| Ref | Part Number | Description |
|---|
| 1 |
98-9517 |
BOLT-ROD, CONNECTING Price: $10.31 |
| 2 |
117-7588 |
METAL-CRANKPIN (-0.4MM) This part replaces 98-9520. Price: $49.06 |
| 2 |
721-0261 |
O-Ring, 2.75 ID X .103 Dia Price: $9.22 |
| 2 |
98-9519 |
BEARING-ROD (-0.2MM) Price: $43.73 |
| 2 |
98-9553 |
BEARING-ROD (STD) Price: $52.92 |
| 3 |
115-3014 |
BUSHING-PIN, PISTON This part replaces 98-9515. Price: $19.81 |
| 3 |
710-3212 |
SCREW 1/4-20 x 2 Not Available Price: |
| 4 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 4 |
98-9514 |
CIRCLIP-PIN, PISTON Price: $2.79 |
| 5 |
748-3042 |
ADAPTER-PUMP BDU21 Not Available Price: |
| 5 |
98-9513 |
PIN-PISTON Price: $13.17 |
| 6 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 6 |
98-9551 |
PISTON RING ASM (STD) Price: $220.34 |
| 6 |
98-9619 |
PISTON RING ASM (0.5MM) Price: $96.35 |
| 7 |
112-8415 |
PISTON ASM This part replaces 98-9470. Price: $456.30 |
| 7 |
710-3237 |
SCREW M6-1.0 x 20 Not Available Price: |
| 7 |
98-9550 |
PISTON (STD) Price: $274.67 |
| 8 |
748-3030A |
DRIVE COUPLING Not Available Price: |
| 8 |
98-9542 |
GEAR-DRIVE, OIL PUMP Price: $89.04 |
| 9 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 9 |
98-9532 |
GEAR-CRANKSHAFT Price: $169.43 |
| 10 |
948-3044 |
DRIVE HUB Not Available This part replaces 748-3044. Price: |
| 10 |
98-9666 |
KEY Price: $3.58 |
| 11 |
110-3729 |
BALL This part replaces 98-7473. Price: $0.69 |
| 11 |
721-3025 |
O-RING 2.489 ID x .070 Not Available Price: |
| 12 |
735-3029 |
COUPLING BOOT Not Available Price: |
| 12 |
98-9375 |
PIN-STRAIGHT Price: $0.41 |
| 13 |
916-0171 |
RETAINING RING This part replaces 716-0171. Price: $5.04 |
| 13 |
98-9522 |
SLEEVE-CRANKSHAFT Price: $116.47 |
| 14 |
127-0416 |
METAL-SIDE (+0.2MM) This part replaces 98-9414. Price: $21.04 |
| 14 |
736-0463 |
Washer, Flat, .25 X .62 X .052 Thk Price: $3.91 |
| 14 |
98-9413 |
BEARING-THRUST (STD) Price: $16.90 |
| 14 |
98-9415 |
BEARING-THRUST (0.4MM) Price: $9.77 |
| 15 |
127-0437 |
METAL-SIDE (+0.2MM) This part replaces 98-9689. Price: $18.42 |
| 15 |
127-0438 |
METAL-SIDE (+0.40MM) This part replaces 98-9690. Price: $12.65 |
| 15 |
98-9688 |
BEARING-THRUST (STD) Price: $16.90 |
| 16 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 98-9556. Price: $86.06 |
| 16 |
748-3037 |
FAN NUT 1/4-20 Not Available Price: |
| 16 |
98-9526 |
BEARING-MAIN (0.2MM) Price: $64.36 |
| 16 |
98-9527 |
BEARING-MAIN (0.4MM) Price: $63.74 |
| 17 |
127-0433 |
METAL-CRANKSHAFT (-0.2MM) This part replaces 98-9530. Price: $60.46 |
| 17 |
738-3098 |
DRIVE SHAFT 20.38 Not Available Price: |
| 17 |
98-9524 |
METAL-CRANKSHAFT (STD SET) This part replaces 98-9555. Price: $62.26 |
| 17 |
98-9531 |
BEARING-MAIN (0.4MM) Price: $39.97 |
| 18 |
112-7005 |
BEARING-MAIN (STD) This part replaces 98-9554. Price: $66.99 |
| 18 |
710-3211 |
Screw, Socket Hd Cap, 1/4-20 X 1.75 Lg Price: $4.52 |
| 18 |
98-9528 |
BEARING-MAIN (-0.2MM) Price: $15.04 |
| 18 |
98-9529 |
BEARING-MAIN (0.4MM) Price: $40.04 |
| 19 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 19 |
98-9373 |
O-RING Price: $3.11 |
| 20 |
710-3258 |
HEX SCREW PATCH-M8X1.25X50MM Not Available Price: |
| 20 |
98-9521 |
COLLAR-CRANKSHAFT Price: $84.21 |
| 21 |
936-3008 |
Washer, Flat, .344 x .750 x .120 This part replaces 736-3008. Price: $6.24 |
| 22 |
KH-24-029-12-S |
DRIVE SHAFT ADAPTER This part replaces 719-3096. Price: $32.02 |
| 502194701 |
502194701 |
Price: $29.97 |
| 502194801 |
502194801 |
Price: $7.55 |
| 502194901 |
502194901 |
Price: $12.55 |
| 502195001 |
502195001 |
Price: $6.60 |
| 725233351 |
725233351 |
SCREW M6S 5X25 Price: $2.99 |
