| Ref | Part Number | Description |
|---|
| 1 |
106-1100 |
CASE-AXLE Price: $406.39 |
| 2 |
532149723 |
Muffler Side Price: $45.99 |
| 2 |
99-7594 |
SEAL-OIL Price: $5.99 |
| 3 |
99-7535 |
PLUG Price: $8.15 |
| 4 |
99-7536 |
WASHER-SEAL Price: $2.58 |
| 5 |
95-7528 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 6 |
99-7532 |
BEARING-ROLLER, TAPER Price: $45.81 |
| 7 |
95-7526 |
COVER-AXLE Price: $87.93 |
| 8 |
106-1072 |
O-RING Price: $21.08 |
| 8 |
532139123 |
Pulley, V-Idler This part replaces 532121361. Price: $22.99 |
| 9 |
532177748 |
Keeper Asm. Belt Engine VGT Price: $11.99 |
| 9 |
99-7589 |
PLUG Price: $3.73 |
| 10 |
532175287 |
Bushing Price: $14.99 |
| 10 |
99-7590 |
WASHER-SEAL Price: $2.94 |
| 11 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $225.99 |
| 12 |
106-1102 |
BOLT-STOP Price: $22.71 |
| 12 |
532143996 |
Pulley Engine VGT Elect Clutch Price: $32.99 |
| 15 |
532179115 |
Tank Fuel Rear 5.0 Price: $86.99 |
| 18 |
532182902 |
CAP.ASM.FUEL.BLACK This part replaces 532181803. Price: $21.99 |
| 20 |
532177328 |
THROTTLE CONTROL This part replaces 532182937. Price: $29.99 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $8.99 |
| 22 |
532175441 |
CHOKE CONTROL This part replaces 532178148. Price: $22.99 |
| 25 |
873920600 |
Nut Keps 3/8-24 Price: $3.99 |
| 26 |
532003645 |
Bushing This part replaces 532124952. Price: $2.99 |
| 27 |
532139277 |
Stem Tank Fuel Price: $5.99 |
| 28 |
532008542 |
Line, Fuel This part replaces 532124703. Price: $4.99 |
| 29 |
532137180 |
Spark Arrester Kit Price: $128.99 |
| 31 |
532145006 |
Clip Push-In Hinged Price: $2.99 |
| 37 |
532123487 |
Clamp Hose Price: $3.99 |
| 39 |
817490636 |
Screw TT 3/8-16 x 2-1/4 unc Price: $3.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
Washer 1-1/2 OD X 15/32 ID X .250 Price: $4.99 |
| 42 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 43 |
532179953 |
Bolt Hex 7/16-20 X 3.75 Ga. 5 Price: $3.99 |
| 47 |
532175288 |
Bushing Price: $3.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER This part replaces 532146629. Price: $11.99 |
| 69 |
532186054 |
Gasket Price: $3.99 |
| 70 |
532175545 |
Tube Exhaust LH Price: $53.99 |
| 71 |
532175546 |
Tube Exhaust RH Price: $53.99 |
| 74 |
532162295 |
Elbow Street Brass Price: $17.99 |
| 80 |
873350800 |
Nut Jam Hex 1/2-13 Unc This part replaces 532163305. Price: $1.99 |
| 81 |
532188800 |
Oil Drain Tube Price: $2.99 |
| 82 |
532188799 |
Valve Drain Oil Price: $45.99 |
| 83 |
532171877 |
Bolt 5/16-18 unc x 1-3/4 W/Sems Price: $3.99 |
| 84 |
817060624 |
Screw 3/8-16 x 1-1/2 Price: $3.99 |
