| Ref | Part Number | Description |
|---|
| 1 |
353-947 |
CAP-DUST, RUBBER Price: $7.73 |
| 1 |
547746001 |
KIT.SVC.DECK.WELD.46.TEX_668 This part replaces 583900905. Price: $449.99 |
| 2 |
354-85 |
DISCONTINUED Price: Call Us |
| 3 |
237-42 |
O-RING Price: $2.78 |
| 4 |
354-86 |
ADAPTER - 90 DEG Price: $34.47 |
| 4 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
237-65 |
O-RING Price: $2.50 |
| 8 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 9 |
237-81 |
O-RING Price: $2.76 |
| 10 |
59-8550 |
O RING Price: $22.51 |
| 11 |
340-62 |
FLANGE KIT Price: $69.76 |
| 12 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 13 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587256501. Price: $49.99 |
| 14 |
3213-2 |
SCREW-HH Price: $1.90 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 15 |
86-6000-01 |
PUMP This part replaces 86-6000. Price: $2,799.05 |
| 15 |
86-6001 |
DISCONTINUED Price: Call Us |
| 17 |
325-5 |
SCREW-HH Price: $1.20 |
| 18 |
237-22 |
O-RING Price: $2.43 |
| 19 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
340-11 |
ADAPTER Price: $40.75 |
| 21 |
237-58 |
O-RING Price: $2.18 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 23 |
237-30 |
O-RING Price: $2.50 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
237-79 |
O-RING Price: $5.46 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
58-5660 |
PISTON PUMP ASM Price: $3,280.54 |
| 27 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $49.99 |
| 27 |
60-3520 |
O-RING Price: $4.57 |
| 28 |
58-5650 |
DISCONTINUED Price: Call Us |
| 29 |
237-146 |
O-RING Price: $3.75 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
340-15 |
FITTING-ELBOW 90 Price: $47.39 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 32 |
60-3540 |
WASHER Price: $1.36 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
60-3530 |
BOLT Price: $2.12 |
| 34 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
237-30 |
O-RING Price: $2.50 |
| 36 |
340-89 |
FITTING-HYD, 45 DEG Price: $40.22 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 37 |
237-80 |
O-RING Price: $6.10 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 68 |
584453101 |
V-BELT.DRIVE.MWR.MECHANICL.46" This part replaces 532405143. Price: $49.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 197 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 198 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 200 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 240 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 256 |
578296405 |
Screws This part replaces 578296404. Price: $2.99 |
| 257 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 261 |
501063502 |
PLATE.PNT.REINF.DECK.46".EDIP Price: $14.99 |
| 262 |
585317805 |
PLATE.REINFOR.46.SIDEBOLT.X431 Price: $22.99 |
