| Ref | Part Number | Description |
|---|
| 1 |
26-7980 |
DISCONTINUED Price: Call Us |
| 2 |
52-5780 |
DISCONTINUED Price: Call Us |
| 3 |
44-6300 |
PLATE-IDLER Price: $101.69 |
| 4 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 5 |
99-5678 |
IDLER PULLEY ASM This part replaces 52-4580. Price: $65.12 |
| 6 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 7 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 8 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 9 |
323-11 |
SCREW-HH Price: $1.08 |
| 10 |
3296-5 |
NUT-HEX Price: $3.09 |
| 11 |
3211-8 |
SCREW-HH Price: $3.50 |
| 12 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 13 |
46-3380 |
BOLT-SHOULDER Price: $9.57 |
| 14 |
55-4300 |
DECAL-WARNING This part replaces 44-6470. Price: $13.99 |
| 15 |
47-5530 |
GEARBOX BASE WA *R Price: $245.50 |
| 16 |
46-3200-01 |
EXT. SPRING This part replaces 46-3200. Price: $73.49 |
| 17 |
40-0300 |
SPACER Price: $8.87 |
| 18 |
46-2620 |
SPRING BRACKET *R Price: $78.61 |
| 19 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 20 |
283-55 |
PIN-CLEVIS Price: $11.14 |
| 21 |
46-3190 |
DISCONTINUED Price: Call Us |
| 22 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 23 |
8-0909 |
DISCONTINUED Price: Call Us |
| 24 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
47-5450 |
DISCONTINUED Price: Call Us |
| 26 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 27 |
3274-1 |
SCREW-HSH Price: $5.52 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 29 |
40-0340 |
SHAFT-ROLLER, REAR Price: $29.99 |
| 30 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 31 |
44-6390 |
SPACER Price: $18.19 |
| 32 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 33 |
3211-9 |
SCREW-HH Price: $1.09 |
| 34 |
44-6260 |
V-BELT Price: $56.38 |
| 35 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 36 |
32146-20 |
NUT-HEX Price: $3.23 |
| 37 |
7-4150 |
WASHER Price: $1.19 |
| 38 |
44-6340 |
PULLEY AND HUB ASM Price: $58.11 |
| 39 |
46-8530 |
BEARING ASM Price: $93.99 |
| 40 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 41 |
26-7970 |
CAUTION DECAL (BLADE) Price: $14.83 |
| 42 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 43 |
57-0570-01 |
SKID This part replaces 57-0570. Price: $242.84 |
| 44 |
3290-224 |
LOCKWASHER-PYRAMID Price: $33.25 |
| 45 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 46 |
32128-21 |
NUT-HF Price: $0.39 |
| 47 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 48 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 49 |
72-9361 |
CUP-SCALP, ANTI This part replaces 27-1000. Price: $39.78 |
| 50 |
44-6250-03 |
BLADE-21.5 INCH This part replaces 44-6250. Price: $22.11 |
| 51 |
27-0920 |
SHAFT Price: $158.07 |
| 52 |
27-0950 |
SPACER Price: $29.99 |
| 53 |
253-139 |
SEAL-OIL Price: $12.45 |
| 54 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 55 |
323-4 |
SCREW-HH Price: $1.02 |
| 56 |
68-7260 |
DECAL-WARNING This part replaces 52-1430. Price: $25.55 |
| 57 |
27-6110 |
DISCONTINUED Price: Call Us |
| 58 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 59 |
27-6140 |
BUSHING-LOCK, TAPER Price: $84.79 |
| 60 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 61 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 62 |
29-4820 |
ROLLER Price: $14.88 |
