| Ref | Part Number | Description |
|---|
| a |
(NOT |
SERVICED) CHOKE SHAFT Price: Call Us (NOT SERVICED) |
| b |
(NOT |
SERVICED) CHOKE PLATE Price: Call Us (NOT SERVICED) |
| c |
(NOT |
SERVICED) CHOKE RETURN SPRING Price: Call Us (NOT SERVICED) |
| d |
(NOT |
SERVICED) CHOKE SHAFT WASHER Price: Call Us (NOT SERVICED) |
| e |
(NOT |
SERVICED) THROTTLE/CHOKE SHAFT FIBER O-RING Price: Call Us (NOT SERVICED) |
| f |
(NOT |
SERVICED) THROTTLE PLATE Price: Call Us (NOT SERVICED) |
| g |
(NOT |
SERVICED) SCREW M3x6 THROTTLE PLATE Price: Call Us (NOT SERVICED) |
| h |
(NOT |
SERVICED) THROTTLE SHAFT Price: Call Us (NOT SERVICED) |
| i |
(NOT |
SERVICED) IDLE JET ASSEMBLY Price: Call Us (NOT SERVICED) |
| j |
(NOT |
SERVICED) THROTTLE/CHOKE SHAFT FIBER O-RING Price: Call Us (NOT SERVICED) |
| k |
(NOT |
SERVICED) IDLE SPEED ADJUSTING SCREW Price: Call Us (NOT SERVICED) |
| l |
(NOT |
SERVICED) IDLE MIXTURE SCREW Price: Call Us (NOT SERVICED) |
| m |
(NOT |
SERVICED) CARBURETOR BODY Price: Call Us (NOT SERVICED) |
| n |
(NOT |
SERVICED) EMULSION TUBE Price: Call Us (NOT SERVICED) |
| o |
(NOT |
SERVICED) MAIN JET Price: Call Us (NOT SERVICED) |
| p |
951-11589 |
FUEL BOWL O-RING Price: $6.04 |
| q |
(NOT |
SERVICED) NEEDLE VALVE Price: Call Us (NOT SERVICED) |
| r |
(NOT |
SERVICED) NEEDLE VALVE SPRING Price: Call Us (NOT SERVICED) |
| s |
(NOT |
SERVICED) FLOAT Price: Call Us (NOT SERVICED) |
| t |
(NOT |
SERVICED) FLOAT PIN Price: Call Us (NOT SERVICED) |
| u |
908-05001 |
FLOAT BOWL Price: $7.16 |
| v |
951-11348A |
FUEL BOWL GASKET This part replaces 951-11348. Price: $5.07 |
| w |
710-04945 |
FUEL BOWL MOUNTING BOLT Price: $3.66 |
| x |
710-04938 |
FUEL DRAIN PLUG Price: $3.66 |
| y |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| 1 |
710-04916 |
BOLT M6x14 Multi-Purpose Price: $3.86 |
| 2 |
951-14609A |
VALVE COVER This part replaces 951-14609. Price: $14.42 |
| 3 |
951-11551 |
VALVE COVER GASKET Price: $9.14 |
| 4 |
951-11606A |
ROCKER ARM This part replaces 951-11606. Price: $29.12 |
| 5 |
751-11124 |
JAM NUT Price: $8.18 |
| 6 |
751-11123 |
FULCRUM NUT Price: $9.09 |
| 7 |
951-12001 |
ROCKER ARM Price: $6.65 |
| 8 |
710-04902 |
ROCKER ARM STUD Price: $5.94 |
| 9 |
951-11977 |
VALVE SPRING RETAINER Price: $3.60 |
| 10 |
751P12004A |
VALVE SPRING This part replaces 951-12004. Price: $1.74 |
| 11 |
921-04237A |
INTAKE VALVE SEAL This part replaces 921-04237. Price: $7.20 |
| 12 |
951-14641 |
EXHAUST VALVE Price: $8.71 |
| 13 |
951-14640A |
INTAKE VALVE This part replaces 951-14640. Price: $8.71 |
| 14 |
951-11687A |
PUSH ROD GUIDE This part replaces 951-11687. Price: $6.12 |
| 15 |
910-06185 |
BOLT M8x54 CYLINDER HEAD Price: $5.88 |
| 16 |
951-14639 |
CYLINDER HEAD Price: $108.54 |
| 17 |
712-05015 |
NUT M6x10mm Starter/Carb/Muff Price: $5.78 |
| 18 |
951-15072 |
MUFFLER SHIELD Price: $22.38 |
| 19 |
951-14429A |
MUFFLER ASSEMBLY This part replaces 951-14429. Price: $55.88 |
| 20 |
951-14428A |
CHOKE TEMP CONTROL THERMOSTAT This part replaces 951-14428. Price: $36.29 |
| 21 |
710-04915 |
BOLT M6x12 Multi-Purpose Price: $3.82 |
| 22 |
951-14427A |
MUFFLER GASKET This part replaces 951-14427. Price: $6.38 |
| 23 |
710-05094 |
MUFFLER STUD M6x95 Price: $3.78 |
| 24 |
951-14437 |
SPARK PLUG/F5RTC Price: $7.34 |
| 25 |
951-10351A |
SPARK ARRESTOR This part replaces 951-10351. Price: $48.91 |
| 26 |
710-04983 |
SPARK ARRESTOR SCREW Price: $3.65 |
| 27 |
951-14425 |
CARB STUD M6x87 Price: $6.18 |
| 28 |
951-11528 |
CARBURETOR INSULATOR GASKET Price: $3.90 |
| 29 |
951-11738A |
CARBURETOR INSULATOR This part replaces 951-11738. Price: $4.60 |
| 30 |
951-14424 |
CARBURETOR GASKET Price: $9.35 |
| 31 |
951-05298 |
CARBURETOR ASSEMBLY Price: $84.19 |
| 32 |
951-14422 |
CHOKE TEMP CONTROL BRACKET GASKET Price: $6.71 |
| 33 |
951-14420A |
CHOKE TEMP CONTROL BRACKET This part replaces 951-14420. Price: $8.96 |
| 34 |
951-14419A |
AIR FILTER BASE GASKET This part replaces 951-14419. Price: $7.08 |
| 35 |
951-14421A |
CHOKE TEMP CONTROL LINKAGE This part replaces 951-14421. Price: $7.10 |
| 36 |
951-14631 |
AIR FILTER ASSEMBLY Price: $16.11 |
| 37 |
(NOT |
SERVICED) AIR FILTER BASE Price: Call Us (NOT SERVICED) |
| 38 |
931-10202 |
AIR FILTER COVER Price: $8.96 |
| 39 |
951-14632A |
AIR FILTER This part replaces 951-14632. Price: $14.83 |
| 40 |
710-04969 |
BOLT M6x30 AF BASE/COIL/E-STARTER Price: $3.66 |
| 41 |
951-14431 |
CYLINDER HEAD GASKET Price: $14.44 |
| 42 |
715-04108 |
CYLINDER HEAD DOWEL PIN 10x16 Price: $3.65 |
| 43 |
747P04862A |
PUSH ROD This part replaces 747-04862. Price: $5.10 |
| 44 |
951-14432A |
TAPPET This part replaces 951-14432. Price: $7.49 |
| 45 |
951-14433A |
PISTON RING SET This part replaces 951-14433. Price: $34.45 |
| 46 |
(NOT |
SERVICED) UPPER PISTON COMPRESSION RING Price: Call Us (NOT SERVICED) |
| 47 |
(NOT |
SERVICED) LOWER PISTON COMPRESSION RING Price: Call Us (NOT SERVICED) |
| 48 |
(NOT |
SERVICED) PISTON OIL RING SEGMENT Price: Call Us (NOT SERVICED) |
| 49 |
(NOT |
SERVICED) PISTON OIL RING EXPANDER Price: Call Us (NOT SERVICED) |
| 50 |
951-11603 |
PISTON PIN SNAP RING Price: $3.53 |
| 51 |
951-14434A |
PISTION This part replaces 951-14434. Price: $56.68 |
| 52 |
951-14435 |
PISTON PIN Price: $11.17 |
| 53 |
951-14436A |
CONNECTING ROD This part replaces 951-14436. Price: $61.10 |
| 54 |
(NOT |
SERVICED) CONNECTING ROD Price: Call Us (NOT SERVICED) |
| 55 |
(NOT |
SERVICED) CONNECTING ROD CAP Price: Call Us (NOT SERVICED) |
| 56 |
(NOT |
SERVICED) CONNECTING ROD BOLT Price: Call Us (NOT SERVICED) |
| 57 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 58 |
951-05360A |
RECOIL STARTER ASSEMBLY This part replaces 951-05360. Price: $50.15 |
| 59 |
731-07925 |
STARTER HANDLE Price: $8.49 |
| 60 |
(NOT |
SERVICED) STARTER HOUSING ROPE EYELET Price: Call Us (NOT SERVICED) |
| 61 |
(NOT |
SERVICED) STARTER HOUSING Price: Call Us (NOT SERVICED) |
| 62 |
(NOT |
SERVICED) STARTER SHAFT Price: Call Us (NOT SERVICED) |
| 63 |
932-05159 |
RECOIL SPRING Price: $19.71 |
| 64 |
(NOT |
SERVICED) STARTER ROPE Price: Call Us (NOT SERVICED) |
| 65 |
(NOT |
SERVICED) STARTER PULLEY Price: Call Us (NOT SERVICED) |
| 66 |
(NOT |
SERVICED) STARTER PAWL RETURN SPRING Price: Call Us (NOT SERVICED) |
| 67 |
(NOT |
SERVICED) PRESSURE PLATE SPRING Price: Call Us (NOT SERVICED) |
| 68 |
(NOT |
SERVICED) STARTER PAWL Price: Call Us (NOT SERVICED) |
| 69 |
(NOT |
SERVICED) PRESSURE PLATE Price: Call Us (NOT SERVICED) |
| 70 |
(NOT |
SERVICED) PRESSURE PLATE BOLT Price: Call Us (NOT SERVICED) |
| 71 |
931-05236 |
ENGINE SHROUD ASSEMBLY Not Available Price: |
| 72 |
931-10631 |
ENGINE SHROUD Price: $28.92 |
| 73 |
750-05320 |
ENGINE SHROUD SPACER Price: $3.56 |
| 74 |
951-14397 |
STARTER/SHROUD REAR STUD M6x78.5 Price: $8.66 |
| 75 |
951-14819 |
STARTER/SHROUD FRONT STUD M6x74 Price: $7.56 |
| 76 |
951-14127 |
CARBON CANISTER FILTER CAP Price: $6.30 |
| 77 |
951-14400 |
CARBON CANISTER FILTER Price: $11.71 |
| 78 |
951-14629 |
CARBON CANISTER Price: $25.97 |
| 79 |
951-14126 |
CARBON CANISTER Price: $27.92 |
| 80 |
935-05045 |
CARBON CANISTER VENT HOSE 5x8x340 Price: $6.24 |
| 81 |
935-05046 |
CARBON CANISTER PURGE HOSE Price: $6.24 |
| 82 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04287. Price: $5.33 |
| 83 |
951-15491 |
FLYWHEEL Price: $89.57 |
| 84 |
951-11596A |
UPPER CRANKSHAFT SEAL This part replaces 951-11596. Price: $5.44 |
| 85 |
710-04919 |
BOLT M6x25 IGN/BRAKE/CVR PLT Price: $3.86 |
| 86 |
932-05255 |
BRAKE SPRING Not Available Price: |
| 87 |
951-05222 |
BRAKE ASSEMBLY Price: $33.99 |
| 88 |
710-04943 |
BOLT M6x28 T/X/P Multi-Purpose/Crankcase Price: $3.76 |
| 89 |
925-06178 |
IGNITION COIL ASSEMBLY Price: $90.39 |
| 90 |
950-06314 |
IGNITION COIL SPACER Price: $5.47 |
| 91 |
951-14404 |
BREATHER COVER PLATE Price: $12.64 |
| 92 |
951-14405 |
BREATHER GASKET Price: $8.96 |
| 93 |
732-04718 |
BREATHER VALVE SPRING Price: $3.78 |
| 94 |
951-11614 |
BREATHER VALVE Price: $3.53 |
| 95 |
951-11730 |
BREATHER SCREEN Price: $4.75 |
| 96 |
951-11529A |
AIR VANE This part replaces 951-11529. Price: $6.25 |
| 97 |
951-14719 |
AIR VANE BRACKET Price: $7.35 |
| 98 |
951-14720 |
CRANKCASE Price: $146.29 |
| 99 |
731-08133 |
FUEL TANK LOWER GROMMET Price: $7.21 |
| 100 |
951-14406A |
FUEL TANK GROMMET This part replaces 951-14406. Price: $9.68 |
| 101 |
731-08104 |
FUEL TANK NUT Price: $6.38 |
| 102 |
951-14407 |
FUEL CAP ASSEMBLY Price: $12.62 |
| 103 |
(NOT |
SERVICED) FUEL CAP HOUSING Price: Call Us (NOT SERVICED) |
| 104 |
951-14695 |
FUEL CAP TETHER Price: $5.59 |
| 105 |
(NOT |
SERVICED) FUEL CAP GASKET Price: Call Us (NOT SERVICED) |
| 106 |
(NOT |
SERVICED) FUEL CAP COVER Price: Call Us (NOT SERVICED) |
| 107 |
725-06031 |
PLASTIC TIE 150MM Price: $2.04 |
| 108 |
931-04629 |
Fuel Tank Price: $61.16 |
| 109 |
951-12296A |
FUEL FILTER This part replaces 951-12296. Price: $8.68 |
| 110 |
935-05047 |
FUEL HOSE Price: $13.42 |
| 111 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 112 |
723-04071A |
FUEL LINE SUPPORT CLAMP This part replaces 723-04071. Price: $2.77 |
| 113 |
951-05413 |
ELECTRIC STARTER ASSEMBLY (69:12) Price: $158.51 |
| 114 |
715-04088A |
DOWEL PIN This part replaces 715-04088. Price: $2.97 |
| 115 |
951-11680 |
FLEXIBLE CLAMP,VENT HOSE Price: $3.61 |
| 116 |
951-14413 |
COMPONENT BRACKET Price: $12.85 |
| 117 |
951-14408 |
CHOKE LINKAGE Price: $5.68 |
| 118 |
951-14409 |
THROTTLE LINKAGE SPRING Price: $7.61 |
| 119 |
951-14721 |
Throttle Linkage Price: $5.88 |
| 120 |
951-11621 |
GOVERNOR ARM SHAFT Price: $8.68 |
| 121 |
951-11902A |
OIL SEAL This part replaces 951-11574. Price: $3.36 |
| 122 |
714-04078 |
GOVERNOR ARM SHAFT COTTER PIN Price: $3.66 |
| 123 |
951-14718A |
GOVERNOR SPRING This part replaces 951-14718. Price: $6.70 |
| 124 |
951-05160A |
GOVERNOR ARM ASSEMBLY Price: $5.37 |
| 125 |
710-06221 |
GOVERNOR ARM BOLT Price: $3.68 |
| 126 |
951-14685 |
GOVERNOR ARM Price: $4.09 |
| 127 |
712-05015 |
GOVERNOR ARM NUT M6 Price: $5.78 |
| 128 |
951-14415 |
CRANKCASE COVER GASKET Price: $12.77 |
| 129 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 130 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 131 |
951-11369 |
MAIN BEARING Price: $30.42 |
| 132 |
951-14417 |
CRANKSHAFT ASSEMBLY Price: $187.05 |
| 133 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 134 |
951-11741 |
CAMSHAFT ASSEMBLY Price: $57.97 |
| 135 |
710-04980 |
BOLT M6x35 AF BASE/BRAKE/DIPSTICK Price: $3.42 |
| 136 |
951-14666 |
DIPSTICK ASSEMBLY Price: $12.54 |
| 137 |
(NOT |
SERVICED) Dipstick Price: Call Us (NOT SERVICED) |
| 138 |
921-04795A |
O-RING This part replaces 921-04795. Price: $3.38 |
| 139 |
(NOT |
SERVICED) OIL FILL TUBE Price: Call Us (NOT SERVICED) |
| 140 |
921-04697A |
O-RING This part replaces 921-04697. Price: $2.45 |
| 141 |
736-04491 |
CRANKSHAFT THRUST WASHER Price: $3.78 |
| 142 |
951-11609 |
Governor Gear Mounting Plate Price: $4.44 |
| 143 |
951-11549 |
GOVERNOR GEAR/SHAFT ASSEMBLY Price: $10.58 |
| 144 |
931-09595 |
GOVERNOR SLIDE CAP Price: $4.85 |
| 145 |
(NOT |
SERVICED) Governor Fly Weight Price: Call Us (NOT SERVICED) |
| 146 |
(NOT |
SERVICED) Governor Gear Price: Call Us (NOT SERVICED) |
| 147 |
936-05038 |
GOVERNOR SLIDE CAP WASHER Price: $4.07 |
| 148 |
(NOT |
SERVICED) GOVERNOR FLY WEIGHT PIN Price: Call Us (NOT SERVICED) |
| 149 |
916-05003 |
GOVERNOR SHAFT STOP RING Price: $4.89 |
| 150 |
(NOT |
SERVICED) GOVERNOR GEAR SHAFT Price: Call Us (NOT SERVICED) |
| 151 |
(NOT |
SERVICED) GOVERNOR GEAR WASHER Price: Call Us (NOT SERVICED) |
| 152 |
951-11733 |
OIL RETURN SEAL Price: $4.28 |
| 153 |
710-04906 |
OIL DRAIN PLUG Price: $5.86 |
| 154 |
736-04440A |
FLAT WASHER This part replaces 736-04440. Price: $6.01 |
| 155 |
951-11520 |
BREATHER HOSE ASSEMBLY Price: $5.48 |
| 156 |
726-04128 |
BREATHER HOSE CLAMP Not Available Price: |
| 157 |
(NOT |
SERVICED) Breather Hose Price: Call Us (NOT SERVICED) |
| 158 |
726-04101 |
BREATHER HOSE CLAMP Not Available Price: |
| 159 |
931-10630 |
PLASTIC SUPPORT CLAMP,WIRE Price: $5.47 |
| 160 |
951-14418A |
CRANKCASE COVER This part replaces 951-14418. Price: $83.09 |
| 161 |
951-11545A |
LOWER CRANKSHAFT SEAL This part replaces 951-11545. Price: $9.07 |
