part replaces 83-2041. Price: $12.99 |
| 11 |
596435701 |
Bolts This part replaces 539107271. Price: $2.99 |
| 12 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 12 |
539109867 |
DOUBLE TUBE CLAMP Price: $5.99 |
| 13 |
539912757 |
KEY, 1/4 SQ X 1 1/4 Price: $3.99 |
| 13 |
94-2690 |
FILTER-FUEL Price: $4.69 |
| 14 |
109-0304 |
HOSE-FUEL This part replaces 83-2040. Price: $1.99 |
| 14 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 15 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 15 |
83-1390 |
VALVE-SHUT-OFF, FUEL Price: $55.01 |
| 16 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 16 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 17 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 17 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 18 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 19 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 20 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 21 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 22 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 23 |
539105637 |
CLUTCH HARNESS Price: $22.99 |
