| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 351-59. Price: $273.15 |
| 1 |
484286 |
Fuel Cap w/ Tether (E.P.A.) Price: Call Us |
| 2 |
351-64 |
DISCONTINUED Price: Call Us |
| 2 |
484279-03 |
TUBE, FUEL INLET - 3.00 Price: Call Us |
| 3 |
351-60 |
Backrest Price: Call Us |
| 3 |
484333 |
Remote Vent, No Valve Price: Call Us |
| 4 |
351-65 |
DISCONTINUED Price: Call Us |
| 4 |
484285 |
Grommet, Viton, Price: Call Us |
| 5 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 5 |
48059-05 |
Clamp, Vapor Recovery Hose 3/16" Price: Call Us |
| 6 |
3217-6 |
NUT-HEX Price: $1.19 |
| 6 |
484345 |
Hose, Vapor Recovery 3/16" Price: Call Us |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
485391 |
Valve, Fuel Shut Off Price: Call Us |
| 8 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 8 |
52-4890 |
ROD-CONNECTING This part replaces 351-61. Price: $33.91 |
| 9 |
463655 |
Fuel Tank Assembly (incl. 1, 2, 3, 4, 7, 8) Price: Call Us |
| 9 |
51-0790 |
ADJUSTER-SEAT, LH This part replaces 351-63. Price: $127.92 |
| 10 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 10 |
351-62 |
DISCONTINUED Price: Call Us |
| 11 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 12 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 13 |
428185 |
Mounting Bracket, Fuel Tanks Front Price: Call Us |
| 14 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 15 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 16 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose I.D. Price: Call Us |
| 17 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) Price: Call Us |
| 18 |
484343-01 |
Mender, 1/4 x 3/16 w/0.02 Hole Price: Call Us |
| 19 |
48059-02 |
CLAMP, FUEL HOSE(KAWASAKI ONLY) Price: Call Us |
| 484297 |
Fuel |
Cap w/Tethered - California Models Only Price: Call Us 484297 |
