| Ref | Part Number | Description |
|---|
| 1 |
494549 |
CYLINDER ASSEMBLY Price: Call Us |
| 1 |
99-7575 |
BOLT Price: $4.00 |
| 2 |
293708 |
BUSHING, CYLINDER Price: Call Us |
| 2 |
99-7570 |
BEARING-ROLLER, TAPER Price: $61.91 |
| 3 |
299819 |
SEAL, OIL Price: Call Us |
| 3 |
95-7535 |
CASE-BEARING Price: $104.73 |
| 4 |
106-1065 |
O-RING Price: $9.02 |
| 5 |
213942 |
HEAD, CYLINDER Price: Call Us |
| 5 |
99-7572 |
COLLAR-SEAL, OIL Price: $21.01 |
| 6 |
106-1066 |
O-RING Price: $5.71 |
| 7 |
272536 |
GASKET, CYLINDER HEAD Price: Call Us |
| 7 |
99-7574 |
SEAL-OIL Price: $4.42 |
| 8 |
294178 |
BREATHER, VALVE CHAMBER Price: Call Us |
| 8 |
99-7559 |
WASHER-LOCK Price: $9.82 |
| 9 |
27549 |
GASKET, VALVE COVER Price: Call Us |
| 9 |
99-7560 |
NUT-LOCK Price: $27.76 |
| 10 |
93394 |
SCREW, SEMS, BREATHER, MOUNTING Price: Call Us |
| 10 |
99-7550 |
SHIM 0.1 Price: $4.34 |
| 11 |
66578 |
GROMMET, BREATHER TUBE Price: Call Us |
| 12 |
270833 |
GASKET, CRANKCASE, STANDARD .015" Price: Call Us |
| 13 |
93111 |
SCREW, CYLINDER HEAD Price: Call Us |
| 15 |
94387 |
PLUG OIL DRAIN Price: Call Us |
| 16 |
492880 |
CRANKSHAFT Price: Call Us |
| 18 |
394820 |
BUSHING, CRANKCASE COVER Price: Call Us |
| 19 |
293708 |
BUSHING, CYLINDER Price: Call Us |
| 20 |
299819 |
SEAL, OIL Price: Call Us |
| 21 |
66768 |
PLUG, OIL FILLER Price: Call Us |
| 22 |
94607 |
SCREW, SEM, MOUNTING Price: Call Us |
| 23 |
296884 |
KEY, FLYWHEEL Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 25 |
298904 |
PISTON ASSEMBLY, STANDARD Price: Call Us |
| 26 |
298982 |
RING SET, PISTON, STANDARD Price: Call Us |
| 27 |
26026 |
LOCK, PISTON PIN Price: Call Us |
| 28 |
298909 |
PIN ASSY, PISTON, STD Price: Call Us |
| 29 |
294367 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 30 |
220670 |
DIPPER, CONNECTING ROD Price: Call Us |
| 32 |
94404 |
SCREW, CONNECTING ROD Price: Call Us |
| 33 |
296676 |
VALVE, EXHAUST Price: Call Us |
| 34 |
296677 |
VALVE, INTAKE Price: Call Us |
| 35 |
260552 |
SPRING, INTAKE VALVE Price: Call Us |
| 37 |
224557 |
GUARD, FLYWHEEL Price: Call Us |
| 40 |
93312 |
RETAINER, VALVE SPRING Price: Call Us |
| 45 |
230173 |
TAPPET, VALVE Price: Call Us |
| 46 |
493747 |
GEAR, CAM Price: Call Us |
| 52 |
271936 |
GASKET, INTAKE ELBOW MOUNTING Price: Call Us |
| 53 |
94523 |
SCREW, EXHAUST Price: Call Us |
| 56 |
280439 |
PULLEY, STARTER Price: Call Us |
| 57 |
490179 |
SPRING, REWIND STARTER Price: Call Us |
| 58 |
280406 |
ROPE, REWIND STARTER Price: Call Us |
| 60 |
393152 |
HANDLE, REWIND STARTER Price: Call Us |
| 66 |
399671 |
CLUTCH ASSEMBLY, REWIND STARTER Price: Call Us |
| 67 |
394897 |
HOUSING, STARTER CLUTCH Price: Call Us |
| 68 |
63770 |
BALL, CLUTCH Price: Call Us |
| 70 |
298799 |
RATCHET, REWIND STARTER Price: Call Us |
| 71 |
394506 |
WASHER, CLUTCH RETAINER Price: Call Us |
| 73 |
221661 |
SCREEN, REWIND STARTER Price: Call Us |
| 74 |
93758 |
SCREW, SEMS Price: Call Us |
| 75 |
223047 |
WASHER, SPRING Price: Call Us |
| 90 |
492645 |
CARBURETOR ASSEMBLY Price: Call Us |
| 95 |
93499 |
SCREW Price: Call Us |
| 96 |
223793 |
THROTTLE, CARBURETOR Price: Call Us |
| 97 |
490371 |
SHAFT AND LEVER, THROTTLE Price: Call Us |
| 108 |
490495 |
VALVE GROUP, CHOKE Price: Call Us |
| 118 |
231533 |
VALVE, NEEDLE Price: Call Us |
| 124 |
94616 |
SCREW, ELBOW MOUNTING Price: Call Us |
| 127 |
220352 |
PLUG, WELCH Price: Call Us |
| 127A |
223789 |
PLUG, WELCH Price: Call Us |
| 149 |
26336 |
SPRING, NEEDLE VALVE Price: Call Us |
| 152 |
260575 |
SPRING, THROTTLE ADJUSTMENT Price: Call Us |
| 153 |
490501 |
SCREW, CARBURETOR CAM AND LEVER Price: Call Us |
| 154 |
93527 |
SCREW, MACHINE, ROUND HEAD Price: Call Us |
| 156 |
492905 |
LEVER, SPEED ADJUSTER, FIXED SPEED Price: Call Us |
| 163 |
271935 |
GASKET, AIR CLEANER MOUNTING Price: Call Us |
| 180 |
495377 |
TANK ASSEMBLY, FUEL Price: Call Us |
| 181 |
494559 |
CAP, FUEL TANK Price: Call Us |
| 190 |
94712 |
SCREW, FUEL TANK Price: Call Us |
| 191 |
272489 |
GASKET, FUEL TANK TO CARBURETOR Price: Call Us |
| 200 |
495213 |
BLADE, GOVERNOR Price: Call Us |
| 201 |
262325 |
LINK, AIR VANE GOVERNOR Price: Call Us |
| 209 |
262317 |
SPRING, AIR VANE GOVERNOR Price: Call Us |
| 216 |
262359 |
LINK, CHOKE Price: Call Us |
| 222 |
490649 |
PANEL, CONTROL Price: Call Us |
| 298 |
220859 |
LOCKNUT, MUFFLER Price: Call Us |
| 299 |
493288 |
MUFFLER, EXHAUST Price: Call Us |
| 305A |
93777 |
SCREW, HEX HEAD BACK PLATE TO CYLINDER Price: Call Us |
| 306 |
224555 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
93758 |
SCREW, SEMS Price: Call Us |
| 308 |
224556 |
COVER, CYLINDER HEAD Price: Call Us |
| 333 |
398593 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
93381 |
SCREW, SEM, ARMATURE MOUNTING Price: Call Us |
| 337 |
802592 |
PLUG, SPARK Price: Call Us |
| 346 |
93705 |
SUB= 69485 Price: Call Us |
| 356 |
398808 |
WIRE, GROUND Price: Call Us |
| 358 |
494550 |
GASKET SET Price: Call Us |
| 363 |
19069 |
PULLEY, FLYWHEEL Price: Call Us |
| 383 |
262328 |
SPRING, FUEL PUMP DIAPHRAGM Price: Call Us |
| 392 |
262328 |
SPRING, FUEL PUMP DIAPHRAGM Price: Call Us |
| 394 |
270026 |
DIAPHRAGM Price: Call Us |
| 432 |
221377 |
CAP, SPRING Price: Call Us |
| 433 |
93265 |
PIN, DIAPHRAGM COVER Price: Call Us |
| 434 |
210959 |
COVER, DIAPHRAGM Price: Call Us |
| 467 |
280715 |
KNOB, CONTROL Price: Call Us |
| 526 |
94408 |
SCREW SEMS TANK BRKT MOUNT Price: Call Us |
| 527 |
223786 |
CLAMP BREATHER TUBE Price: Call Us |
| 528 |
231527 |
TUBE, BREATHER Price: Call Us |
| 529 |
67838 |
GROMMET, BREATHER TUBE Price: Call Us |
| 536 |
494279 |
AIR CLEANER KIT Price: Call Us |
| 541 |
22398 |
WASHER, SPEED ADJUSTER LEVEL Price: Call Us |
| 542 |
94269 |
SCREW, AIR CLEANER Price: Call Us |
| 608 |
491046 |
STARTER ASSEMBLY, REWIND Price: Call Us |
| 611 |
391813 |
FUEL PIPE AND CLIP ASSEMBLY Price: Call Us |
| 621 |
396847 |
SWITCH, STOP Price: Call Us |
| 634 |
271853 |
WASHER, THROTTLE SHAFT, FOAM Price: Call Us |
| 635 |
66538 |
ELBOW, SPARK PLUG Price: Call Us |
| 676 |
393756 |
DEFLECTOR, MUFFLER Price: Call Us |
| 679 |
270382 |
WASHER, FOAM Price: Call Us |
| 680 |
221839 |
WASHER, BRASS Price: Call Us |
| 741 |
261533 |
GEAR, TIMING Price: Call Us |
| 779 |
262276 |
LINK, CONTROL Price: Call Us |
| 851 |
221798 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 864 |
492232 |
ADAPTER ASSEMBLY, MUFFLER Price: Call Us |
| 869 |
211172 |
SEAT, INTAKE VALVE, STANDARD Price: Call Us |
| 870 |
211291 |
SEAT, EXHAUST VALVE, STANDARD Price: Call Us |
| 871 |
262001 |
GUIDE, EXHAUST VALVE Price: Call Us |
| 883 |
272203 |
GASKET, MUFFLER Price: Call Us |
| 966 |
492797 |
BASE, AIR CLEANER Price: Call Us |
| 967 |
491588 |
SUB= 3364 Price: Call Us |
| 968 |
223765 |
COVER, AIR CLEANER Price: Call Us |
| 969 |
490073 |
SCREW, COVER MOUNTING Price: Call Us |
| 971 |
94018 |
SCREW, AIR CLEANER Price: Call Us |
| 987 |
398970 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 995 |
223887 |
BRACKET, CONTROL LINK Price: Call Us |
| 63709 |
GUIDE, |
INTAKE VALVE Price: Call Us 63709 |
| 93448 |
PLUG, |
PIPE, HEX SOCKET Price: Call Us 93448 |
| 230978 |
CRANKSHAFT |
GEAR PIN Price: Call Us 230978 |
| 270895 |
GASKET, |
CRANKCASE .005" Price: Call Us 270895 |
| 270896 |
GASKET, |
CRANKCASE .009" Price: Call Us 270896 |
| 296079 |
ROD |
ASSEMBLY, CONNECTING .020" UNDERSIZE CRANKPIN Price: Call Us 296079 |
| 298905 |
PISTON |
ASSEMBLY .010" OVERSIZE Price: Call Us 298905 |
| 298906 |
PISTON |
ASSEMBLY .020" OVERSIZE Price: Call Us 298906 |
| 298907 |
PISTON |
ASSEMBLY .030" OVERSIZE Price: Call Us 298907 |
| 298908 |
PIN |
ASSEMBLY, PISTON .005" OVERSIZE Price: Call Us 298908 |
| 298983 |
RING |
SET, PISTON .010" OVERSIZE Price: Call Us 298983 |
| 298984 |
RING |
SET, PISTON .020" OVERSIZE Price: Call Us 298984 |
| 298985 |
RING |
SET, PISTON .030" OVERSIZE Price: Call Us 298985 |
