| Ref | Part Number | Description |
|---|
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 1 |
532198563 |
CORD.ELECTRIC.10FT.120V.SNOW Price: $17.99 |
| 2 |
2410-30 |
CAP-PLASTIC Price: $0.83 |
| 2 |
532169675 |
SPRING RETAINER Price: $3.99 |
| 3 |
237-68 |
O-RING Price: $3.22 |
| 3 |
532429112 |
WRENCH.SNOWTHROWER.ZINC.YZ Price: $2.99 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 4 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
819131316 |
WASHER Price: $2.99 |
| 6 |
119-4067 |
SCREW-HH Price: $0.81 |
| 6 |
588077501 |
BOLT.1/4-20 X 1-13/16 SHEAR This part replaces 532192090. Price: $1.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 15 |
112-1718-01 |
BEDBAR Price: $300.88 |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 20 |
137-6090 |
BEDKNIFE-EDGEMAX LOWCUT (RM 18IN) This part replaces 125-2770. Price: $172.72 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
120-9941 |
BOLT-BEDBAR Price: $13.66 |
| 25 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 27 |
125-2779-01 |
WEIGHT-END, 5 INCH Price: $125.85 |
| 28 |
115-5258 |
SPRING-WIRE, FLAT Price: $3.40 |
| 29 |
140-5510 |
BEARING-SEALED, STAINLESS This part replaces 115-3296. Price: $28.48 |
| 30 |
115-3299 |
SEAL-FLOCKED Price: $13.85 |
| 32 |
137-8403 |
ES REEL+, 5IN FWY (18) 11 BLD LD This part replaces 119-9154. Price: $737.62 |
| 34 |
125-2772 |
LH THREADED INSERT ASM Price: $125.14 |
| 35 |
125-2773 |
RH THREADED INSERT ASM Price: $73.73 |
| 36 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 37 |
127-4284 |
WASHER-SPECIAL This part replaces 121-6953. Price: $5.88 |
