Engine Assembly Type 7
Parts (37)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 115-6694 | YOKE-LIFT This part replaces 110-8111-01. Price: $77.72 |
| 1 | 530016153 | Screw Price: $1.99 |
| 2 | 110-8110 | SPACER Price: $13.38 |
| 3 | 110-8114 | WASHER Price: $4.14 |
| 4 | 66-7230 | SPRING-COMPRESSION Price: $9.25 |
| 5 | 3256-3 | WASHER-FLAT Price: $0.49 |
| 5 | 530015780 | Screw Price: $1.99 |
| 6 | 3211-12 | SCREW-HH Price: $1.70 |
| 6 | 530095646 | Assy-Fuel Pick-up Price: $2.99 |
| 7 | 3220-3 | NUT-HJ Price: $0.28 |
| 7 | 530047442 | Strap-Ground Price: $1.99 |
| 8 | 530039198 | Ignition Module Price: $29.99 |
| 8 | 92-7008 | END-ROD, FEMALE Price: $49.99 |
| 9 | 110-8108 | ROD-LINK Price: $24.52 |
| 9 | 530015814 | Screw Price: $1.99 |
| 10 | 530052296 | Assy-Wire Harness Price: $4.99 |
| 11 | 530037793 | Foam- Air Filter Price: $1.99 |
| 12 | 530016101 | Nut Price: $1.99 |
| 13 | 530057480 | Assy- Air Box Price: $4.99 |
| 14 | 530035526 | Grommet-Carb Adjust Price: Call Us |
| 15 | 530054144 | Seal-Carb Adapter Price: $2.99 |
| 16 | 530055698 | Reflector-Heat Price: $1.99 |
| 18 | 530016136 | Clip-High Tension Lead Price: $1.99 |
| 19 | 530012550 | Cylinder Price: $17.99 |
| 20 | 530049870 | Backplate-Muffler Price: $3.99 |
| 22 | 530037813 | Diffuser-Muffler Price: $1.99 |
| 23 | 530036103 | Screen-Spark Price: Call Us |
| 24 | 530016132 | Bolt-Muffler Price: $1.99 |
| 27 | 530016386 | Screw Price: $5.99 |
| 28 | 530049700 | Carb. Adapter Price: $3.99 |
| 29 | 530016187 | Screw Price: $1.99 |
| 31 | 545160401 | Ring-Piston This part replaces 530038729. Price: $2.99 |
| 32 | 530015697 | Retainer-Piston Pin Price: $1.99 |
| 35 | 530031163 | Bar Wrench Price: $4.99 |
| 36 | 530056363 | Assy-Seal & Bearing Price: $11.99 |
| 37 | 530037935 | Cap-Crankcase Price: $8.99 |
| 38 | 545113101 | CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
