| Ref | Part Number | Description |
|---|
| 1 |
138-6917 |
ENGINE-YANMAR, 4TNV86CT-DTR This part replaces 120-4111. Price: $20,763.34 |
| 2 |
120-8916-03 |
MOUNT-CONTROLLER Price: $71.66 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 4 |
104-7201 |
NUT-HF Price: $0.69 |
| 5 |
321-3 |
SCREW-HH Price: $0.28 |
| 6 |
99-7435 |
RELAY Price: $32.43 |
| 7 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 8 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 9 |
1-633545 |
SPACER Price: $2.39 |
| 10 |
1-633630 |
GROMMET Price: $5.29 |
| 11 |
3290-134 |
SCREW Price: $0.27 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
321-9 |
SCREW-HH Price: $0.27 |
| 12 |
532194338 |
PULLEY.ASM.ENG.OGURA.3 Price: $54.99 |
| 13 |
121-3058 |
GASKET-EXHAUST Price: $19.54 |
| 14 |
121-3060 |
FLANGE-EXHAUST Price: $113.53 |
| 15 |
33004-00 |
NUT-HF Price: $0.34 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
18-2130 |
CLAMP Price: $5.63 |
| 17 |
121-1613 |
PIPE-EXHAUST Price: $136.35 |
| 18 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
121-1475 |
HOSE-OUTLET, AIR CLEANER Price: $85.24 |
| 20 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 23 |
115-2368 |
HOSE-FUEL Price: $28.33 |
| 24 |
110-4007 |
HOSE-FUEL Price: $26.06 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
