| Ref | Part Number | Description |
|---|
| 2 |
712-0375 |
Hex L-Nut 3/8-16 Thd. Price: $4.02 |
| 4 |
13815 |
Clutch Brkt. Ass'y. Price: Call Us |
| 5 |
736-0169 |
L-Wash. 3/8" I.D.* Price: $3.33 |
| 6 |
712-0798 |
Hex Nut 3/8-16 Thd.* Price: $3.86 |
| 9 |
13872 |
Hand Brake Lever Price: Call Us |
| 11 |
747-0304 |
Brake Rod Price: Call Us |
| 12 |
13832 |
CAM-PARKIN Not Available Price: |
| 13 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 14 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 15 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 16 |
714-0145 |
Hairpin Cotter 3/8" Rod Price: $4.42 |
| 17 |
714-0115 |
Cotter Pin 1/8" Dia. x 1.00" Lg.* Price: $3.48 |
| 18 |
13859 |
BRACKET Not Available Price: |
| 19 |
13856 |
Clutch-Brake Pedal Ass'y. Price: Call Us |
| 20 |
712-0375 |
Hex Cent. L-Nut 3/8-16 Thd.* Price: $4.02 |
| 22 |
756-0328 |
ENGINE PULLEY Not Available Price: |
| 25 |
714-0507 |
Cotter Pin 3/32" Dia. x .75" Lg. * Price: $3.93 |
| 26 |
911-0198 |
Ferrule This part replaces 711-0198. Price: $12.05 |
| 27 |
747-0306 |
BRAKE ROD CAM Not Available Price: |
| 28 |
735-0239A |
FOOT PAD This part replaces 735-0196. Price: $10.76 |
| 29 |
714-0145 |
Hairpin Cotter 3/8" Rod Price: $4.42 |
| 30 |
936-0101 |
Fl-Wash. .375" I.D. x 1.00" O.D. x .030" Not Available This part replaces 736-0101. Price: |
| 31 |
13823 |
JACK SHAFT MTG. BRACKET. ASS'Y. Not Available Price: |
| 32 |
712-0181 |
Hex Top L-Nut 3/8-16 Thd. Price: $3.90 |
| 36 |
756-0324 |
JACK SHAFT Not Available Price: |
| 37 |
720-0189 |
GRIP Not Available Price: |
| 38 |
910-0198 |
HEX SCREW SEMS 5/16-18 x .75 Not Available This part replaces 710-0198. Price: |
| 40 |
741-0591 |
Flanged Brg. 5/8" I.D. This part replaces 741-0295. Price: $4.02 |
| 42 |
710-0599 |
Hex Thd. Rolling Scr. 1/4-20 x .50" Lg. Price: $3.86 |
| 43 |
33871 |
Clutch-ldler Horn Ass'y. Price: Call Us |
| 44 |
715-0108 |
Spring Pin Spiral 1/4" Dia. x 1.00" Lg. Price: $4.38 |
| 45 |
747-0300 |
Parking Brake Link Price: Call Us |
| 46 |
13822 |
BRACKET-ID Not Available Price: |
| 47 |
756-0487 |
Idler Pulley This part replaces 756-0293. Price: $45.43 |
| 48 |
736-0300 |
Fl-Wash. 3/8" I.D. Price: $3.93 |
| 49 |
710-0347 |
Hex Bolt 3/8-16 x 1.75" Lg. Price: $4.39 |
| 50 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 51 |
710-0216 |
Hex Bolt 3/8-16 x .75" Lg. Price: $3.93 |
| 53 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 54 |
710-0180 |
HEX SCREW 3/8-24 x .75 GR5 Not Available Price: |
| 55 |
13829 |
BELT GUARD Not Available Price: |
