| Ref | Part Number | Description |
|---|
| 1 |
115-8105 |
HARNESS-WIRE, DASH Price: $239.54 |
| 2 |
32105-9 |
SCREW Price: $0.54 |
| 3 |
95-8900 |
SWITCH Price: $95.42 |
| 4 |
32144-89 |
SCREW-THREAD FORMING Price: $1.49 |
| 5 |
104-6961 |
REFLECTOR-HEXAGON, RED Price: $8.02 |
| 6 |
139-4500 |
FRONT LIGHT REPLACEMENT KIT This part replaces 114-8429. Price: $271.08 |
| 7 |
218-456 |
FLASHER Price: $37.40 |
| 8 |
2412-104 |
CLAMP-R Price: $2.37 |
| 9 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 10 |
104-6962 |
REFLECTOR-AMBER Price: $5.71 |
| 11 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 12 |
108-8005 |
CONTROLLER-SIGNAL Price: $193.43 |
| 13 |
114-9711 |
HARNESS-WIRE, TAIL LIGHTS Price: $133.95 |
| 14 |
107-8012 |
DECAL-WARNING LIGHTS, DASH Price: $10.02 |
| 16 |
139-4501 |
REAR LAMP REPLACEMENT KIT This part replaces 114-8428. Price: $191.54 |
| 17 |
95-8999 |
SWITCH Price: $42.14 |
| 18 |
3296-9 |
NUT-HEX Price: $0.25 |
| 19 |
321-4 |
SCREW-HH Price: $0.99 |
| 20 |
104-7201 |
NUT-HF Price: $0.69 |
| 22 |
115-7662-03 |
BRACKET-LIGHT, LH Price: $34.47 |
| 23 |
115-7663-03 |
BRACKET-LIGHT, RH Price: $34.47 |
| 24 |
3250-32 |
SCREW-PPH Price: $0.54 |
| 25 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 26 |
115-8139 |
ADAPTOR-HARNESS, TAIL LIGHT Price: $54.40 |
| 27 |
218-578 |
FUSE-BLADE, 10 AMP Price: $2.58 |
| 28 |
59-5400 |
BOLT-SHOULDER Price: $50.99 |
| 29 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 31 |
115-7988 |
LANYARD-TAILGATE Price: $17.43 |
| 32 |
322-13 |
SCREW-HH Price: $2.73 |
