| Ref | Part Number | Description |
|---|
| 1 |
43-1911 |
FAN Price: $152.80 |
| 1 |
598602801 |
Decks This part replaces 532441275. Price: $349.99 |
| 1 |
710-04968 |
Bolt Price: $5.77 |
| 2 |
43-3690 |
SHAFT-FAN Price: $469.68 |
| 2 |
951-11054B |
Valve Cover This part replaces 951-11054. Price: $13.54 |
| 3 |
3257-30 |
KEY-WOODRUFF Price: $5.35 |
| 3 |
951-14855 |
Breather Hose Price: $7.64 |
| 4 |
43-3700 |
HUB - FAN Price: $144.65 |
| 4 |
726-04101 |
Hose Clamp Not Available Price: |
| 5 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
53-9750-03 |
MASKED FAN MOUNT ASM This part replaces 53-9750. Price: $613.60 |
| 7 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 7 |
751-11124 |
Pivot Locking Nut Price: $8.18 |
| 8 |
43-3870-03 |
MUFFLER SUPPORT This part replaces 43-3870. Price: $30.07 |
| 8 |
751-11123 |
Valve Adjusting Nut Price: $9.09 |
| 9 |
3233-14 |
SCREW-CARR Price: $1.95 |
| 10 |
43-3880 |
PULLEY HUB WA Price: $83.15 |
| 10 |
710-04902 |
Pivot Bolt Price: $5.94 |
| 11 |
43-5910 |
FAN BELT Price: $16.05 |
| 12 |
29-8910 |
WASHER Price: $0.75 |
| 12 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 13 |
32136-3 |
NUT-SHH Price: $1.22 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 14 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
3-6803 |
WASHER-ADJUSTING Price: $0.75 |
| 15 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 15 |
710-04933 |
Bolt Price: $3.42 |
| 16 |
32128-23 |
NUT-HF Price: $1.51 |
| 17 |
43-3850 |
MUFFLER Price: $433.18 |
| 18 |
66-5310-03 |
V PULLEY-IDLER This part replaces 66-5310. Price: $75.13 |
| 18 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
66-5320 |
SPACER IDLER FAN Price: $3.08 |
| 19 |
951-11282 |
MUFFLER ASSEMBLY Not Available Price: |
| 20 |
33014-00 |
NUT-HEX Price: $0.25 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 20 |
710-05001 |
Stud Price: $3.66 |
| 21 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
751P11289A |
MUFFLER GASKET This part replaces 951-11289. Price: $1.96 |
| 22 |
712-04214 |
Nut Price: $3.86 |
| 22 |
77-3140-03 |
ENGINE MOUNT ASM This part replaces 77-3140. Price: $92.87 |
| 23 |
32128-37 |
NUT-HF Price: $3.63 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 23 |
710-04940 |
Bolt Price: $4.56 |
| 24 |
43-3200 |
HEX HD CAPSCREW Price: $13.96 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
951-11111 |
Exhaust Pipe Shield Not Available Price: |
| 25 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 25 |
710-04914 |
Bolt Price: $3.71 |
| 26 |
43-3530-03 |
FLYWHEEL PULLEY This part replaces 43-3530. Price: $512.12 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
710-04915 |
Bolt Price: $3.82 |
| 27 |
324-11 |
SCREW-HH Price: $3.05 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 27 |
951-10642B |
MUFFLER SHROUD Not Available This part replaces 951-10642A. Price: |
| 28 |
53-9480 |
WASHER-SNUBBER Price: $3.87 |
| 28 |
710-04939 |
Stud, M6 x117 Price: $5.71 |
| 29 |
131-1821 |
MOUNT-ENGINE This part replaces 53-9680. Price: $105.39 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
710-04910 |
Stud, M6 x 105 Price: $5.51 |
| 30 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 32 |
66-7030 |
DISCONTINUED Price: Call Us |
| 33 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
951-12705 |
Carburetor Assembly This part replaces 951-10974A. Price: $88.63 |
| 34 |
33114-016 |
SCREW-HH This part replaces 42-9230. Price: $0.27 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 35 |
951-11112 |
Choke Control Bracket Price: $22.42 |
| 36 |
321-3 |
SCREW-HH Price: $0.28 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 36 |
951-10634A |
Air Cleaner Housing This part replaces 951-10634. Price: $28.25 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
68-9110 |
MOUNT SHIM Price: $8.44 |
| 37 |
712-04213 |
Nut Price: $5.94 |
| 38 |
589676103 |
KEEPER 42 MANDREL BELT FOR 6.2 This part replaces 532432520. Price: $6.99 |
| 38 |
951-11284 |
Choke Knob Price: $6.22 |
| 39 |
751P10757A |
THROTTLE LEVER KNOB This part replaces 951-10757. Price: $6.01 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 40 |
951-10637 |
Ignition Switch Price: $13.28 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 43 |
951-10640 |
Choke Push Rod Price: $8.93 |
| 44 |
951-10635 |
Heater Box Price: $14.68 |
| 45 |
710-04919 |
Bolt Price: $3.86 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
532197250 |
BRKT.CLUTCH.CABLE Price: $4.99 |
| 47 |
951-10648 |
Push Rod Kit (incl. intake and exhaust rod) Price: $15.70 |
| 49 |
715-04108 |
Dowel Pin 10×16 This part replaces 715-04090. Price: $3.65 |
| 55 |
531171201 |
SERVICE KIT IDLER.ARM.42" This part replaces 532437110. Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 57 |
951-11113 |
Air Shield Price: $8.11 |
| 59 |
951-14053 |
Governor Shaft This part replaces 951-11356. Price: $13.94 |
| 60 |
736-04461 |
Washer Price: $3.50 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 62 |
714-04078 |
Cotter Pin This part replaces 714-04074. Price: $3.66 |
| 63 |
532199478 |
ARM.BRAKE.ZINC This part replaces 532199477. Price: $14.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC Price: $11.99 |
| 64 |
951-11369 |
Radial Ball Bearing Price: $30.42 |
| 65 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
598559101 |
Belts This part replaces 532429636. Price: $44.99 |
| 68 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 69 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 70 |
532199972 |
CLUTCH.ASM.MANUAL.YT.PREDATORQ Price: $49.99 |
| 70 |
751P11371B |
CRANKCASE GASKET This part replaces 951-11371. Price: $3.07 |
| 72 |
710-04932 |
Cover Bolt Price: $3.66 |
| 75 |
751P11368A |
OIL SEAL This part replaces 951-11368. Price: $2.70 |
| 78 |
736-04440A |
FLAT WASHER This part replaces 736-04440. Price: $6.01 |
| 80 |
751P11370A |
OIL SEAL This part replaces 951-11370. Price: $2.23 |
| 81 |
951-10646A |
Ignition Module This part replaces 951-10646. Price: $92.65 |
| 82 |
951-11110 |
Air Flow Shield Price: $3.88 |
| 83 |
951-10650 |
Fuel Line Kit (incl. clamps and fuel line) Price: $24.77 |
| 84 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11731. Price: $3.60 |
| 85 |
951-10641 |
Oil Drain Assembly, includes 77, 78, 79 Price: $11.36 |
| 86 |
951-10805 |
Flywheel Price: $117.33 |
| 87 |
951-10909B |
COOLING FAN This part replaces 951-10909. Price: $20.39 |
| 88 |
951-10911 |
Starter Cup Price: $15.19 |
| 89 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04209. Price: $5.33 |
| 90 |
951-10647A |
Valve Kit This part replaces 951-10647. Price: $57.04 |
| 92 |
951-12644 |
FAN COVER ASSEMBLY Not Available This part replaces 951-10663A. Price: |
| 93 |
736-04455B |
FLAT WASHER This part replaces 736-04455. Price: $5.94 |
| 94 |
710-04974 |
Bolt Price: $6.07 |
| 95 |
951-14151 |
Recoil Starter This part replaces 951-10658. Price: $75.50 |
| 96 |
951-10630 |
Ignition Key This part replaces 731-05632. Price: $6.07 |
| 97 |
951-10758 |
Throttle Control Assembly Price: $20.49 |
| 98 |
710-05103 |
Bolt Price: $3.52 |
| 99 |
951-11108 |
Governor Shield Not Available Price: |
| 100 |
951-11935 |
Governor Spring This part replaces 751-11935. Price: $6.85 |
| 101 |
751P10664A |
THROTTLE SPRING This part replaces 951-10664. Price: $2.01 |
| 102 |
751P10665A |
THROTTLE LINKAGE This part replaces 951-10665. Price: $1.53 |
| 104 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 105 |
710-04908 |
Bolt Price: $5.65 |
| 109 |
951-10662 |
ENGINE/DIPSTICK COVER Not Available Price: |
| 110 |
710-04905 |
Bolt Price: $3.86 |
| 113 |
None |
Dipstick Tube |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 115 |
None |
Dipstick |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 117 |
951-12533 |
Fuel Cap Assembly This part replaces 951-10649. Price: $20.81 |
| 118 |
951-11933 |
Fuel Filter This part replaces 751-11933. Price: $8.42 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 119 |
951-10653B |
Fuel Tank Price: $70.14 |
| 121 |
951-11114 |
Switch Housing MTG Bracket Not Available Price: |
| 122 |
951-11904 |
Dipstick O-Ring This part replaces 751-11934. Price: $3.69 |
| 123 |
710-04965 |
Bolt, M4 x 55 Price: $5.77 |
| 124 |
710-04935 |
Bolt, M4 x 60 Price: $3.66 |
| 125 |
710-05182 |
Bolt Price: $3.61 |
| 126 |
715-04088A |
DOWEL PIN This part replaces 715-04088. Price: $2.97 |
| 127 |
951-10645A |
Electric Starter Price: $267.09 |
| 128 |
710-04979 |
Bolt Price: $3.42 |
| 129 |
951-11109 |
Blower Housing Shield Price: $6.40 |
| 130 |
951-10639B |
PRIMER This part replaces 951-10639A. Price: $13.84 |
| 131 |
710-04945 |
Bolt Price: $3.66 |
| 132 |
710-04938 |
FUEL DRAIN PLUG Price: $3.66 |
| 143 |
951-11680 |
Wire Clip Price: $3.61 |
| 144 |
531169801 |
SERVICE KIT BELT KEEPER This part replaces 532199204. Price: $4.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401971 |
RETURN SPRING Price: $4.99 |
| 152 |
532435110 |
CABLE.CLUTCH.CABLE.W/SPRING Price: $32.99 |
| 155 |
951-11106 |
Governor Arm Bracket Price: $6.89 |
| 156 |
951-11381 |
Oil Fill Tube O-Ring This part replaces 951-11903. Price: $4.59 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 192 |
531152801 |
SERVICE KIT BRACKET BRKT.BRAKE This part replaces 532197260. Price: $5.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
