| Ref | Part Number | Description |
|---|
| 1 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 2 |
3-8448 |
WASHER-THRUST Price: $2.58 |
| 2 |
532179758 |
MUFFLER.B&S.MODEL.21.11HP.OHV Price: $69.99 |
| 3 |
26-8310-01 |
BAIL-LIFT This part replaces 26-8310. Price: $233.66 |
| 4 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 5 |
6-1030 |
HOUSING Price: $158.52 |
| 6 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 8 |
325-17 |
SCREW-HH Price: $2.90 |
| 9 |
5-1091 |
SPACER Price: $4.98 |
| 9 |
596501502 |
Keepers This part replaces 501832601. Price: $9.99 |
| 10 |
3-9280-01 |
DRAWBAR This part replaces 3-9280. Price: $321.93 |
| 11 |
325-14 |
SCREW-HH Price: $2.64 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
5-1706 |
SPRING-EXTENSION Price: $12.91 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 43 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
