| Ref | Part Number | Description |
|---|
| 1 |
21-6220 |
DISCONTINUED Price: Call Us |
| 1 |
532125122 |
RIM.ASM.8"REAR.YELLOW.SERVICE This part replaces 532124789. Price: $109.99 |
| 2 |
21-6210 |
DISCONTINUED Price: Call Us |
| 2 |
532138756 |
TIRE.TURF.SAVER.23X8.5-12. This part replaces 532124106. Price: $139.99 |
| 2A |
532007154 |
Tube, Tire (AYP part number) Price: $49.99 |
| 3 |
21-6200 |
DISCONTINUED Price: Call Us |
| 3 |
532108097 |
Spacer, Split (AYP part number) Price: $3.99 |
| 4 |
532009396 |
Square Key (AYP part number) This part replaces 532124762. Price: $3.99 |
| 4 |
62-3430 |
GASKET This part replaces 21-6190. Price: $5.99 |
| 5 |
532123797 |
Transaxle, Peerless Price: $764.80 |
| 5 |
62-3420 |
GASKET This part replaces 21-6180. Price: $11.50 |
| 6 |
254-90 |
BEARING-CUP This part replaces 21-6120. Price: $11.29 |
| 6 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 7 |
21-8010 |
BRG CONE This part replaces 21-6110. Price: $30.15 |
| 7 |
819111214 |
Washer 11/32 x 3/4 x 14 Gauge (AYP part number) Price: Call Us |
| 8 |
21-6170 |
DISCONTINUED Price: Call Us |
| 8 |
532121274 |
Knob, Control (AYP part number) Price: $5.99 |
| 9 |
21-6090 |
DISCONTINUED Price: Call Us |
| 9 |
876020412 |
Pin, Cotter 1/8 x 3/4 (AYP part number) Price: $3.99 |
| 10 |
21-6150 |
DISCONTINUED Price: Call Us |
| 10 |
812000008 |
Ring, Klip (AYP part number) Price: $3.99 |
| 11 |
21-6140 |
DISCONTINUED Price: Call Us |
| 11 |
532141002 |
Rod Shifter (AYP part number) This part replaces 532123781. Price: $16.58 |
| 12 |
21-6130 |
DISCONTINUED Price: Call Us |
| 12 |
532123782 |
Spring, Torsion (AYP part number) Price: $2.99 |
| 13 |
22-4970 |
DISCONTINUED Price: Call Us |
| 14 |
21-6340 |
DISCONTINUED Price: Call Us |
| 14 |
876020416 |
Pin, Cotter 1/8 x 1 (AYP part number) Price: $3.99 |
| 15 |
21-6310 |
DISCONTINUED Price: Call Us |
| 15 |
532105701 |
Washer, Shift Plate (AYP part number) Price: $3.99 |
| 16 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 16 |
531003379 |
WASHER This part replaces 819091216. Price: $2.99 |
| 17 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 17 |
871040412 |
Bolt, Hex 1/4-28 x 3/4 Grade 8 (AYP part number) Price: $3.99 |
| 18 |
32140-96 |
Sems Screw Price: Call Us |
| 18 |
532123791 |
Keeper, Belt, Transaxle, LH (AYP part number) Price: $5.99 |
| 19 |
21-6370 |
DISCONTINUED Price: Call Us |
| 19 |
532123794 |
Arm, Shift (AYP part number) Price: $2.38 |
| 20 |
21-6280 |
DISCONTINUED This part replaces 21-6300. Price: $2.00 |
| 20 |
532126909 |
Spring, Rod, Brake (AYP part number) Price: $2.99 |
| 21 |
21-6280 |
DISCONTINUED This part replaces 21-6290. Price: $2.00 |
| 21 |
532123786 |
Rod, Brake (AYP part number) Price: $24.99 |
| 22 |
21-6280 |
DISCONTINUED Price: $2.00 |
| 22 |
819131316 |
Washer 13/32 x 13/16 x 16 Gauge (AYP part number) Price: $2.99 |
| 23 |
21-6270 |
DISCONTINUED Price: Call Us |
| 23 |
873680600 |
Locknut 3/8-16 Price: $1.99 |
| 24 |
21-6060 |
DISCONTINUED Price: Call Us |
| 24 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $4.99 |
| 25 |
21-6100 |
DISCONTINUED Price: Call Us |
| 25 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 26 |
21-6050 |
DISCONTINUED Price: Call Us |
| 26 |
532123772 |
Shaft Assembly, Shifter (AYP part number) Price: $13.22 |
| 27 |
281-2 |
PLUG-PIPE, SQH Price: $2.09 |
| 27 |
734117771 |
BUSHING This part replaces 819171216. Price: $2.99 |
| 28 |
21-6040 |
DISCONTINUED Price: Call Us |
| 28 |
532123793 |
Rod, Tie (AYP part number) Price: $27.99 |
| 29 |
21-6080 |
DISCONTINUED Price: Call Us |
| 29 |
873610400 |
NUT.FIN HEX 1/4-28 UNF This part replaces 873530400. Price: $2.99 |
| 30 |
21-6070 |
DISCONTINUED Price: Call Us |
| 30 |
532123787 |
Strap, Torque (AYP part number) Price: $2.99 |
| 31 |
21-6350 |
DISCONTINUED Price: Call Us |
| 31 |
532071208 |
Bushing, Steering Rod (AYP part number) Price: $3.99 |
| 32 |
302-34 |
FITTING-LUBE Price: $10.99 |
| 32 |
532123780 |
Bracket, Transaxle, LH (AYP part number) Price: $4.99 |
| 33 |
819212016 |
Washer 21/32 x 1-1/4 x 16 Gauge (AYP part number) Price: $3.99 |
| 34 |
812000053 |
E-Ring (AYP part number) Price: $3.99 |
| 35 |
532123800 |
Washer 1-1/32 x 1-5/8 x 16 Gauge (AYP part number) Price: $3.99 |
| 36 |
532125096 |
Woodruff Key 3/16 x 3/4 (AYP part number) Price: $3.99 |
| 37 |
532121327 |
Pulley, Transaxle (AYP part number) Price: $22.03 |
| 38 |
532059192 |
Cap, Valve (AYP part number) Price: $3.99 |
| 39 |
532065139 |
Stem, Valve (AYP part number) Price: $5.99 |
| 40 |
532123792 |
Keeper, Belt, Transaxle, RH (AYP part number) Price: $3.99 |
| 41 |
812000004 |
Ring, Retainer (AYP part number) Price: $3.99 |
| 42 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 46 |
532123776 |
Bracket, Transaxle, RH (AYP part number) Price: $4.06 |
| 52 |
874780544 |
Bolt, Hex 5/16-18 x 2-3/4 (AYP part number) Price: $3.99 |
| 53 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 55 |
874760612 |
Bolt, Hex 3/8-16 x 3/4 (AYP part number) Price: $1.99 |
| 58 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 74 |
532104757 |
Cap, Axle (AYP part number) Price: $1.99 |
| 75 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
