| Ref | Part Number | Description |
|---|
| a |
None |
Screw, M3×6 |
| aa |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| b |
736-04638A |
LOCK WASHER This part replaces 736-04638. Price: $2.88 |
| bb |
710-04938 |
FUEL DRAIN PLUG Price: $3.66 |
| c |
None |
Choke Plate |
| d |
None |
Choke Shaft |
| e |
None |
Idle Adjusting Screw |
| f |
None |
Choke Spring |
| g |
None |
Washer, P16-1C-0-16 |
| h |
None |
Gasket |
| i |
None |
Throttle Shaft |
| j |
None |
Throttle Shaft Spring |
| k |
None |
Throttle Plate |
| l |
None |
Breather Hose |
| m |
None |
Venting Hose |
| n |
None |
Carburetor Body |
| o |
None |
Idle Jet |
| p |
None |
Nozzle Tube |
| q |
None |
Main Jet |
| r |
921-04424 |
CARBURETOR FLOAT BOWL GASKET Price: $6.38 |
| s |
None |
O-Ring, P18-2001 |
| t |
None |
Needle Valve |
| u |
None |
Needle Valve Spring |
| v |
None |
Float Pin |
| w |
None |
Float |
| x |
None |
Float Bowl |
| y |
951-11348A |
FUEL BOWL GASKET This part replaces 951-11348. Price: $5.07 |
| z |
710-04945 |
BOLT M8-1 x 10 Price: $3.66 |
| 1 |
710-04968 |
BOLT M6 x 16 Price: $5.77 |
| 2 |
908-04163 |
VALVE OHV COVER Price: $10.77 |
| 3 |
921-04414 |
VALVE COVER GASKET Price: $10.77 |
| 4 |
710-05409 |
STUD M6-0.75 x 25 Price: $5.19 |
| 4 |
712-04323 |
NUT Price: $5.01 |
| 4 |
908-04160 |
RKRA-ENGINE OHV 19 Price: $5.48 |
| 5 |
908-04161 |
PUSH ROD GUIDE Price: $4.52 |
| 6 |
750-05444 |
PUSH ROD TUBE 195 Price: $8.33 |
| 7 |
710-05195 |
SCREW M8-1.25 x 45:CL5.8 Price: $5.38 |
| 8 |
908-04122 |
SPRING VALVE RET Price: $5.59 |
| 9 |
932-04771 |
COMPRESSION SPRING 16ID x 33.83 Price: $5.48 |
| 10 |
921-04416 |
INTAKE VALVE SEAL Price: $7.94 |
| 11 |
921-04416 |
INTAKE VALVE SEAL Price: $7.94 |
| 12 |
751P11885 |
INTAKE VALVE This part replaces 751-11885. Price: $5.08 |
| 13 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 14 |
608P05058 |
MUFFLER GUARD Not Available This part replaces 608-05058. Price: |
| 15 |
738-04473 |
SHOULDER SCREW 9.5 x 69 M6-1 Price: $5.59 |
| 16 |
608P05065 |
MUFFLER Not Available This part replaces 608-05065. Price: |
| 17 |
908-04114 |
EXHAUST TUBE ASSEMBLY Price: $11.49 |
| 18 |
921-04420 |
EXHAUST GASKET Price: $5.48 |
| 19 |
619P04295 |
CYLINDER HEAD This part replaces 619-04295. Price: $57.67 |
| 20 |
921-04419 |
MANIFOLD GASKET Price: $6.38 |
| 21 |
631-04519P |
MANIFOLD ASSEMBLY Price: $11.54 |
| 22 |
710-06157 |
STUD - M6-1.3 ZS Price: $3.81 |
| 23 |
710-05370 |
STUD M6-1 x 30.5 LG Price: $5.19 |
| 24 |
921-04408 |
CARBURETOR GASKET Price: $6.38 |
| 25 |
908-04168 |
AIR VANE SUPPORT Price: $8.49 |
| 26 |
712-05015 |
HEX NUT Price: $5.78 |
| 27 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
| 28 |
710-05299 |
SCREW M5-2.2 x 16 Price: $4.37 |
| 29 |
747-05476 |
CHOKE CONTROL ROD Price: $5.48 |
| 30 |
732-04835 |
EXTENSION SPRING .75 DIA x 76.5 Price: $5.38 |
| 31 |
747-05469 |
THROTTLE CONTROL ROD Price: $5.48 |
| 32 |
993-00001A |
CARBURETOR ASSEMBLY-CHOKE 195 Price: $91.17 |
| 33 |
735-04250 |
BREATHER TUBE Price: $5.48 |
| 34 |
908-04155 |
GOVERNOR SPEED ADJUSTMENT BRACKET Price: $5.59 |
| 36 |
951-14512 |
AIR FILTER ASSEMBLY Price: $11.38 |
| 37 |
None |
ELEMENT |
| 38 |
None |
ELEMENT |
| 40 |
921-04407 |
MANIFOLD GASKET Price: $6.38 |
| 41 |
710-05360 |
SCREW M5-.8 x 20 Price: $4.70 |
| 42 |
921-04413 |
HEAD GASKET Price: $10.05 |
| 43 |
715-04108 |
DOWEL PIN Price: $3.65 |
| 44 |
951-11891 |
TPT-CAM 195 Price: $8.96 |
| 45 |
931-08209 |
CHOKE VANE Price: $5.48 |
| 46 |
951-14521 |
RING SET Price: $25.21 |
| 47 |
919-04328 |
ENGINE PISTON 71MM Price: $30.69 |
| 48 |
716-04176 |
WRIST PIN CLIP 15M Price: $5.01 |
| 49 |
750-05443 |
TUBE-14.3 OD x 10.5 ID x 9.75LG Price: $7.39 |
| 50 |
619P04291 |
CONNECTING ROD This part replaces 619-04291. Price: $9.47 |
| 51 |
736-3090 |
FLAT WASHER Price: $5.79 |
| 52 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
| 54 |
712-05066 |
FLANGE NUT M5-0.8 Price: $1.78 |
| 55 |
931-09244 |
GEAR COVER Price: $8.49 |
| 56 |
924-04275 |
ELECTRIC STARTER MOTOR Price: $206.41 |
| 57 |
794-00064 |
IGNITION MODULE Price: $74.16 |
| 58 |
929-05012 |
WIRE HARNESS Price: $7.30 |
| 59 |
931-04670 |
DIPSTICK ASSEMBLY Price: $13.12 |
| 60 |
921-04421 |
O-RING 21ID x 2.8 THK Price: $5.29 |
| 61 |
921-04422 |
O-RING 15.6 ID x 1.78 DIA Price: $5.29 |
| 62 |
710-05234 |
SCREW M6-1:50:CL5. Price: $5.38 |
| 63 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 64 |
908-04171 |
SHROUD SPACER Price: $5.29 |
| 65 |
931-08157 |
ELECTRIC START ENGINE SHROUD Price: $26.79 |
| 66 |
951-04301 |
RECOIL START ASSEMBLY Price: $74.73 |
| 67 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04287. Price: $5.33 |
| 68 |
908-04144 |
START CUP Price: $9.15 |
| 69 |
951-05003 |
FLYWHEEL Price: $123.61 |
| 70 |
924-04202 |
ALTERNATOR ASSEMBLY Price: $73.07 |
| 71 |
710-05269 |
STUD M5-8:22 Price: $5.19 |
| 72 |
710-05240 |
STUD-M6-1:40 LG Price: $5.19 |
| 73 |
919-05077 |
CRANKCASE ASSEMBLY Price: $209.90 |
| 74 |
710-05293 |
SCREW M6-1 x 16 Price: $4.37 |
| 75 |
908-04162 |
BREATHER COVER Price: $7.39 |
| 76 |
921-04430 |
BREATHER GASKET Price: $5.10 |
| 77 |
931-05122 |
BREATHER BODY ASSEMBLY This part replaces 631-05122. Price: $18.97 |
| 78 |
951-14407 |
FUEL CAP ASSEMBLY Price: $12.62 |
| 79 |
731-08104 |
FUEL TANK NUT Price: $6.38 |
| 80 |
731-08133 |
FUEL TANK LOWER GROMMET Price: $7.21 |
| 81 |
931-04629 |
FUEL TANK Price: $61.16 |
| 82 |
710-04915 |
BOLT M6-1 x 12 GR8.8 Price: $3.82 |
| 83 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 84 |
751P14165 |
FUEL HOSE This part replaces 751-14165. Price: $4.80 |
| 85 |
951-12296A |
FUEL FILTER This part replaces 951-12296. Price: $8.68 |
| 86 |
908-04158 |
GOVERNOR CONTROL ARM BRACKET Price: $7.39 |
| 87 |
747-05399 |
GOVONOR CONTROL ROD Price: $8.96 |
| 88 |
951-11902A |
OIL SEAL This part replaces 951-11574. Price: $3.36 |
| 89 |
736-04527 |
FLAT WASHER 6.8 x 16 x .4 Price: $5.38 |
| 90 |
714-04078 |
COTTER PIN Price: $3.66 |
| 91 |
735-05005 |
HOSE-5MM Price: $5.59 |
| 93 |
951-14400 |
CARBON CANISTER FILTER Price: $11.71 |
| 94 |
951-14127 |
CARBON CANISTER FILTER CAP Price: $6.30 |
| 95 |
947-04244 |
CHOKE OVER RIDE ROD ASSEMBLY Price: $16.98 |
| 96 |
921-04433 |
CRANKCASE GASKET Price: $11.31 |
| 97 |
715-04116 |
DOWEL PIN Price: $4.37 |
| 98 |
951-12126 |
OIL SEAL-25 x 41.25 x 6 Price: $12.42 |
| 99 |
951-11369 |
BEARING Price: $30.42 |
| 100 |
919-04336 |
CRANKSHAFT-END 195 25M Price: $88.80 |
| 101 |
908-04182 |
OIL SLINGER SUPPORT BRACKET Price: $4.70 |
| 102 |
917-04108 |
OIL SLING GEAR ASSEMBLY Price: $8.02 |
| 103 |
917-04093 |
GEAR ASSEMBLY Not Available Price: |
| 104 |
736-04527 |
FLAT WASHER 6.8 x 16 x .4 Price: $5.38 |
| 105 |
919-04300 |
CAM SHAFT ASSEMBLY Price: $34.51 |
| 106 |
919-04287 |
CRANKCASE COVER Price: $79.68 |
| 107 |
710-05198 |
HHFLG M6-1 x 35 CL8.8 Price: $5.01 |
| 108 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 109 |
951-11622A |
FLEXIBLE CLAMP This part replaces 951-11622. Price: $3.42 |
| 110 |
951-14126 |
CARBON CANISTER Price: $27.92 |
| 111 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
