| Ref | Part Number | Description |
|---|
| 1 |
3274-70 |
SCREW-HSH Price: $9.50 |
| 1 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 1 |
920-3000 |
CONTROL KNOB Not Available This part replaces 720-3000. Price: |
| 2 |
353-727 |
BONNET-SPECIAL Price: $105.32 |
| 2 |
598831601 |
Service Kit This part replaces 532427148. Price: $199.99 |
| 3 |
353-729 |
DETENT STUD Price: $179.48 |
| 3 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 3 |
712-3059 |
Nut, Hex Top Lock, 1/2-20 Price: $4.08 |
| 4 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 4 |
532427146 |
PULLEY.FLANGE.IMPELLER Price: $29.99 |
| 4 |
936-3022 |
BELL WASHER Not Available This part replaces 736-3022. Price: |
| 5 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 5 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532442438. Price: $9.99 |
| 5 |
703-1705 |
BRACKET-FRICTION Not Available Price: |
| 6 |
237-54 |
O-RING Price: $1.97 |
| 6 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 6 |
723-3055 |
FRICTION WASHER Not Available Price: |
| 7 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 7 |
532192199 |
CLEAN OUT TOOL Price: $14.99 |
| 7 |
748-3024 |
SHOULDER SPACER. Not Available Price: |
| 8 |
353-305 |
O-RING Price: $10.91 |
| 8 |
532405400 |
CLIP.CLEANOUT.TOOL Price: $2.99 |
| 8 |
711-3252 |
ROD-UPPER SHIFT CONTROL Not Available Price: |
| 9 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 9 |
923-3018 |
Ball Joint This part replaces 723-3018. Price: $15.50 |
| 10 |
353-302 |
O-RING Price: $10.13 |
| 10 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 10 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 11 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 532427942. Price: $5.99 |
| 11 |
712-3054 |
Nut, Hex Patch Lock, 3/8-24 GR5 Price: $3.90 |
| 12 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 12 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 12 |
736-0185 |
Washer, Flat, .406 X .75 X .063 Thk Price: $3.43 |
| 13 |
353-392 |
RING-PISTON Price: $13.94 |
| 13 |
532427145 |
HUB.IMP.PULLEY.D-SHAFT Price: $4.99 |
| 13 |
714-0507 |
Pin, Cotter, 3/32 Dia X .75 Lg Price: $3.93 |
| 14 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 14 |
532427154 |
SLEEVE.IMP.PULLEY.D-SHAFT Price: $3.99 |
| 14 |
703-1640 |
CAM LEVER ASSEMBLY Not Available Price: |
| 15 |
353-328 |
SHIM (.040) Price: $3.53 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 15 |
703-1642 |
ASSEMBLY Not Available Price: |
| 16 |
353-329 |
SHIM (.020) Price: $2.10 |
| 16 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 16 |
736-0105 |
Washer, Bell Price: $3.96 |
| 17 |
353-330 |
SHIM (.010) Price: $3.60 |
| 17 |
532194189 |
SCREW.HWH.13-16-5.8.BZP Price: $4.99 |
| 17 |
712-0262 |
Nut, Hex Center Lock Jam, 3/8-24 Price: $3.90 |
| 18 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 18 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 18 |
936-0206 |
Washer, Spec .378 x 1.0 x .125 Thk This part replaces 736-0206. Price: $3.93 |
| 19 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 19 |
710-1039 |
Screw, Hex Cap 3/8-24 x 1.0 GR8 This part replaces 710-0152. Price: $4.02 |
| 20 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 20 |
532427345 |
GASKET.GEAR.BOX Price: $4.99 |
| 20 |
747-3129 |
HYDRO CONTROL ROD Not Available Price: |
| 21 |
353-575 |
BOOT Price: $58.68 |
| 21 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 21 |
712-3067 |
Nut, Hex Patch Lock, 7/16-20 Price: $5.59 |
| 22 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 22 |
736-0226 |
Washer, Flat Price: $3.64 |
| 22 |
93-3651 |
RETAINER-BOOT Price: $31.38 |
| 23 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 23 |
711-3255 |
FERRULE Not Available Price: |
| 24 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 24 |
735-0200 |
RUBBER WASHER Not Available Price: |
| 24 |
92-2547 |
SEAL-RETAINER Price: $15.10 |
| 25 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 25 |
711-3254 |
STUD-ADJUSTMENT Not Available Price: |
| 25 |
92-2546 |
WIPER-SEAL Price: $4.56 |
| 26 |
353-957 |
CUP-SEAL Price: $16.26 |
| 26 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 26 |
912-3057 |
Hex Nut, 5/16-24 This part replaces 712-3057. Price: $5.94 |
| 27 |
353-301 |
CHECK-LIFT, POPPET Price: $23.96 |
| 27 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 27 |
748-3027-0637 |
CONTROL ARM Not Available This part replaces 748-3027. Price: |
| 28 |
353-304 |
SPRING-CHECK, LIFT Price: $25.31 |
| 28 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 28 |
736-3081 |
Washer, Flat, .320 X .60 X .06 Thk HDN Price: $3.08 |
| 29 |
353-331 |
O-RING Price: $16.66 |
| 29 |
532427147 |
SHAFT.IMPELLER.D-SHAFT Price: $74.99 |
| 29 |
712-3009 |
Nut, 5/16 GR 5 This part replaces 712-3068. Price: $5.99 |
| 30 |
353-760 |
RELIEF-BODY Price: $239.97 |
| 30 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 30 |
715-3036 |
PIN-SLOTTED ROLL 5MMX30MMLG Not Available Price: |
| 31 |
353-758 |
O-RING Price: $18.26 |
| 31 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 31 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 32 |
353-952 |
SEAL-BACK-UP Price: $7.89 |
| 32 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 32 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 33 |
3217-7 |
NUT-HEX Price: $0.28 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 33 |
703-1537 |
BRACKET-CLUTCH HANDL Not Available Price: |
| 34 |
353-772 |
COVER-LEFT Price: $415.33 |
| 34 |
532407768 |
O-RING Price: $3.99 |
| 34 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 35 |
353-721 |
PLUG Price: $44.12 |
| 35 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 35 |
736-0176 |
Flat Washer 1/4 ID x .93 OD This part replaces 736-3000. Price: $3.95 |
| 36 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 40 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 41 |
92-3058 |
SPRING - CENTERING Price: $31.34 |
| 42 |
353-780 |
DETENT ASM This part replaces 353-754. Price: $480.94 |
| 43 |
3274-15 |
SCREW-HSH Price: $0.42 |
| 44 |
353-763 |
CAP-ADJUSTMENT Price: $161.34 |
| 45 |
104-7727 |
SPRING-DETENT This part replaces 353-579. Price: $18.78 |
| 46 |
42-2680 |
RACE-BALL Price: $76.92 |
| 47 |
52-5880 |
BALL-DETENT Price: $4.60 |
| 48 |
354-29 |
PLATE-THRUST Price: $236.43 |
| 49 |
353-762 |
SPUD-OUT Price: $152.45 |
| 50 |
353-728 |
SLEEVE Price: $77.42 |
| 52 |
353-732 |
SLEEVE-DETENT Price: $113.02 |
| 53 |
38-0410 |
NUT-HEX Price: $5.77 |
| 54 |
83-1890 |
SWITCH-BALL Price: $63.08 |
