| Ref | Part Number | Description |
|---|
| 010 |
112-8415 |
PISTON ASM This part replaces 98-9470. Price: $456.30 |
| 010 |
115-4127 |
PISTON KIT This part replaces 98-9469. Price: $518.71 |
| 020 |
98-9618 |
PISTON RING ASM (STD) Price: $102.14 |
| 020 |
98-9619 |
PISTON RING ASM (0.5MM) Price: $96.35 |
| 030 |
98-9513 |
PIN-PISTON Price: $13.17 |
| 040 |
98-9514 |
CIRCLIP-PIN, PISTON Price: $2.79 |
| 050 |
117-7586 |
CONNECTING ROD ASM This part replaces 98-9516. Price: $547.99 |
| 060 |
115-3014 |
BUSHING-PIN, PISTON This part replaces 98-9515. Price: $19.81 |
| 070 |
98-9517 |
BOLT-ROD, CONNECTING Price: $10.31 |
| 080 |
117-7588 |
METAL-CRANKPIN (-0.4MM) This part replaces 98-9520. Price: $49.06 |
| 080 |
98-9519 |
BEARING-ROD (-0.2MM) Price: $43.73 |
| 080 |
98-9553 |
BEARING-ROD (STD) This part replaces 98-9518. Price: $52.92 |
| 090 |
98-9642 |
CRANKSHAFT ASM Price: $4,332.74 |
| 100 |
110-3729 |
BALL This part replaces 98-7473. Price: $0.69 |
| 110 |
98-9532 |
GEAR-CRANKSHAFT Price: $169.43 |
| 120 |
98-9666 |
KEY Price: $3.58 |
| 130 |
98-9542 |
GEAR-DRIVE, OIL PUMP Price: $89.04 |
| 140 |
98-9522 |
SLEEVE-CRANKSHAFT Price: $116.47 |
| 150 |
98-9521 |
COLLAR-CRANKSHAFT Price: $84.21 |
| 160 |
105-3783 |
O-RING Price: $6.33 |
| 170 |
112-7005 |
BEARING-MAIN (STD) This part replaces 98-9523. Price: $66.99 |
| 170 |
98-9528 |
BEARING-MAIN (-0.2MM) Price: $15.04 |
| 170 |
98-9529 |
BEARING-MAIN (0.4MM) Price: $40.04 |
| 180 |
127-0433 |
METAL-CRANKSHAFT (-0.2MM) This part replaces 98-9530. Price: $60.46 |
| 180 |
98-9524 |
METAL-CRANKSHAFT (STD SET) Price: $62.26 |
| 180 |
98-9531 |
BEARING-MAIN (0.4MM) Price: $39.97 |
| 190 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 98-9525. Price: $86.06 |
| 190 |
98-9526 |
BEARING-MAIN (0.2MM) Price: $64.36 |
| 190 |
98-9527 |
BEARING-MAIN (0.4MM) Price: $63.74 |
| 200 |
127-0416 |
METAL-SIDE (+0.2MM) This part replaces 98-9414. Price: $21.04 |
| 200 |
98-9413 |
BEARING-THRUST (STD) Price: $16.90 |
| 200 |
98-9415 |
BEARING-THRUST (0.4MM) Price: $9.77 |
| 210 |
127-0437 |
METAL-SIDE (+0.2MM) This part replaces 98-9689. Price: $18.42 |
| 210 |
127-0438 |
METAL-SIDE (+0.40MM) This part replaces 98-9690. Price: $12.65 |
| 503226503 |
503226503 |
NUT Price: $3.99 |
| 503283201 |
536033701 |
CARBRETOR HD-12C H372 This part replaces 503283201. Price: $99.99 |
| 503400606 |
503400606 |
TUBE Price: $5.99 |
| 503431801 |
503431801 |
SLEEVE Price: $4.99 |
| 503627501 |
503627502 |
FILTER HOLDER XP This part replaces 503627501. Price: $9.99 |
| 503665301 |
503665301 |
SLEEVE Price: $5.99 |
| 503701101 |
503701101 |
PIPE Price: $3.99 |
| 503712701 |
503712701 |
FLANGE Price: $9.99 |
| 503735401 |
503735401 |
AIR FILTER CLIP Price: $3.99 |
| 503743801 |
503743801 |
GASKET Price: $7.99 |
| 503743901 |
503743901 |
INTAKE PIPE Price: $37.99 |
| 503814501 |
575269101 |
AIR FILTER ASSY This part replaces 503814501. Price: $22.99 |
| 503814502 |
575269102 |
AIR FILTER ASSY This part replaces 503814502. Price: $27.99 |
| 503814503 |
575269103 |
AIR FILTER ASSY This part replaces 503814503. Price: $24.99 |
| 725530555 |
725530555 |
SCREW Price: $2.99 |
