| Ref | Part Number | Description |
|---|
| 1 |
110-6120 |
ENGINE ASSEMBLY-REPLACEMENT This part replaces 95-6499. Price: $22,658.55 |
| 1 |
919-3060A |
AXLE HOUSING Not Available This part replaces 619-3060. Price: |
| 2 |
661-3014 |
BRAKE ASSEMBLY-DRUM Not Available Price: |
| 2 |
99-8879 |
COUPLING-SPRING, CENTER This part replaces 98-0826. Price: $643.95 |
| 3 |
710-0538 |
Screw, Hex Cap Lock, 5/16-18 x .625 GR5 Price: $4.02 |
| 3 |
95-6481-03 |
PLATE-ADAPTER, PUMP This part replaces 95-6481. Price: $909.81 |
| 4 |
710-1695 |
SCREW 3/8-16 x 1 Not Available Price: |
| 4 |
98-0655 |
HYD HOSE ASM Price: $149.15 |
| 5 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
710-3119 |
Screw, Hex Cap Lock, 3/8-16 x .75 GR5 Price: $5.91 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 6 |
710-3238 |
SCREW 7/16-14X1.75 GR5 Not Available Price: |
| 7 |
353-992 |
FLANGE-SPLIT Price: $20.28 |
| 7 |
711-1326 |
AXLE STUB SHAFT (LH) Not Available Price: |
| 8 |
108-8047 |
GEAR PUMP REPLACEMENT KIT This part replaces 69-2050. Price: $4,136.66 |
| 8 |
711-1327 |
AXLE SHAFT Not Available Price: |
| 9 |
354-42 |
FLANGE-SPLIT Price: $14.79 |
| 9 |
711-1358 |
AXLE STUB SHAFT (LH) Not Available Price: |
| 10 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 10 |
711-1389A |
DIFF LOCK SHAFT Not Available Price: |
| 11 |
69-5640 |
HOSE-RETURN Price: $36.06 |
| 11 |
715-0226 |
DOWEL PIN .375X.75 Not Available Price: |
| 12 |
715-3010 |
DOWEL PIN-1/4 x 3/4 Not Available Price: |
| 12 |
99-8077 |
TUBE - SUCTION This part replaces 94-1891. Price: $254.61 |
| 13 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 13 |
716-0180 |
Ring, Retaining Price: $10.38 |
| 14 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 14 |
716-0195 |
RETAINING RING Not Available Price: |
| 15 |
323-6 |
SCREW-HH Price: $0.66 |
| 15 |
716-0196 |
RETAINING RING Not Available Price: |
| 16 |
69-9220-03 |
BRACKET-TUBE, SUCTION This part replaces 69-9220. Price: $23.66 |
| 16 |
716-0390 |
RETAINING RING Not Available Price: |
| 17 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 17 |
716-0391 |
RETAINING RING Not Available Price: |
| 18 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
716-0396 |
ROTOR CLIP Not Available Price: |
| 19 |
3217-6 |
NUT-HEX Price: $1.19 |
| 19 |
716-0397 |
RETAINING RING Not Available Price: |
| 20 |
325-6 |
SCREW-HH Price: $1.42 |
| 20 |
717-1120 |
Gear, Differential, 10T Price: $28.27 |
| 21 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 21 |
717-1173 |
Shaft, Cross Price: $34.09 |
| 22 |
3213-2 |
SCREW-HH Price: $1.90 |
| 22 |
717-1178 |
Shaft, Cross Price: $25.43 |
| 23 |
33115-030 |
SCREW-HH Price: $0.68 |
| 23 |
717-1180 |
Block, Differential Pinion Price: $29.40 |
| 24 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 24 |
717-3316 |
Gear, Bevel, 65T Price: $301.53 |
| 25 |
33115-025 |
SCREW-HH Price: $0.61 |
| 25 |
717-3317 |
MITER GEAR 14T Not Available Price: |
| 26 |
321-6 |
SCREW-HH Price: $0.25 |
| 26 |
717-3471 |
BULL GEAR (RH) Not Available Price: |
| 27 |
717-3478 |
BULL GEAR (LH) Not Available Price: |
| 27 |
95-6465-03 |
RH REAR MOUNT ASM This part replaces 95-6465. Price: $93.67 |
| 28 |
323-10 |
SCREW-HH Price: $0.89 |
| 28 |
718-0666 |
DIFFERENTIAL CARRIER Not Available Price: |
| 29 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 29 |
718-3104 |
DIFF LOCK COLLAR Not Available Price: |
| 30 |
69-8490-03 |
BRACKET-CABLE, THROTTLE This part replaces 69-8490. Price: $22.94 |
| 30 |
718-3105 |
DIFF LOCK YOKE Not Available Price: |
| 31 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 31 |
718-3112 |
BEARING COVER Not Available Price: |
| 32 |
33113-016 |
SCREW-HH Price: $0.34 |
| 32 |
721-0495 |
OIL SEAL Not Available Price: |
| 33 |
32128-21 |
NUT-HF Price: $0.39 |
| 33 |
721-0496 |
Seal, Oil Price: $9.52 |
| 34 |
921-3020A |
Seal, Oil, 1.18 ID This part replaces 721-3020A. Price: $10.75 |
| 34 |
95-6489 |
DISCONTINUED Price: Call Us |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 35 |
732-0187 |
COMPRESSION SPRING Not Available Price: |
| 36 |
33116-050 |
SCREW-HH Price: $15.13 |
| 36 |
736-0355 |
Washer, Flat, .56 x 1.0 x .04 Not Available Price: |
| 37 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 37 |
736-0715 |
THRUST WASHER Not Available Price: |
| 38 |
741-0721 |
BALL BEARING Not Available Price: |
| 38 |
95-6470-03 |
LH FRONT MOUNT ASM This part replaces 95-6470. Price: $109.73 |
| 39 |
32128-23 |
NUT-HF Price: $1.51 |
| 39 |
741-1104 |
BEARING BALL Not Available Price: |
| 40 |
741-1107 |
BALL BEARING Not Available Price: |
| 40 |
98-3023 |
WASHER Price: $10.18 |
| 41 |
741-1112 |
THRUST BEARING Not Available Price: |
| 41 |
95-6486 |
SPACER-MOUNT Price: $11.33 |
| 42 |
941-3033A |
Bearing, Ball This part replaces 741-3033A. Price: $50.07 |
| 42 |
98-0830 |
RETAINER-MOUNT Price: $19.21 |
| 43 |
741-3080 |
Bearing, Needle Price: $22.21 |
| 43 |
98-3024 |
MOUNT-ENGINE Price: $103.88 |
| 44 |
323-38 |
SCREW-HH Price: $2.62 |
| 45 |
325-9 |
SCREW-HH Price: $1.87 |
| 46 |
33116-030 |
SCREW-HH Price: $1.56 |
| 47 |
95-6467-03 |
RH FRONT MOUNT ASM This part replaces 95-6467. Price: $99.77 |
| 48 |
95-6465-03 |
RH REAR MOUNT ASM This part replaces 95-6465. Price: $93.67 |
| 49 |
282-28 |
CLEVIS-ADJUSTABLE Price: $58.02 |
| 50 |
77-2990 |
CABLE-THROTTLE Price: $348.96 |
| 51 |
69-0090 |
PIN-THROTTLE Price: $18.93 |
| 52 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 54 |
93-3526 |
SWITCH Price: $177.42 |
| 55 |
67-4510 |
GUAGE-TEMP, WATER Price: $151.90 |
| 56 |
51-5070 |
SWITCH-THERMAL Price: $149.69 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 502103001 |
502103001 |
SPACER Price: $11.99 |
| 502103101 |
502103101 |
BUSHING Price: $9.99 |
| 502119701 |
502119701 |
SPRING Price: $0.99 |
| 502213201 |
502213201 |
LEVER, THROTTLE Price: $2.99 |
| 502213301 |
502213301 |
Throttle Flap Price: $0.84 |
| 502213401 |
502213401 |
SHAFT ASSY, THROTTLE Price: $3.99 |
| 502213501 |
502213501 |
Plug Price: $10.05 |
| 502213701 |
502213701 |
FUEL LINE FITTING Price: $5.99 |
| 502213801 |
502213801 |
Cover, Fuel Price: $3.71 |
| 502213901 |
502213901 |
CHOKE SHAFT Price: $3.99 |
| 503104701 |
503104701 |
SCREW Price: $9.99 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503117001 |
503117001 |
VALVE/INLET. Price: $19.99 |
| 503281505 |
577133001 |
CARBURETOR WT-964-1 This part replaces 503281505. Price: $74.99 |
| 503281506 |
577133001 |
CARBURETOR WT-964-1 This part replaces 503281506. Price: $74.99 |
| 503524201 |
503524201 |
NOZZLE Price: $8.58 |
| 503574201 |
503574201 |
WELCH PLUG Price: $6.99 |
| 503581501 |
503581501 |
JET Price: $4.99 |
| 503612301 |
503612301 |
Lo-Speed Needle Price: $2.17 |
| 503612401 |
503612401 |
HI SPEED NEEDLE Price: $2.23 |
| 503625201 |
503625201 |
SCREW Price: $0.55 |
| 503896701 |
503896701 |
DIAPHRAGM Price: $44.99 |
| 503913901 |
503913901 |
LIMITER CAP Price: $2.99 |
| 503914001 |
503914001 |
LIMITER CAP Price: $4.99 |
| 503915101 |
503915101 |
ADJUSTING SCREW Price: $7.99 |
| 503915401 |
503915401 |
CAP Price: $7.99 |
| 503915701 |
503915701 |
SPRING Price: $4.99 |
| 503915801 |
503915801 |
NEEDLE. Price: $4.99 |
| 503922301 |
503922301 |
LIMITER CAP & SCREW SET Price: $44.99 |
| 504130807 |
504130807 |
PUMP DIAPHRAGM Price: $27.99 |
| 504210049 |
504210049 |
SPRING, H-NEEDLE Price: $11.99 |
| 504210050 |
530035293 |
NEEDLE SPRING This part replaces 504210050. Price: $2.99 |
| 505316717 |
505316717 |
SCREW Price: $6.99 |
| 505316745 |
505316745 |
SPRING Price: $2.99 |
| 505316754 |
505316754 |
DIAPHRAGM COVER Price: $3.99 |
| 505316782 |
505316782 |
STARTER LEVER Price: $2.99 |
| 505520110 |
505520110 |
GASKET, METERING SIDE Price: $3.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 505520127 |
505520127 |
LEVER Price: $4.99 |
| 506028101 |
506028101 |
FLAP Price: $2.99 |
| 530035139 |
530035188 |
SPRING-METERING LEVER This part replaces 530035139. Price: $3.99 |
| 530035173 |
530069844 |
GASKET/DIAPHRAGM KIT This part replaces 530035173. Price: $17.99 |
