| Ref | Part Number | Description |
|---|
| 1 |
233-21 |
KNOB Price: $12.99 |
| 2 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 2 |
532179758 |
MUFFLER Price: $70.99 |
| 3 |
38-3400 |
GUARD-RUBBER Price: $8.02 |
| 4 |
105-7806 |
LATCH-LEVER, VALVE Price: $35.46 |
| 5 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 6 |
21-9010 |
LEVER-VALVE, PIVOT MOUNT Price: $28.78 |
| 7 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 8 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 9 |
92-5512 |
FITTING-STR This part replaces 95-8849. Price: $21.46 |
| 10 |
100-6586 |
CYLINDER-HYD, 2.5 INCH Price: $858.08 |
| 11 |
105-7839-03 |
VALVE LEVER ASM Price: $102.95 |
| 12 |
100-6591 |
CYLINDER-HYD, 3 INCH Price: $968.00 |
| 12 |
532140186 |
PULLEY ENGINE Price: $55.99 |
| 14 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
353-512 |
PLUG Price: $15.26 |
| 15 |
581289901 |
FUEL.TANK.ASM.1.5.GAL.NON-EPA This part replaces 532407545. Price: $54.99 |
| 16 |
283-17 |
PIN-CLEVIS Price: $4.89 |
| 17 |
106-8071 |
VALVE ASM This part replaces 106-8071-01. Price: $481.47 |
| 18 |
340-99 |
FITTING-HYD, 90 DEG Price: $32.27 |
| 18 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532430220. Price: $14.99 |
| 19 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 20 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $22.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
| 21 |
92-7834 |
HOSE-HYD Price: $11.20 |
| 22 |
340-110 |
FITTING-SWIVEL, 90 DEG Price: $49.98 |
| 23 |
63-9260 |
MANIFOLD VALVE ASM Price: $136.31 |
| 24 |
63-8990 |
HOSE-HYD Price: $57.67 |
| 25 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 26 |
92-7833 |
HOSE ASM Price: $59.90 |
| 28 |
532137040 |
LINE.FUEL.20 Price: $3.99 |
| 29 |
532137180 |
ARRESTER SPARK (OPTIONAL) Price: $128.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
539990247 |
LOCKWASHER.7/16 This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 69 |
532272293 |
Gasket Eng 1 313 Id Tin Plated This part replaces 532165291. Price: $7.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532150280 |
SUB= 150280 This part replaces 532173937. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
