| Ref | Part Number | Description |
|---|
| 1 |
93-6816 |
CONTROL-THROTTLE Price: $49.33 |
| 2 |
50947 |
SCREW, 3/8-16X1.25 WAHHTAPBLKP Price: Call Us |
| 2 |
93-6743 |
STOP-THROTTLE Price: $8.04 |
| 3 |
138489 |
WASHER, EXLK .384X.69X.04 Price: Call Us |
| 3 |
218-594 |
FUSE-20 AMP Price: $3.02 |
| 4 |
218-578 |
FUSE-BLADE, 10 AMP Price: $2.58 |
| 4 |
307174 |
NIPPLE 3/8-18 NPT X 4" ZINC Price: Call Us |
| 5 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 6 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 6 |
47828 |
CAP PIPE 3/8-18 NPT ZN PL Price: Call Us |
| 7 |
93-6762 |
SWITCH-BALL Price: $132.17 |
| 8 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 8 |
47452 |
TUBING, .25X.50X BULK GAS LINE Price: Call Us |
| 9 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 10 |
315599 |
REGULATOR, VOLTAGE BS W/O SENSOR Price: Call Us |
| 10 |
3250-13 |
SCREW-PPH Price: $0.95 |
| 11 |
3274-90 |
SCREW-HSH Price: $1.53 |
| 12 |
92-9775 |
CLUSTER-LAMP, WARNING Price: $147.98 |
| 13 |
93-4411 |
GAUGE-TEMPERATURE Price: $125.82 |
| 14 |
80-6980 |
LATCH Price: $81.68 |
| 15 |
44-2212 |
AMBER INDICATOR LIGHT ASM Price: $72.17 |
| 16 |
35287 |
SCREW, #8-32X.38 HHWATAP Price: Call Us |
| 16 |
92-3194 |
DISCONTINUED Price: Call Us |
| 17 |
305553 |
MUFFLR 14/18 TWIN NLSN22785C Price: Call Us |
| 17 |
93-6902 |
DECAL-BLOCK, FUSE Price: $6.45 |
| 18 |
305554 |
EXHAUST TUBE 15HP RH B&S VANG Price: Call Us |
| 18 |
32149-9 |
NUT-HEX, KEPS Price: $1.15 |
| 19 |
56472 |
DEFLECTOR SIDE OUT (BS222573) Price: Call Us |
| 19 |
94-4985 |
DECAL-PANEL, INSTRUMENT Price: $57.02 |
| 20 |
305555 |
EXHAUST TUBE 15HP LH B&S VANG Price: Call Us |
| 20 |
94-3691-03 |
PANEL-INSTRUMENT ASM This part replaces 94-3691. Price: $124.28 |
| 21 |
70-1480 |
RELAY Price: $105.19 |
| 22 |
32128-33 |
NUT-HF Price: $0.25 |
| 22 |
9796 |
BRACKET, TRANSAXLE Price: Call Us |
| 23 |
35497 |
SCREW, 5/16-18X.50 WAHHTAP Price: Call Us |
| 23 |
80-7345 |
DISCONTINUED Price: Call Us |
| 24 |
2412-39 |
CLAMP-R Price: $1.70 |
| 24 |
44811 |
SCREW, 1/4-20X.75 WAHHTAP Price: Call Us |
| 25 |
304709853 |
BRACKET, MUFFLER Price: Call Us |
| 25 |
94-3692 |
DISCONTINUED Price: Call Us |
| 26 |
57072 |
BOLT, 5/16-18X.63 CARRLN Price: Call Us |
| 26 |
93-6941 |
SEAL-TRIM Price: $2.36 |
| 27 |
309436 |
PUSHNUT, 5/16 BOLT RETAINER Price: Call Us |
| 28 |
320922853 |
SHIELD, MUFFLER HEAT TWIN Price: Call Us |
| 29 |
55273 |
NUT 5/16-18 HXWDFLLK Price: Call Us |
| 30 |
219-18 |
DISCONTINUED Price: Call Us |
| 31 |
218-562 |
LENS Price: $10.44 |
| 31 |
314797 |
OIL SENSOR, B&S TWIN CYL Price: Call Us |
| 32 |
32128-44 |
NUT Price: $2.69 |
| 33 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 33 |
57569 |
RETAINER .31IDX.62X.03 WERE Price: Call Us |
| 34 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 35 |
93-7726 |
DISCONTINUED Price: Call Us |
| 41 |
304439 |
KNOB, THROTTLE CTL MOLD Price: Call Us |
| 42 |
307362 |
THROTTLE CONTROL ERO 18 TWIN Price: Call Us |
| 43 |
320553 |
SCREW, 10-24X.63PHPNMA Price: Call Us |
| 44 |
308459 |
NUT #10-24 HXHDNYLK Price: Call Us |
| 45 |
159585 |
SCREW, #8-32X.38 PHPNMA Price: Call Us |
| 46 |
120622 |
NUT, #8-32 REGHEX Price: Call Us |
| 57 |
321306853 |
HEAT SHIELD V/G LT EURO Price: Call Us |
