| Ref | Part Number | Description |
|---|
| 1 |
323-56 |
SCREW-HH Price: $2.18 |
| 2 |
67-9100 |
GASKET Price: $15.83 |
| 3 |
32120-8 |
RING-SNAP Price: $1.76 |
| 4 |
72-3750 |
BEARING-ROLLER Price: $180.02 |
| 5 |
67-9080 |
HOUSING-MOTOR Price: $1,756.34 |
| 6 |
46-8410 |
SHAFT-MOTOR Price: $968.23 |
| 8 |
166020 |
Rod Shift Fender Adjust Yt Price: Call Us |
| 8 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 9 |
179334 |
Clutch Ogura Price: Call Us |
| 9 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 10 |
110-6341 |
BEARING-ROLLER This part replaces 46-8400. Price: $41.33 |
| 10 |
76020416 |
Pin, Cotter 1/8 x 1 Price: Call Us |
| 11 |
25-2400 |
GASKET Price: $19.26 |
| 12 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 13 |
25-2410 |
VALVE ASM Price: $514.54 |
| 14 |
10040400 |
Washer Lock Hvy Helical Price: Call Us |
| 14 |
92-8918 |
SECTION-CENTER Price: $1,338.76 |
| 15 |
93-4132 |
O-RING Price: $6.84 |
| 16 |
73800500 |
Nut Lock Hx w/Ins. 5/16-18 Unc Price: Call Us |
| 17 |
126197X |
Washer 1-1/2 x 15/32 x .250 Price: Call Us |
| 17 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 18 |
25-2440 |
PLATE-VALVE, PUMP Price: $491.90 |
| 19 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 19 |
73800600 |
Nut, Lock Hex w/Ins. 3/8-16 Unc Price: Call Us |
| 20 |
173937 |
Bolt 7/16-20 x 4 Gr. 5-1.5 Price: Call Us |
| 20 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 21 |
140845 |
Knob Price: Call Us |
| 21 |
251-8 |
BEARING-BALL Price: $30.06 |
| 22 |
158274 |
Rod, Brake Price: Call Us |
| 22 |
25-2460 |
PLUG-HH Price: $37.38 |
| 23 |
178289 |
Bracket Anti Rotation Price: Call Us |
| 23 |
237-86 |
O-RING Price: $5.47 |
| 24 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 24 |
73350600 |
Nut, Hex Jam 3/8-16 Price: Call Us |
| 25 |
106888X |
Spring, Rod, Brake Price: Call Us |
| 25 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 26 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 27 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 27 |
76020412 |
Pin, Cotter 1/8 x 3/4 Price: Call Us |
| 28 |
175765 |
Rod, Brake, Park Price: Call Us |
| 28 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 29 |
71673 |
Cap, Brake Parking Black Price: Call Us |
| 30 |
123780X |
Bracket, Transaxle, L.H. Price: Call Us |
| 32 |
74780512 |
Bolt 5/16-18 Unc x 3/4 Price: Call Us |
| 33 |
72140608 |
Bolt 3/8-16 x 1 Price: Call Us |
| 34 |
175578 |
Shaft, Foot Pedal Price: Call Us |
| 35 |
120183X |
Bearing Nylon Price: Call Us |
| 36 |
19211616 |
Washer 21/32 x 1 x 16 Gauge Price: Call Us |
| 37 |
1572H |
Pin,Roll 3/16 x 1 Price: Call Us |
| 38 |
179114 |
Pulley Idler Composite Price: Call Us |
| 39 |
74760648 |
Bolt Rdhd 3/8-16 Unc x 3 Price: Call Us |
| 40 |
353-551 |
PLUG-HH Price: $18.48 |
| 41 |
175556 |
Keeper, Idler Price: Call Us |
| 41 |
83-7260 |
CONE-RELIEF, CHARGE Price: $50.57 |
| 42 |
19131312 |
Washer 13/32 x 13/16 x 12 Ga. Price: Call Us |
| 42 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 43 |
19111012 |
Bolt Shoulder 5/16-18 Unc Price: Call Us |
| 44 |
32151-75 |
RING-RETAINING Price: $2.51 |
| 45 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 46 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 47 |
127783 |
Pulley, Idler Price: Call Us |
| 48 |
154407 |
Bellcrank Clutch Grnd Drv Stl Price: Call Us |
| 49 |
123205X |
Retainer, Belt Price: Call Us |
| 49 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 50 |
119-2895 |
SPLINED SHAFT KIT This part replaces 67-8020. Price: $1,116.09 |
| 50 |
72110612 |
Bolt 3/8-16 x 1-1/2 Price: Call Us |
| 51 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 51 |
73680600 |
Nut, Crownlock 3/8-16 Price: Call Us |
| 52 |
145212 |
Nut Price: Call Us |
| 52 |
25-2610 |
SPRING-VALVE Price: $29.42 |
| 53 |
105710X |
Link, Clutch Price: Call Us |
| 53 |
88-8220 |
VALVE-BY PASS Price: $189.03 |
| 54 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 55 |
105709X |
Spring, Return, Clutch Price: Call Us |
| 55 |
237-22 |
O-RING Price: $2.43 |
| 57 |
161741 |
V-Belt, Drive Price: Call Us |
| 58 |
158278 |
Keeper, Belt, Transaxle, R.H. Price: Call Us |
| 59 |
169691 |
Keeper Belt Centerspan Price: Call Us |
| 60 |
67-9090 |
PLUG Price: $41.68 |
| 61 |
17120614 |
Screw 3/8-16 x .875 Price: Call Us |
| 62 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 62 |
8883R |
Cover, Foot Pedal Price: Call Us |
| 63 |
175684 |
Pulley, Engine Price: Call Us |
| 63 |
93-0312 |
WASHER-HARDENED Price: $0.78 |
| 64 |
99-5689 |
CHECK VALVE KIT Price: $83.29 |
| 65 |
10040700 |
Washer, Lock Hvy Hlcl Spr 7/16 Price: Call Us |
| 65 |
117-2700 |
HOUSING KIT This part replaces 54-7890. Price: $2,321.28 |
| 66 |
161488 |
Keeper Belt Engine F-proof Price: Call Us |
| 66 |
25-3190 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 69 |
142432 |
Screw Hex Wsh Hi-Lo 1/4-1/2 Unc Price: Call Us |
| 71 |
158283 |
Strap Torque Lh Hydro-3000 Price: Call Us |
| 73 |
158282 |
Strap Torque Rh Hydro-3000 Price: Call Us |
| 76 |
12000053 |
E-Ring Price: Call Us |
| 77 |
9396E |
Key Square 1/4 x 2 Price: Call Us |
| 81 |
165598 |
Shaft Asm Cross Tapered Price: Call Us |
| 82 |
165711 |
Spring, Torsion Price: Call Us |
| 83 |
19171216 |
Washer 17/32 x 3/4 x 16 Gauge Price: Call Us |
| 84 |
165926 |
Link Transaxle Price: Call Us |
| 89 |
179121X428 |
Console Price: Call Us |
| 95 |
158508 |
Control Asm Bypass Hydro-3000 Price: Call Us |
| 96 |
4497H |
Retainer Spring 1" Zinc/cad. Price: Call Us |
| 110 |
74780612 |
Bolt Hex 3/8-16 x 3/4 Gr. 5 Price: Call Us |
| 111 |
123776X |
Bracket, Transaxle, R.H. Price: Call Us |
| 120 |
73900600 |
Nut Lock Flg. 3/8-16 Unc Price: Call Us |
| 126 |
1685H |
Nut Lock 5/16-18 Nc Thd Price: Call Us |
| 127 |
74490548 |
Bolt Hex Flghd 5/16-18 x 3.0 Gr. 5 Price: Call Us |
| 128 |
184902 |
Lever Control HG 3000 Price: Call Us |
| 129 |
105529X |
Bolt Shoulder 5/16-18 Unc Price: Call Us |
| 131 |
10140500 |
Washer Lock 5/16 Price: Call Us |
| 134 |
158272 |
Rod Actuator Bypass Hydro-3000 Price: Call Us |
| 135 |
123800X |
Washer 1-1/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 136 |
163168X |
Washer Axle Flange Price: Call Us |
| 137 |
19111212 |
Washer 11/32 x 3/4 x 12 Ga. Price: Call Us |
| 138 |
19112016 |
Washer 11/32 x 1.25 x 16 Ga. Price: Call Us |
| 139 |
74780612 |
Bolt Fin Hex 3/8-16 x 3/4 Price: Call Us |
| 140 |
4475J |
Bushing Pinion Sector Price: Call Us |
| 142 |
74330516 |
Bolt 5/16 x 24 x 1 Price: Call Us |
| 146 |
74490536 |
Bolt Hex Flghd 5/16-18 x 2-1/4 Price: Call Us |
| 150 |
175456 |
Spacer Price: Call Us |
| 151 |
19133210 |
Washer 13/32 x 2 x 10 Ga. Price: Call Us |
| 156 |
166002 |
Washer Srrted 5/16ID x 1.125 Price: Call Us |
| 158 |
165589 |
Bracket Shift Mount Price: Call Us |
| 159 |
183900 |
Hub Shift Price: Call Us |
| 161 |
72140406 |
Bolt Rdhd Sqnk 1/4-20 x 3/4 Gr 5 Price: Call Us |
| 162 |
73680400 |
Nut Crownlock 1/4-20 Unc Price: Call Us |
| 163 |
74780416 |
Bolt Hex Fin 1/4-20 Unc x 1 Gr 5 Price: Call Us |
| 164 |
19091010 |
Washer 5/8 x .281 x 10 Ga Price: Call Us |
| 165 |
165623 |
Bracket Pivot Lever Price: Call Us |
| 166 |
166880 |
Screw 5/16-18 x 5/8 Price: Call Us |
| 168 |
165492 |
Bolt Shoulder 5/16-18 x .561 Price: Call Us |
| 169 |
165580 |
Plate Fastening Lt Price: Call Us |
| 189 |
160849 |
Washer Spacer Axle Price: Call Us |
| 197 |
169613 |
Nyliner Snap-In 5/8" Id Price: Call Us |
| 198 |
169593 |
Washer Nyl 7/8 Id x .105 Price: Call Us |
| 202 |
72110614 |
Bolt Carr Sh 3/8-16 x 1-3/4 Gr.5 Price: Call Us |
| 230 |
10040500 |
Washer Lock 5/16 Price: Call Us |
